M3600 Series Instruction Manual
WWW.MOTIC.COM
2
Motic Swiftline 3600 Series
Stage Clips
Camera Port
H ead
A rm
Cord Holder
Coarse Focus
Knob
Fine Focus
Knob
Mechanical
Stage Control
Light Intensity
Control
Eyepiece
Nosepiece
Objective
Specimen
Holder
Stage
Iris Diaphragm
Illuminator
On / O Switch
3
Microscope Components
ARM - the vertical column (attached to the base) which supports the
stage and contains the coarse and fine adjusting knobs and focusing
mechanism.
BASE - the housing and platform of the instrument to which the arm is
attached. The base stands on rubber feet and contains the illuminator
assembly. The bulb replacement part number is printed on the
underside of the base.
COARSE FOCUS CONTROL - the larger focus control knob located on
either side of the microscope which facilitates rapid and heavy
movement of the focusing mechanism.
COAXIAL CONTROLS - the focusing mechanism moves the stage up and
down to bring the specimen into focus. The coaxial focusing system
combines both the coarse and fine focus into one knob located on both
sides of the microscope. The control is designed for a continuous
operation over the range of the stage movement.
CONDENSER –the condenser is mounted in the stage and it is used in
conjunction with the iris diaphragm. The function of the condenser is to
provide full illumination to the specimen plane and to enhance the
resolution and contrast of the object being viewed. The condenser can
be raised and lowered for precise light control.
CORD HOLD (Corded models only)ER - the bracket installed on the back
of the arm which is used to wrap and store the electrical cord.
EYEPIECES - the upper optical element that further magnifies the
primary image of the specimen and brings the light rays in focus at the
eye point.
FINE FOCUS CONTROL - the fine focusing knobs, located on either side
of the microscope, on the sides of the coaxial focusing control. They are
used for precise focusing adjustments once the specimen has been
brought into view with the coarse focus controls.
HEAD - the top portion of the microscope that contains the refracting
prisms and the eyepiece tube. The eyepiece is locked onto the eyepiece
tube with a set screw
CAMERA PORT - the top portion of the microscope is equipped with an
optional camera port. This port allows the end user to attach a digital
camera (such as a Moticam), with the purchase of the optional C-Mount
camera lens (MA15604). Ask your microscope dealer for details. To
remove the cap, a 1.5mm hex wrench is will be required (not
provided).
