Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: February 18, 2021
Product Diagram (DK31C2DHSPD and DK31C2DHSPDUE)
Front View
Port Speciîcations and Installation
1Power LED Indicator âą Solid White LED Docking Stationindicates the is
receiving power and is powered ON
23.5mm Audio Port âą Connect an Audio Device
âą 4 Position Audio Jack Headset for use
3USB-C Charging Port
âą SuperSpeed USB 10Gbps (USB 3.2 Gen 2)
âą Supports charging of up to 5V/3A
âą Connect the to aDocking Station SuperSpeed USB
10Gbps Peripheral Storage Device or (e.g. îash
drive), using a SuperSpeed USB-C 10Gbps (USB 3.2
Gen 2) Cable
4USB-C Charging Port
âą SuperSpeed USB 10Gbps (USB 3.2 Gen 2)
âą USB Power Deliver (PD) 3.0
âą Supports charging of up to 5V/3A
âą Connect the to aDocking Station SuperSpeed USB
10Gbps Peripheral Storage Device or (e.g. îash
drive), using a SuperSpeed USB-C 10Gbps (USB 3.2
Gen 2) Cable
5SD Card Slot
âą Secure Digital (SD) 4.0 UHS-II, SD 3.0, 2.0, 1.1, and 1.0
compatibility
âą Push an , label side up, into the SD Card SD Card Slot
until it clicks into place
Note: The Host Computerâs Operating System (OS)
will automatically detect the SD Card and install the
required driver software.
âą Push then pull the to remove SD Card
USB-Câą 10Gbps Gen 2 Triple Monitor Docking Station - 2x DP + HDMI - 100W PD - DP 1.4 MST
Left Side View
Port Speciîcations and Installation
6Power Button
âą Powered by defaultON
âą Press and release the to power the Power Button OFF
Docking Station
Right Side View
Port Speciîcations and Installation
7Nano Lock Slot âą Secure the to a stationary objectDocking Station
8Lock Slot âą Secure the to a stationary objectDocking Station
Rear View
Port Speciîcations and Installation
9USB-A Device Ports
âą SuperSpeed USB 5Gbps (USB 3.2 Gen 1)
âą Connect the to twoDocking Station SuperSpeed
USB 5Gbps Peripherals Storage Devices or (e.g. îash
drives), using SuperSpeed USB 5Gbps (USB 3.2
Gen 1) Cables
10 USB-A Device Ports
âą USB 2.0
âą Minimum 2.5W (5V/0.5A) power output
âą Connect the to twoDocking Station USB-A
Peripherals Storage Devices and/or (e.g. îash drives),
using USB Cables
2 3 4
15
6
7 8
913 15
14
10 11 12
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment oî and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
âą Connect the equipment into an outlet on a circuit diîerent from that to which the receiver is connected.
âą Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modiîcations not expressly approved by StarTech.com could void
the userâs authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le prĂ©sent appareil est conforme aux CNR dâIndustrie Canada applicables aux appareils radio exempts de licence. Lâexploitation
est autorisée aux deux conditions suivantes:
(1) lâappareil ne doit pas produire de brouillage, et (2) lâutilisateur de lâappareil doit accepter tout brouillage radioĂ©lectrique subi,
mĂȘme si le brouillage est susceptible dâen compromettre le fonctionnement.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
Warranty Information
This product is backed by a three-year warranty.
For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their oîcers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of proîts, loss of
business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
Safety Measures
âą If product has an exposed circuit board, do not touch the product under power.
Mesures de sécurité
âą Si lâun des circuits imprimĂ©s du produit est visible, ne pas touchez le produit lorsquâil est sous tension.
ćźć
šćŻŸç
âąî èŁœćă«éČćșăăç¶æ
ăźćè·Żćșç€ăć«ăŸăăć Žćăé»æșăć
„ăŁăŠăăç¶æ
ă§èŁœćă«è§ŠăăȘăă§ăă ăăă
Misure di sicurezza
âą Se il prodotto p2-ha un circuito stampato visibile, non toccare il prodotto quando Ăš acceso.
SÀkerhetsÄtgÀrder
⹠Rör aldrig vid enheter med oskyddade kretskort nÀr strömmen Àr pÄslagen.
FR: startech.com/fr
DE: startech.com/de
ES: startech.com/es
NL: startech.com/nl
IT: startech.com/it
JP: startech.com/jp
StarTech.com Ltd.
45 Artisans Crescent
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Road
Brackmills,
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
4490 South Hamilton
Road
Groveport, Ohio
43125
U.S.A.
StarTech.com Ltd.
Siriusdreef 17-27
2132 WT Hoofddorp
The Netherlands
Package Contents
âą USB-C Dock x 1
âą Power Cable (NA/JP & ANZ) x 2
âą USB-C Cable (1 m) x 1
âą Quick-Start Guide x 1
Requirements
For the latest requirements, please visit:
www.startech.com/DK31C2DHSPD www.startech.com/DK31C2DHSPDUE or
âą Host Computer
âą USB PD Support
âą USB-C Port
âą DP alt mode
Installation
Notes: Installation is automatic for all modern Operating Systems. If the drivers do
not auto-install, please visit to locate the latest www.startech.com/DK31C2DHSPD
drivers.
Operation
RJ45 Port LED Indicators
LED Color Status Indication
Green Solid âą Link speed is 1000Mbps
Amber Solid âą Link speed is 100Mbps
None Oî âą Link speed is 10Mbps
11 RJ45 Port
âą 10/100/1000 Mbps
âą Connect the to a , Docking Station Network Device
using a Network Cable
12 Video 1-2 DisplayPort
Ports
âą DP 1.4
âą HDCP 1.4 and HDCP 2.2
âą High Dynamic Range (HDR) support
âą DSC support
âą Video 1 (Left) and Video 2 (Right)
âą Connect the to two Docking Station DisplayPort
Enabled Display Devices DisplayPort Cables, using
13 Video 3 HDMI Port
âą HDMI 2.0a version
âą YCbCr 4:4:4, 4:2:2 and 4:2:0 chroma subsampling
âą HDCP 1.4 and HDCP 2.2 compliant
âą High Dynamic Range (HDR) support
âą Connect the to an Docking Station HDMI Enabled
Display Device HDMI Cable, using an
14 USB-C Host Port
âą USB 3.1 Gen 2
âą USB Power Delivery 3.0 (PD 3.0)
âą Capability of charging the up to 100WHost Computer
âą USB Power Delivery (PD) pass-through:
1. Connect the to a , Docking Station Power Source
using the Universal Power Adapter
2. Connect the to the , Docking Station Host Laptop
using a SuperSpeed USB-C 10Gbps (USB 3.2
Gen 1) Cable
15 DC 20V Port âą Connect the to a , Docking Station Power Source
using the Universal Power Adapter
