Trijicon ACOG®
There’s a reason the Trijicon ACOG® (Advanced Combat
Optical Gunsight) is the official medium-distance engagement
optic of the U.S. Marine Corps and U.S. Special Operations
Forces. And why more than one million have been produced.
Each one is specifically engineered to provide increased
hit potential in all lighting conditions, while also providing
legendary durability and reliability.
Bindon Aiming Concept (BAC) features both eyes open shooting
for improved situational awareness
Battery free tritium/fiber optic illumination provides brilliant aiming point
in any lighting, LED versions also available
BDC reticles available in most magnifications along with target-ranging
reference points
Ruggedized forged housing delivers combat proven durability and reliability
1
2
3
4
Fixed magnifications available from 1.5x to 6x
5
The Science of Brilliant®
At Trijicon, we are bound by a commitment to industry-leading research, design, and testing to seek innovative aiming
solutions that constantly redefine “brilliant.” That’s why every Trijicon riflescope design is tested to the procedures below.
To learn more about Trijicon and The Science of Brilliant, visit Trijicon.com/Science
Alaska-to-Africa Temperature Tested
To ensure each family of riflescopes is ready for whatever our users put them
through, we perform an “Alaska-to-Africa” temperature shock test with temps from
-20°F to 140°F.
Solid Zero Tested
Our riflescopes are designed to hold their zero giving you the precision you need.
Every model is subjected to 5,000 consecutive rounds, confirming no reticle shift
has occurred.
Drop Tested
Because we don’t believe every drop should be followed by a warranty claim, we drop
test each riflescope design to check for durability.
Shock & Vibration Tested
All riflescope models are tested to withstand recoil and vibrational stresses without
malfunction, so it can take a beating before, during, and after use.
Immersion Tested
All models are immersion tested, and every riflescope is dry-nitrogen filled to eliminate
internal fogging.
Features and Benefits
A Always On, Always Ready
Most ACOG® models are battery-free, featuring a tritium/
fiber optic-illuminated reticle that atuomatically adjusts
the brightness based on available light.
B Outstanding Clarity
The quality of the glass and multi-coated lenses
maximizes light-gathering capabilities and clear field
of view with zero distortion.
C Rugged Aluminum-Alloy Housing
Fixed-power design allows for minimal moving parts
to create a nearly indestructible sighting system.
D Exact Target Distances & Holds
Most ACOG models feature a bullet dropcompensating and
target-ranging reticle for decisive aiming.
E Combat Proven
No other magnified optic has been used more in combat
than the ACOG.
F Shock-Resistant
Proven to withstand recoil from a .22LR to a .50BMG and
everything in between. Easily passes U.S. Military drop test
requirements.
1.5x16s
(TA44 Series)
1.5x24
(TA45 Series)
2x20
(TA47 Series)
3x24
(TA50 Series)
Magnification 1.5x 1.5x 2x 3x
Objective Lens 16mm 24mm 20mm 24mm
Eye Relief 2.4 in.
61.0mm
3.6 in.
91.4mm
2.1 in.
53.3mm
1.4 in.
35.6mm
Exit Pupil
0.42 in.
10.7mm
0.63 in.
16.0mm
0.39 in.
10.0mm
0.31 in.
8.0mm
Field of View
(in degrees) 7.4° 4.9° 5.6° 4.9°
Field of View 39.0 ft. @ 100 yds.
12.9m @ 100m
25.6 ft. @ 100 yds.
8.6m @ 100m
29.31 ft. @ 100 yds.
9.8m @ 100m
25.6 ft. @ 100 yds.
8.6m @100m
Adjustments
(PER IN. @ 100 YDS.) 2 clicks 2 clicks 2 clicks 2 clicks
Dimensions (L x W x H)
W/O MOUNT
4.0 x 1.6 x 2.1 in.
102 x 42 x 53mm
5.8 x 1.6 x 2.1 in.
147 x 42 x 53mm
5.3 x 1.6 x 2.1 in.
135 x 42 x 53mm
5.0 x 1.8 x 2.1
127 x 46 x 53mm
Weight
W/O MOUNT
5.1 oz.
144.5g
6.3 oz.
179.1g
6.4 oz.
180.6g
6.1 oz.
173.0g
Illumination Source Fiber Optics
& Tritium
Fiber Optics
& Tritium
Fiber Optics
& Tritium
Fiber Optics
& Tritium
Battery Life N/A N/A N/A N/A
Reticle Calibration N/A
N/A N/A
.223 / 7.62x39
G Waterproof
Exceptional waterproof performance. Dry nitrogen-
filled to eliminate fogging and tested to perform in both
extreme cold and heat.
H “Both Eyes Open” Design
Can be used as a CQB sight when shooting “both eyes
open” using the Bindon Aiming Concept.
3x30
(TA33 Series)
3.5x35
(TA11 Series)
3.5x35 LED
(TA110 Series)
4x32
(TA01 Series)
3x 3.5x 3.5x 4x
30mm 35mm 35mm 32mm
1.9 in.
48.3mm
2.4 in.
61.0mm
2.4 in.
61.0mm
1.5 in.
38.1mm
0.33 in.
8.4mm
0.39 in.
9.9mm
0.39 in.
10.0mm
0.32 in
8.1mm
3.7° 5.5° 5.5° 7.0°
19.3 ft. @ 100 yds.
6.5m @ 100m
28.8 ft. @ 100 yds.
9.6m @ 100m
28.8 ft. @ 100 yds.
9.6m @ 100m
36.6 ft. @ 100 yds.
12.2 @ 100m
4 clicks 3 clicks 2 clicks 2 clicks
6.1 x 1.6 x 2.1 in.
155 x 42 x 53mm
8.0 x 2.1 x 2.6 in.
203 x 53 x 66mm
8.0 x 2.1 x 2.6 in.
203 x 76 x 66mm
5.8 x 2.0 x 2.3 in.
147 x 51 x 58mm
7.8 oz.
221.1g
14.0 oz.
396.9g
16.8 oz.
476.3g
10.9 oz.
309.0g
Fiber Optics
& Tritium
Fiber Optics
& Tritium
LED Powered
by a AA Battery Tritium Only
N/A N/A N/A12,000+ hours*
.223 / .308 /
7.62x39 / 300 BLK
.223 / .308 /
M193 / 300 BLK .223 / .308 .223 / .308
D
H
C
B
E
F
G
A
