TLM-A068-EN-C/T-2310-01
17-50mm F/4
Di
III
VXD
Model:
A068
Owner’s manual
5
1
4
7
11
8
10
9
Sony
1312
6
11
12
2
3
Zooming
Focusing
For Sony E
* The Marking is a directive conformity mark of the European Community (EC).
* Das -Zeichen entspricht der EC Norm.
* La marquage est un marquage de conformité à la direcive CEE (CE).
* La marca es marca de conformidad segun directiva de la Comunidad Europea (CE).
* Il marchio attesta la conformita alla directtiva della Comunità Europea (CEE).
* 标志表示符合欧州共同体 (EC) 指标
The EEC Conformity Report applies to the Council
Directive 2014/30/EU, 2011/65/EU and is used
by Tamron Co., Ltd., manufacturer of this product.
25
3
5
Thank you for purchasing this Tamron lens. Before using your new lens, please read the contents of this Owner’s manual to properly
use the lens. Also, it will be important to read the manual of the camera to which you will attach the lens.
After reading, store this Owner’s manual in a safe place.
Please read also the document “Precautions for Safe Use of Tamron Lenses” supplied with the lens for the detailed safety precautions
to observe when using Tamron lenses.
• Explains precautions that help to prevent problems.
• Explains things you should know in addition to basic operations.
PART NAMES (Refer to Fig. )1
① ② Lens hood Hood attaching alignment mark
③ ④ Hood locking mark Filter ring
⑤ ⑥ Hood release mark Focus ring
⑦ ⑧ Focal length scale Focal length mark
⑨ ⑩ Focus set button Zoom ring
⑪ ⑫ Connector port Lens attachment mark
⑬ Lens-camera interface contacts
MAIN SPECIFICATIONS
Model A068
Focal Length 17 - 50 mm
Maximum Aperture F/4
Angle of View (diagonal) 103°41' - 46°48'
Optical Construction 13/15
Minimum Object Distance (MOD) 0.19 m (7.5") (Wide) / 0.3 m (11.8") (Tele)
Maximum Magnification Ratio 1:4.6 (Wide MOD) / 1:3.8 (Tele MOD)
Filter Size ø 67 mm
Length 114.4 mm (4.5")
Maximum Diameter ø 74.8 mm
Weight 460 g (16.2 oz)
Lens Hood HA062
Connector Type USB Type-C
• Length : From front end of the lens to mount surface.
• Specifications, appearance, functionality, etc., are subject to change without prior notice.
ATTACHING AND REMOVING THE LENS
Remove the rear cap of the lens. Align the lens attachment mark and mounting mark on the camera, and then insert the lens.⑫
Turn the lens clockwise until it locks.
To remove the lens, turn the lens in the opposite direction while pressing the lens release button on the camera.
• Turn off the power of the camera before attaching or removing the lens.
• For details, please read the instruction manual of your camera.
SWITCHING FOCUS MODE
Select the desired focus mode on the camera.
For manual focusing, turn the focus ring to acquire the desired focus.⑥
For details, please read the instruction manual of your camera.
• Under AF mode, there may be difficulty for autofocus to work depending on the subject.
FOCUS SET BUTTON (Ref. Fig. )1
Press the focus set button to use the function that has been assigned from the camera.⑨
See the manual of the camera for more details.
CONNECTOR PORT (Ref. Fig. )1
Lenses with the connector port can be connected to a computer using the TAMRON connection cable (sold separately). Then, using ⑪
the dedicated “TAMRON Lens Utility
TM
” application, you will be able to update the firmware and register functions to the focus set
button .⑨
See the online help of “TAMRON Lens Utility” using the link below for more details.
https://www.tamron.com/jp/consumer/support/help/lensutility/en/
• Do not use the TAMRON connection cable (sold separately) for any purpose other than connecting the TAMRON lens equipped
with a connector port to a computer.
• Tamron will not bear any responsibility for any loss or damage of data in use of the TAMRON connection cable (sold separately).
ZOOMING (Ref. Fig. )1
Turn the zoom ring to adjust the focal length (Zoom position) to a desired position.⑩
ENGLISH
