REMOTE CONTROLLER
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any
another query, please contact our dealer or local vendor from whom you have purchased the product. They are
trained and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The
warranty does not apply to damage caused by incorrect installation or abnormal wear and tear. The company
gives no warranty against damage to any surface due to incorrect removal and installation of the product. The
products are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the
warranty. This product is warranted for manufacturing defects only.
WARNING!
1. For Indoor use only
2. In the using of the remote, if the indicated lamp blinking quickly, pls change the battery in time. Pls don’t
use poor quality battery to avoid the leaking of battery liquid to damage the remote.
3. Pls don’t use the remote on the wide-range metal or strong electromagnetic wave area, otherwise, it will
badly affect the controlling distance.
Caution, risk of electric shock.
PRODUCT KEY DIAGRAM FEATURES
This marking indicates that this
product should not be disposed
of with other household wastes.
2
YEARS
WARRANTY
*
LINKING & UNLINKING
Remark: The light can be working after linking with the remote.
If the light not blink slowly, the linking failed, Pls switch off the light again, and follow the
above steps again.
LINKING INSTRUCTIONS
UNLINKING INSTRUCTIONS
If the light not blink quickly, the unlink failed, pls switch off the light again, and follow the above
steps to unlink again.
TECHNICAL DATA:
MODEL VT-2438
INPUT VOLTAGE 3V (AAA x 2PCS)
(BATTERY NOT INCLUDED)
TRANSMISSION
FREQUENCY 2.4GHz
TRANSMISSION
POWER 6dBm
STANDBY POWER
CONSUMPTION 15μA
DIMENSION 47x19x153mm
Color Ring
Speed+
Mode
Speed-
White light
Saturation
/ CCT Control
Indicator light
Master OFFMaster ON ON OFFW
MS- S+
1 2
3 4
5 6
7 8
“ ” Zone OFF
“ ” Zone ON
(Link/Unlink)
Brightness
Dimming
Slide the brightness slider to adjust the brightness.
Touch the color ring to change colors.
Under white light mode, adjust color temperature;
Under color light mode, change color saturation.
M
S-
ON
OFF
WPress the button to get white light.
Touch ON button, turn on the linked device.
Touch OFF button, turn o the linked device.
Dynamic mode switching button.
Lower the dynamic mode speed.
Accelerate the dynamic mode speed.
S+
Switch off the light,
after 10 seconds
switch on again
1 2 3 The light blink 3 times slowly
means the linking is done
successfully.
When the light on, short press
any zone of " " 3 times
within 3 seconds
Link/Unlink
button
ON OFFW
MS- S+
1 2
3 4
5 6
7 8
B
+
G
R
Power
Supply
controller
B
+
G
R
Power
Supply
controller
3The light blinking 10
times quickly, means the
unlinking successfully.
Switch off the light,
after 10 seconds
switch on again
1When the light on, short
press " " 5 times within
3 seconds
2
Unlinking must be the same
zone with the Linking
Link/Unlink
button
ON OFFW
MS- S+
1 2
3 4
5 6
7 8
B
+
G
R
Power
Supply
controller
B
+
G
R
Power
Supply
controller
You can add an endless numbers of lights to a zone on the 8 channel remote by linking the lights to dierent zones.
This way you are completely exible in creating dierent group combinations. Below you can see some grouping
examples.
1 2 3 11 2
Remark:
1. The user can re-programme freely as needed. One remote can control countless lamps or controllers, but one lamp or
controller can only be controlled by four remotes ( Max ).
2. Please check the battery installation and controller ( totally discharge the power ), when you programme after switching
o and switching on.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
COMPATIBLE DEVICES
Compatible with the below devices (Not included; available to buy separately)
(SKU: 2912
VT-2432)
(NOT INCLUDED)
(SKU: 2913
VT-2434)
(NOT INCLUDED)
VT-2432 VT-2434
