Technaxx® * User Manual
Power Bank 6000mAh with FullHD Camera TX-92
The Declaration of Conformity you nd here: www.technaxx.de/ (in bar at the bottom
“ ”Konformitätserklärung ). Before using the device the rst time, read the user manual
carefully.
This device has a rechargeable battery. It must be fully charged before rst use.
NOTE: Charge the battery of the device every 2–3 month if it is not used!
Service phone No. for technical support: 01805 012643 (14 cent/minute from German
xed-line and 42 cent/minute from mobile networks).
Free Email: support@technaxx.de
Keep this user manual for future reference or product sharing carefully. Do the same with
the original accessories for this product. In case of warranty, please contact the dealer or
the store where you bought this product. * Warranty 2 years
Features
Charging the most mobile devices (e.g. Smartphone, tablet PC, eBook reader, etc.)
 Rechargeable portable 6000mAh lithium ion battery (type 18650) 3.7V/22.2Wh FullHD
video recording with 1/4" CMOS camera sensor 2MP & sound USB output 5V/1.5A for
charging external digital devices MicroSD(HC) card slot up to 32GB Infrared night  
vision up to 2m Backup power on the go, ideal for travelling Built-in protection against  
overcurrent, short circuit, overload, overcharge, overvoltage Charging status is shown
by 4 LEDs Easy handling via remote control
Technical specications Power Bank
Built-in rechargeable 6000mAh lithium ion battery
Battery type 18650 3.7V 22.2Wh
Power supply input (Micro USB) DC 5V/1A power adapter** (**not included)
Power supply output (USB) DC 5V/1.5A
Charging time ~7–9 hours without simultaneous recording
~15 hours with simultaneous recording
Connections
1x Micro USB 5V/2A (for power bank charging)
1x USB 5V/1.5A (for charging external device)
1x MicroSD(HC) card slot (max. 32GB)
Only video DC 3.7V/160mA
Power consumption Only IR DC 3.7V/100mA
Sound recording Built-in non-visible microphone
Operating systems Windows 7 / 8 / 8.1 / 10 / MacOS
Working temperature –5°C up to +50°C
Weight / Dimensions 187g / (L) 13.8 x (W) 6.2 x (H) 2.1cm
Technical specications Video Camera
Camera sensor 1/4” CMOS, 2MP, 1280x720
Viewing angle 60° horizontal
Video resolution 1920x1080 AVI format @ 30fps
Photo resolution No photo function
IR night vision ~ 2m
Continuous recording time ~28 hours (only video function without IR)
External storage MicroSD(HC) cards up to 32GB (up to Class 6)
[has no internal storage]
Package Contents:
Power Bank 6000mAh with FullHD camera TX-92, Micro USB to USB
charging cable, Remote Control with button cell battery (CR2032), User Manual
Produkt Overview
L1 3 LED charging status Camera
L2 Battery status
L3 LED for Infrared (ashing ON) 4 USB Slot
(for charging other devices)
L4 K1 LED for Infrared (ashing OFF) Video recording (ON/OFF)
1 K2 MicroSD Card slot Reset
2 5 4x Infrared LEDs Micro USB Charging slot
Charge the Power Bank fully before use (~ 7–9 hours)
Connect the Micro USB port of the charging
cable* (*included) to the Power Bank. Then connect
the USB port of the charging cable to the USB port
of a AC adapter** (**not included) or to a
PC/Notebook (see right picture).
During charging the RED LED is blinking.
The number of lighting of the RED LEDs is
depending on the amount of power in the power
bank.
When only one LED is lighting that means the
Power Bank is almost empty, 4 LED lighting means
the Power Bank is almost full of power.
Charging: Use a 5V/1A adapter** (**not included) to
charge the Power Bank. During charging the Blue
LED L1&L2 steady on, RED light blinking. When
fully charged the RED L1&L2&L3&L4 are steady on.
Capacity Charging time of the
Power Bank iPhone 5 Sony Z1, Z2 Galaxy
Note3
Galaxy
S4, S5
6000mAh approx. 7–9 hours 2.5 times 1.2 time 1.2 times
1.4 time
Functions of remote control
Long press , will flash for 3 times and then A L1&L2
turn o, recording begins; press long to save the B
videos and to switch off – all LEDs are lighting shortly
and then go o.
On standby mode, press , will ash for 3 C L1&L2
times, and then turn off, recording begins; press to C
save the videos, turn on, the Power Bank goes L1&L2
to standby mode.
can be turned on/off manually only while IR light
recording. While recording, press , will flash for 3 D L3
times, and then turn o – IR lights turn on; Press D
again, will flash for 3 times, and then turn o. The L4
IR light turns o and is switched o.
Attention: When you have a problem with the remote
control, press to reset.K2
A: Turn on / Video recording
B: Save videos / Turn o
C: Steady on/ Video recording
D: IR light on / o
