INSTALLATION OF STI-9730 WIRE GUARD DAMAGE STOPPER®
All specifications and information shown were current as of publication and are subject to change without notice.
9730 OCT2010
Safety Technology International, Inc.
2306 Airport R terford, Michigan 48327-1209oad • Wa
Phone: 248-673-9898 • Fax: 248-673-1246
Toll Free: 800-888-4784 • E-mail: info@sti-usa.com
Web: www.sti-usa.com
Safety Technology International (Europe) d.Lt
Unit 49G Pipers Road • Park Farm Industrial Estate • Redditch
Worcestershire • B98 0HU • England • Tel: 44 (0) 1527 520 999
Fax: 44 (0) 1527 501 999 • Freephone: 0800 085 1678 (UK only)
E-mail: info@sti-europe.com • Web: www.sti-europe.com
INSTALLATION INSTRUCTIONS
1. Center and place wire guard over device or product to be protected
and mark all 6 hole locations with pencil or marker.
2. Drill all 6 holes using 1/4” diameter drill 1-1/2” deep.
3. Insert anchors into drilled holes.
4. Place wire guard in position, insert screws and tighten.
MARK AND DRILL
1/4 DIA. HOLE
(6) PLACES
19033 #10 ANCHOR
(6) PROVIDED
19013
#10 x 1-1/2 in. SCREW
(6) PROVIDED
STI-9730
WIRE GUARD
12.41 in.
(315mm)
12.17 in.
(309mm)
14.47 in.
(367mm)
16.25 in.
(413mm)
16.57 in.
(421mm)
EXTERNAL DIMENSIONS
INTERNAL DIMENSIONS
Electronic warranty form at www.sti-usa.com/wc14
SMOKE DETECTOR COVERS
STI-9601 Low profile - Flush mount
STI-9601-SS Low profile - Flush mount -
Stainless Steel
STI-9602 Low profile - Surface mount
STI-9604 Mini - Flush mount
STI-9604-SS Mini - Flush mount -Stainless
Steel
STI-9605 Mini - Surface mount
STI-9605-SS Mini - Surface mount -
Stainless Steel
STI-9609 High profile - Flush mount
STI-9609-SS High profile - Flush mount -
Stainless Steel
STI-9610 High profile - Surface mount
STI-9712 Photoelectric - Surface mount
STI-9713 Photoelectric - Flush mount
BEAM SMOKE DETECTORS
STI-9623 For DS240 and DS241
STI-9624 For Fireray 50/100R
STI-9625 For System Sensor Beam
Smoke Detector 6424
STI-9706 Flush Mount
STI-9707 Surface Mount
PIR GUARDS
STI-9618 Corner Mount
STI-9619 Corner Mount
STI-9620 6.25 x 4 x 2.25”
STI-9621 7 x 5.75 x 4.50”
STI-9622 8.75 x 4 x 3.75”
CLOCK/BELL WIRE CAGES
STI-9631 10.5” Diameter
STI-9631-SS 10.5” Diameter – Stainless Steel
STI-9631-R 10.5” Diameter – Red
STI-9632 16.5 Diameter
STI-9632-SS 16.5 Diameter – Stainless Steel
STI-9633 20” Diameter
EXIT SIGN WIRE CAGES
STI-9640 10.5 x 13.75 x 2.75”
STI-9740 15.5 x 20.5 x 6”
BAY LIGHT WIRE CAGES
STI-9702 For Hubbell®Superbay Lights –
21.43 x 22.50”
STI-9709 For Hubbell®Superbay Lights – 24.5
x 26”
MISCELLANEOUS WIRE CAGES
STI-9601
STI-9625
STI-9796
STI-9632
STI-9640
STI-9702
STI-9649
STI-9705
STI-9624
STI-9618
STI-9651 Fluorescent Light Damage Stopper®
STI-9705 Horn/Strobe/Speaker Damage Stopper®– Flush
STI-9708 Horn/Strobe/Speaker Damage Stopper – Surface
STI-9711 Horn/Strobe/Speaker Damage Stopper – Flush
STI-9714 Horn/Strobe/Speaker Damage Stopper – Surface
STI-9716 Camera Damage Stopper®
STI-9717 Speaker/Strobe Damage Stopper®– Flush
STI-9720 Speaker Strobe Damage Stopper®– Surface
STI-9730 Wire Guard Damager Stopper®
STI-9796 Outdoor Light Damage Stopper®
STI-9880 Fluorescent Lighting Damage Stopper®– Small
STI-9881 Fluorescent Lighting Damage Stopper®– Large
JUNE2014
ADDITIONAL WIRE GUARDS AVAILABLE
Visit for complete detailswww.sti-usa.com
STI • Waterford • MI • 800-888-4784
STI-9880
EMERGENCY LIGHT CAGES
STI-9641 10.7 x 14.6 x 4”
STI-9644 8.7 x 17.7 x 5”
STI-9645 13.8 x 21.7 x 5.9”
STI-9649 10.75 x 24.75 x 11.25”
STI-9703 5 x 13.5 x 4”
BEACON & SOUNDER CAGES
STI-9614 7.9 x 6”
STI-9615 3.7 x 3.5”
STI-9617 5.9 x 4.9”
STI-9664 3.86 x 6.18”
STI-9665 7 x 8.43”
STI-9604-SS
STI-9621
STI-9615 STI-9664
