Seite 1/4
INSTRUCTION MANUAL
ENERGY STORAGE POWER SUPPLY
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
8
8
8
Thank you for selecting and buying V-TAC Product. V-TAC will serve you the best.
Please read these instructions carefully & keep this user manual handy for future
reference. If you have any another query, please contact our dealer or local vendor
from whom you have purchased the product. They are trained and ready to serve you
at the best.
INTRODUCTION
TECHNICAL DATA
Multi-Language Manual QR CODE
Please scan the QR code to access the manual
in multiple languages.
Model VT-303
Battery capacity 252Wh
Net Weight 3.2Kg
Dimension 230x208x168mm
DC Input Port 20V 3A
(Support 12-24V)
Auxiliary Charge
Output 12V 8A
AC output port 230V, Pure Sine Wave/
300W, Peak 600W
USB output port 5V2.4A, QC3.0,
USB-C30W
Battery Lithium Electronic
Battery
Battery Cycle ≥1000
Work Temperature -10~40°C
Charging Temperature 0~40°C
WARNING
PACKAGING LIST
1. Please make sure to turn off the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. Please read all instructions before using this product.
4. In order to reduce the risk, close supervision is required when using this product near
children.
5. The use of accessories recommended or sold by non professional product manufacturers
may lead to the risk of electric shock.
6. When the product is not in use, please pull the power plug out of the product socket.
7. It is forbidden to dismantle the product, which may lead to unpredictable risks such as fire,
explosion or electric shock.
8. Do not use damaged wires or plugs or damaged output cables to use the product, which
may cause electric shock.
9. Please charge the product in a well ventilated place. Do not restrict the ventilation of the
product in any way.
10. Please put the product in a well ventilated and dry place to avoid the risk of electric
shock due to water intrusion.
11. It is forbidden to expose the product to fire or temperature higher than 130°C, which may
lead to fire, explosion and other safety accidents.
12. It is forbidden to use or place the product under high temperature (direct hot sunshine or
hot car interior), otherwise the internal battery may overheat, catch fire or function failure,
shorten the service life and other risks.
13. Please charge the product every three months to prevent the battery from running out.
Caution, risk of
electric shock.
This marking indicates that this
product should not be disposed of
with other household wastes.
20
PAP
Power supply Car Charger AC Power
Adapter User Guide
User guide
8
8
8
Auxiliary Charge Output
USB Output key, Click Switch
LED Screen
230V AC Output
DC Output
DC Input Charging
INPUT: 12V -24 V
12V-8A
12V -8A
QC3.0 USB-C3 0W
AC 220 V 3 00 W AC 220 V 3 00 W
12V-8A
PARTS & DESCRIPTION
7
7
Display percentage
of input power
Output power
Input power DC: DC working indicator
AC: AC work indicator
Over operating temperature warning /
overload warning / short circuit warning
Flashing is low voltage warning
LED light: click normally on, click SOS
mode again, and click LED light off again
1: High temperature protection. When the temperature is greater than or equal to 75°C, the
machine will start the automatic protection and prohibit input and output. When the temperature is
less than 75°C, it will return to normal.
2: Power on / off key. Please click the power key to turn off the power.
3: When the indication of DC, USB and AC lights up, it means that the output port has been
turned on, and the corresponding equipment can be powered.
4: When not using the power output port, please press 1,2,7,11 or power key to turn off the power
to save power.
5: At low temperature, the battery capacity of the product may be affected. The product can be
charged in the temperature range of 0-40°C, and the equipment can be powered in the tempera-
ture range of -10°C to +40°C.
6: For the first time, it is recommended to fully charge the battery to avoid the inconvenience
caused by insufficient power.
DC Output on key, Click ON/OFF
USB 2.0 Output
USB-C30W Output
USB-A: QC3.0 Output
AC Output on key, Click ON/OFF
AC Working Indicator
PRECAUTIONS FOR USE
