Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: September 30, 2022 11:13 AM
Product Diagram (Side A)
(Side B)
(Side C)
(Side D)
Requirements
For the latest requirements, please visit www.StarTech.com/DKM31C3HVCPD
Product ID
DKM31C3HVCPD
USB-C 10Gbps Docking Triple Monitor Mini Station with HDMI & VGA â DP Alt Mode Pass Through - 25cm Wrap Around Cable
1
2
Component Function
1Built-in USB-C Host Cable
âą Connect to a USB-C Port on a Host Laptop
âą USB 3.2 Gen 2 (10Gbps)
âą Power Delivery 3.0 Speciîcation
2VGA Video Port
âą Connect a VGA Display Device
âą Up to 1080p (1920x1200/1920x1080) 60Hz
âą Via DisplayPort 1.4 DP Alt Mode
3HDMI Video Port
âą Connect an HDMI Display Device
âą HDMI 2.0b HDR10
âą Up to 4K (4096x2160) 60Hz
âą Via DisplayPort 1.4 DP Alt Mode
4USB-C Data/Charge/DP++
Video Port
âą Connect and/or charge a USB-C peripheral
âą Connect a USB-C display directly, or for any other
Display, a USB-C Video Adapter is required
âą USB 3.2 Gen 2 (10Gbps)
âą Supports 5V/2A (10W) charging
âą Display output via DisplayPort 1.4 DP Alt Mode
âą USB-C Power Adapter required for charging
52x USB-A DataPorts âą Connect and/or charge USB-A peripherals
âą USB 3.2 Gen 2 (10Gbps)
6USB-C 100W Power
Delivery Input Port
âą Connect a USB-C power adapter
âą USB Power Delivery 3.0
7Gb Ethernet Port
âą Connect a CAT 5e/CAT 6 cable to establish a
network connection
âą 10/100/1000Mbps
34
5
5
6
7
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
PHILLIPSÂź is a registered trademark of Phillips Screw Company in the United States or other countries.
Warranty Information
This product is backed by a 3-year warranty.
For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their oîcers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of proîts, loss of
business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
FR: startech.com/fr
DE: startech.com/de
ES: startech.com/es
NL: startech.com/nl
IT: startech.com/it
JP: startech.com/jp
StarTech.com
Ltd.
45 Artisans Cres
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Rd,
Brackmills
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
4490 South Hamilton
Road
Groveport, Ohio
43125
U.S.A.
StarTech.com Ltd.
Siriusdreef 17-27
2132 WT Hoofddorp
The Netherlands
Regulatory Compliance
FCC - Part 15
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment oî and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
âą Connect the equipment into an outlet on a circuit diîerent from that to which the receiver is connected.
âą Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modiîcations not expressly approved by StarTech.com could void
the userâs authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le prĂ©sent appareil est conforme aux CNR dâIndustrie Canada applicables aux appareils radio exempts de licence. Lâexploitation
est autorisée aux deux conditions suivantes:
(1) lâappareil ne doit pas produire de brouillage, et (2) lâutilisateur de lâappareil doit accepter tout brouillage radioĂ©lectrique subi,
mĂȘme si le brouillage est susceptible dâen compromettre le fonctionnement.
Installation
Side A Ports
1. Connect the on the Multiport Adapter to a USB-C Built-in USB-C Host Cable
port on your host laptop. Your computer will automatically detect the device and
install all the required drivers.
2. Connect a VGA cable from your VGA enabled display device to the VGA Output
Port on the Multiport Adapter, to add a VGA display to your workstation.
3. Connect an HDMI cable from your HDMI enabled display device, to the
HDMI Output Port on the Multiport Adapter, to add an HDMI display to your
workstation.
4. To connect a display: If using display with USB-C input, connect a USB-C cable
from your display to the Multiport Adapter . For USB-C DP++ Video Port on the
other displays, connect a USB-C Video Adapter (HDMI, DisplayPort or VGA, sold
separately) from the Multiport Adapter to your USB-C DP++ Video Port on the
display device.
To connect and/or charge a USB-C peripheral device: Connect a USB-C
cable from your USB peripheral device to the on the USB-C Data/Charge Port
Multiport Adapter.
Notes:
âą A video cable may also be required to connect your display, depending upon
your USB-C video adapter.
âą Your computerâs USB-C port must support DP Alt Mode in order to output
video.
âą Video performance, such as resolution, refresh rate depends upon your
host computerâs video controller. Please verify the speciîcations of your
computer.
âą A USB-C power adapter must be connected to the USB-C 100W Power
Delivery Input Port on the Multiport Adapter, in order to charge connected
peripheral devices with up to 5V/2A (10W).
âą Without a power adapter connected, the USB port will output whatever bus
power is available, up to 4.5W.
Installation Contâd
Side B Port
5. Connect USB-A cables from your USB peripheral devices to the USB-A Data Ports
on the Multiport Adapter, to connect the devices to your computer.
Notes:
âą One of the is located on Side C. USB-A Data Ports
âą The USB port will output whatever bus power is available, up to 4.5W.
Side C Port
6. Connect a USB-C power adapter (up to 100W) from an AC outlet to the USB-C
100W Power Delivery Input Port on the Multiport Adapter, to charge the laptop
thatâs connected to the . Built-in USB-C Host Cable
Side D Port
7. Connect a CAT 5e/CAT 6 cable from your local area network (e.g. Router, Switch,
Modem, etc.) to the Gb Ethernet Port on the Multiport Adapter, to access your
network via a wired LAN connection.
