V-TAC VT-15200ST Bedienungsanleitung
Lesen Sie kostenlos die đ deutsche Bedienungsanleitung fĂźr V-TAC VT-15200ST (2 Seiten) in der Kategorie Lampe. Dieser Bedienungsanleitung war fĂźr 11 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet
Seite 1/2
1. Installation must be performed by a qualiďŹed electrician
2. Replace any cracked protective shield.
3. Keep away from the ďŹre.
4. Don't immerse in the water
5. Luminaire cannot be installed in low-lying areas, so as not to soak.
NC
ON OF F
W Y
W Y
AUTO
3H 5H
8H
INSTRUCTION MANUAL
TECHNICAL DATA
MODEL VT-15111ST
DC: 5V, 40W/60W/70W
2500Lm
90°
SMD 5054
6-8 Meters
LiFePO4 3.2V Battery
4-6 Hours
8-10 Hours
SOLAR PANEL WATTS
10224
10225
10226
10227
10228
10229
SKU
LUMENS
BEAM ANGLE
LED CHIP TYPE
MAX. MOUNTING HEIGHT
BATTERY TYPE
CHARGING TIME
WORKING TIME
INTRODUCTION & WARRANTY
WARNING
PARTS INCLUDED
LAMP POST INSTALLATION
INSTALLATION GUIDE
MAINTENANCE
WALL MOUNT INSTALLATION
REMOTE CONTROL
LED SOLAR STREET LIGHT
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read
these instructions carefully before starting the installation and keep this manual handy for future
reference. If you have any another query, please contact our dealer or local vendor from whom
you have purchased the product. They are trained and ready to serve you at the best. The warranty
is valid for 2 years from the date of purchase. The warranty does not apply to damage caused by
incorrect installation or abnormal wear and tear. The company gives no warranty against damage
to any surface due to incorrect removal and installation of the product. This product is warranted
for manufacturing defects only.
⢠Before installing please remove all the parts to check if all are in good condition or not.
⢠Install the Protruding Pole on a wall or on a Lamp Pole with the Expansion Screws
⢠Fix the Solar Panel on the Bracket. Fix them on the Mounting Arm and tighten the screws.
⢠Place the Mounting Arm on the top pole part of the Protruding Pole
⢠Fix the Luminaire on the front portion of the Protruding Pole
⢠Make sure that the connection Plug on the luminaire is carefully stretched out from the hole
beneath the Protruding Pole
⢠Now Connect the plugs and tighten the Waterproof Cap.
⢠The luminaire should be connected to the solar panel against the sun light. Please makes sure
the solar panel is adjusted in correct angle in order to receive sunlight.
⢠Aîer installation test the light using the remote control.
⢠The remote control is designed with an operation distance of 8-10m
⢠Clean the light with a dry, lint-free cloth.
⢠Check the solar panel for dirt regularly. If dirt or is present remove it to guarantee
ďŹawless function of the product.
⢠Especially during the winter, keep the product free from snow and ice.
⢠ConďŹrm installation direction is correct (solar panel should be at top)
⢠ConďŹrm no objects blocking the solar panel to receive sunlight
MULTI-LANGUAGE MANUAL QR CODE
Please scan the QR code to access the manual in
multiple languages.
This marking indicates that this
product should not be disposed of
with other household wastes.
Turn On Turn Oî
Brightness +/-
Optically controlled
mode
100% Brightness
80% Brightness
50% Brightness
3H: The light will
work for 3 Hrs 5H: The light will
work for 5 Hrs
8H: The light will
work for 8 Hrs
NC
ON O FF
W Y
W Y
AUTO
3 H 5H
8H
Solar Panel
Expansion Screw 2x4
Protruding Pole
(For Wall/Pole Installation)
Mounting Arm
(For Solar Panel)
1 Expansion Plate
(For Lamp Post Installation)
1.5m Wire Solar Panel Bracket
Solar Light Remote Control
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
Light Source
Internal six angle
screw ďŹxation
Protruding Pole
(For Wall/Pole Installation)
Hole
Screw Fixation
Expansion Plate
Light Source
Internal six angle
screw ďŹxation
Hole
Screw ďŹxation
Mounting Arm
(For Solar Panel)
Protruding Pole
(For Wall/Pole Installation)
Plug the male and female plugs
and tighten the waterproof cap
Solar Charging
(The battery is in the lamp housing)
Mounting Arm
(For Solar Panel)
Solar Charging
(The battery is in the lamp housing)
VT-15300SVT-15200ST
3500Lm3000Lm
Produktspezifikationen
| Marke: | V-TAC |
| Kategorie: | Lampe |
| Modell: | VT-15200ST |
