REMOTE CONTROLLER
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any
another query, please contact our dealer or local vendor from whom you have purchased the product. They are
trained and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The
warranty does not apply to damage caused by incorrect installation or abnormal wear and tear. The company
gives no warranty against damage to any surface due to incorrect removal and installation of the product. The
products are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the
warranty. This product is warranted for manufacturing defects only.
WARNING!
1. For Indoor use only
2. In the using of the remote, if the indicated lamp blinking quickly, pls change the battery in time. Pls don’t
use poor quality battery to avoid the leaking of battery liquid to damage the remote.
3. Pls don’t use the remote on the wide-range metal or strong electromagnetic wave area, otherwise, it will
badly aïŹ€ect the controlling distance.
Caution, risk of electric shock.
PRODUCT KEY DIAGRAM
REMOTE FEATURES
This marking indicates that this
product should not be disposed
of with other household wastes.
2
YEARS
WARRANTY
*
LINKING & UNLINKING
Remark: The light can be working after linking with the remote.
If the light not blink slowly, the linking failed, Pls switch oïŹ€ the light again, and follow the
above steps again.
LINKING INSTRUCTIONS
UNLINKING INSTRUCTIONS
If the light not blink quickly, the unlink failed, pls switch oïŹ€ the light again, and follow the above
steps to unlink again.
GROUPING OF SEVERAL LIGHTS
COMPATIBLE DEVICES
TECHNICAL DATA:
MODEL VT-2436
INPUT VOLTAGE 3V (AAA x 2PCS)
(BATTERY NOT INCLUDED)
MODULATION
METHOD GFSK
TRANSMISSION
POWER 6dBm
STANDBY POWER
CONSUMPTION 20ÎŒA
DIMENSION 53x21x110.5mm
Brightness
/ Color Temperature
Zone ON
Master ON
Master OFF
4x(un) Link Light
Press once change
to color temperature
Zone OFF
● To dim all dual white lights at once or change the color
temperature, first press ‘Master ON’.
● To do this with individual lights, first press ‘ Zone ON’.
Secondly, set the adjustment for color temperature or
brightness.
● To turn on the night light mode of a single ( dual white )
light, press and hold the ‘Zone OFF’ from one of the 4
Zones.
● To turn on all the lights in night light mode, press and hold
‘Master OFF’.
● For remote control FUT006, the default mode is to adjust the
brightness, rotating the wheel from left to right, brightness
up, from right to left, brightness down. Switching to
adjusting the color temperature by pressing the middle
button once, left to right, cooler, right to left, warmer.
When the light on, short press
any zone of " " 3 time within
3 seconds
Switch off the light,
after 10 seconds
switch on again
1 2 3 The light blink 3 times
slowly means the linking
is done successfully.
Link/Unlink
button
B
+
G
R
Power
Supply
controller
B
+
G
R
Power
Supply
controller
When the light on, short press
" " 5 times within 3 seconds
Unlinking must be the same zone
with the Linking
Switch off the light,
after 10 seconds
switch on again
1 2 3 The light blinking 10
times quickly, means the
unlinking successfully.
Link/Unlink
button
B
+
G
R
Power
Supply
controller
B
+
G
R
Power
Supply
controller
You can add an endless numbers of lights to a zone on the 4 channel remote by linking the lights to diïŹ€erent
zones. This way you are completely ïŹ‚exible in creating diïŹ€erent group combinations. Below you can see some
grouping examples.
Remark:
1. The user can re-programme freely as needed. One remote can control countless lamps or controllers, but
one lamp or controller can only be controlled by four remotes ( Max ).
2. Please check the battery installation and controller ( totally discharge the power ), when you programme
after switching oïŹ€ and switching on.
VT-2431
(SKU: 2911
VT-2431)
(NOT INCLUDED)
Compatible with the below devices (Not included; available to buy separately)
(SKU: 2919
VT-2440)
(NOT INCLUDED)
(SKU: 2916
VT-2439)
(NOT INCLUDED)
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
