Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: December 2, 2019
Product Diagram (DKT30CHVAUSP)
Side View
Rear View
Port Function
1VGA Output Port âą Connect a VGA Display Device
2RJ45 Port âą Connect a Network Cable
3USB-C Port
âą Connect a (e.g. îash drive), USB-C Storage Device
or USB-C Peripheral Device
âą Connect the for Host Computerâs Power Adapter
Power Delivery passthrough
4SD Card Slot âą Connect an SD Card
5USB-A Ports âą Connect a USB-A Peripheral Device
âą Charge a USB-A Peripheral
6HDMI Output Port âą Connect an HDMI Display Device
7USB-C Host Connector âą Connect to a or Laptop Computer
83.5 mm Audio Port âą Connect an with a 4-position jack Audio Device
USB-Câą Multiport Adapter - 4K HDMI/VGA - SDâą - 2x USB-A/1x USB-C - 100W PD 3.0
Requirements
For the latest requirements and to view the full manual, please visit:
www.startech.com/DKT30CHVAUSP.
âą Host Computer with USB-C Port
Installation
Powering the Multiport Adapter
USB Power Delivery 3.0 - Bus Power:
The is powered by the and does not Multiport Adapter Host Computerâs USB-C Port
require a separate power adapter. For power delivery passthrough follow these steps.
1. Connect the to a on the using the Multiport Adapter USB-C Port Host Computer
USB-C Host Connector.
2. Connect the from the to the USB-C Connector Host Computerâs Power Adapter
USB-C Port Multiport Adapteron the .
3. The will power the and pass Host Computerâs Power Adapter Multiport Adapter
power through to the .Host Computer
Windows 7 Driver Installation
1. Connect the to a on the using the Multiport Adapter USB-C Port Host Computer
USB-C Host Connector. The pop-up will appear.Found New Hardware
2. On the pop-up, click the button.Found New Hardware Cancel
3. Using a web browser, navigate to the StarTech.com website:
www.startech.com/DKT30CHVAUSP.
4. On the screen, click the tab.Product Support
5. In the section, click on the driver link that corresponds with Drivers and Downloads
the operating system running on the .Host Computer
6. Once the download is complete, extract the contents of the .Zip île.
7. Click the appropriate driver for the version of operating system that you are running
and follow the on-screen prompts to complete the installation.
1
234
5
67
8
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment oî and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
âą Connect the equipment into an outlet on a circuit diîerent from that to which the receiver is connected.
âą Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modiîcations not expressly approved by StarTech.com could void
the userâs authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le prĂ©sent appareil est conforme aux CNR dâIndustrie Canada applicables aux appareils radio exempts de licence. Lâexploitation
est autorisée aux deux conditions suivantes:
(1) lâappareil ne doit pas produire de brouillage, et (2) lâutilisateur de lâappareil doit accepter tout brouillage radioĂ©lectrique subi,
mĂȘme si le brouillage est susceptible dâen compromettre le fonctionnement.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
PHILLIPSÂź is a registered trademark of Phillips Screw Company in the United States or other countries.
Warranty Information
This product is backed by a three-year warranty.
For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their oîcers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of proîts, loss of
business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
Safety Measures
âą If product has an exposed circuit board, do not touch the product under power.
Mesures de sécurité
âą Si lâun des circuits imprimĂ©s du produit est visible, ne pas touchez le produit lorsquâil est sous tension.
ćźć
šćŻŸç
âąî èŁœćă«éČćșăăç¶æ
ăźćè·Żćșç€ăć«ăŸăăć Žćăé»æșăć
„ăŁăŠăăç¶æ
ă§èŁœćă«è§ŠăăȘăă§ăă ăăă
Misure di sicurezza
âą Se il prodotto p2-ha un circuito stampato visibile, non toccare il prodotto quando Ăš acceso.
SÀkerhetsÄtgÀrder
⹠Rör aldrig vid enheter med oskyddade kretskort nÀr strömmen Àr pÄslagen.
FR: fr.startech.com
DE: de.startech.com
ES: es.startech.com
NL: nl.startech.com
IT: it.startech.com
JP: jp.startech.com
StarTech.com Ltd.
45 Artisans Cres
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Rd,
Brackmills
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
2500 Creekside
Parkwy
Lockbourne, Ohio
43137
U.S.A.
Connect an Audio Device
âą Connect a to the on the and 3.5mm Cable 3.5 mm Audio Port Multiport Adapter
to an . Audio Device
Operation
RJ45 Port LED Indicators
LED Color Status Indication
Green Solid âą Link speed is either 1000Mbps (1 GbE), 100Mbps, or
10Mbps
Oî âą No connection established
Amber Flashing âą Link established
Oî âą No link established
Connecting a Display
âą Connect an to the on the HDMI M/M Cable HDMI Output Port Multiport Adapter
and to the on the .HDMI Input Port HDMI Display Device
- or -
âą Connect a to the on the and VGA M/M Cable VGA Output Port Multiport Adapter
to the on the .VGA Input Port VGA Display Device
Connect to a Network
âą Connect a to the on the and to the Network Cable RJ45 Port Multiport Adapter
Network Device.
Connect USB Peripherals
âą Connect a to the on the .USB-C Peripheral USB-C Port Multiport Adapter
- and/or -
âą Connect to the on the .USB-A Peripherals USB-A Ports Multiport Adapter
Connect an SD Card
1. Insert an label side up into the on the .SD Card SD Card Slot Multiport Adapter
Note: The will automatically detect and Host Computerâs Operating System (OS)
install the required driver software.
2. Using the , navigate to the location (e.g. root Host Computerâs OS SD Cardâs
directory).
3. Access the data on the inserted in step 1.SD Card
