S -2 0C41
LE Pan htD el Lig
Ver:B.2
Tel:+86-25-85805753
F 6ax:+86-25-8580529
htt www it.ccp:// .sw
E-m il: t@ wia contac s t.cc
USER MANUAL
S E c t r Co. , LT D.W I T l e o n i c s
Congratulations on purchase f th s product. Pleas read this user manual carefully. your o i e
Feature Appearance
Usage
Packing List
Specifications
Caution
Clean
1. 240pcs of ultra bright LEDs, 50,000hrs long life time;
2. Delicate in appearance, sm lla in size, light weight and portable;
3. He -free technology and constant current circuit design at
ensure consiste , stable, and accu te light output in various nt ra
environments;
4. 10% to 100% PWM digital integ ted dimming, and the ra
5. LCD screen displays color temperature, brightness, and power
information;
6. It adopts LED side-emitting technology; the output light is
7. 3200K-5600K continuously adjustable;
8. It c u d fan be se or indoor and outdo dor vi eo an phod tography ;
portrait photography; wedding photography; and especially
suitable for children photography.
Model
LED
Luminance
Beam angle
Color temperature
CRI
Power
Working voltage
Dimension
Weight
Standard
a essoriescc
S-2410C
240PCS of ultra bright LEDs
1065 Lux @ 1m
75°
5600K±300K 3200K±200K~
96
60W
DC12V — 17V
Ф520x50mm
2.85kg
Power Adaptor( )15V 90W ,
Power cable, Carrying case
1. Under normal circumstances, there is no need to change the
LED, pls do not disassemble the light randomly.
2. Never solder the LED bulbs by non-professionals
3. Pls remove the battery if long time no use.
4. Only use the provided adapter to avoid damage.
5. Never expose to rain or moisture.
6. Pls keep the front panel clean.
7. Only use the light in the temperature range of -10 ~40 ℃ ℃.
1. Please clean the front LED panel with soft dry cloth. If using
soft cloth with slight clean neutral detergent solution, please
wipe again with a soft dry cloth.
2. Do not use wet cloth, anhydrous alcohol, gasoline, or a
mixture of anhydrous alcohol and ether etc. to wipe the front
aLED p ne , l o rwthe ise it may c use da amage to the fron a l.t LED p ne
Fig 1 Fig 2
â‘  Front Panel V-mount battery plateâ‘¡
â‘¢ â‘£ Battery release button CT dimming knob
⑤ DC in: 5.5x2.1mm, Polarity:
â‘¥ Brightness dimming knob
⑦ LCD screen Handle⑧
1. Install the light on the tripod or bracket, and tighten the
retaining bolt. Loose the rotary knob on both sides of the
2. Ins allt one V nt-mou battery or two Sony F-m nt atterou DV b ies
or plug in the provided power adaptor to DC input socket,
then press the power button to work.
(Note: The above mentioned three kinds of power-supply
modes are in parallel connection, please avoid using both or
all of them at the same time to avoid malfunction like
battery protection.)
3. Adjust the brightness from 10% to 100% and the color
tempe ture from 3200K to 5600K according to actual ra
requirements.
4. The LCD screen displays the battery remaining capacity on
the right side, details are as below:
Four LEDs
Three LEDs
Two LEDs
One LED
No display
75%-100%
50%-75%
25%-50%
10%-25%
<10%
Lack of power
Item
S-2410C
Power Adaptor
Power cable
Carrying case
Warranty card
User manual
Quantity
x1
x1
x1
x1
x1
x1
