Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: August 28, 2019 8:48 AM
Product Diagram (DK30CHHPD/DK30CHHPDUK/
DK30CHHPDEU/DK30CHHPDAU)
Front
Component Function
1USB-A Port
âą Used to charge a connected .USB Device
âą Used to connect to the USB Devices Docking
Station (îash drive, etc.).
âą BC 1.2 Compliant.
âą 7.5W of power output.
âą Charges with or without a connection to the
Host Computer.
2USB-C Port
âą Used to charge a connected .USB Device
âą B.C. 1.2 compliant.
âą 7.5 W of power output.
âą Charges with or without a connection to the
Host Computer.
33.5 mm Audio Port âą Used to connect an to the Audio Device
Docking Station (headset, microphone, etc.).
4Mounting Holes (x 4)
âą Used to mount the to a desk Docking Station
or wall.
Note: Located on the bottom of the Docking
Station.
5Power Button âą Used to turn the On/Oî.Docking Station
6 Lock Slot
âą Used to secure the to a Docking Station
secure stationary object.
Note: Located on the side of the Docking
Station.
USB-C Dual Video 1080p Monitor, USB 3.1 Gen 1 Dock
Rear
Component Function
7Power Connector
âą Used to power the by Docking Station
connecting the to Universal Power Adapter
the .Docking Station
8USB-C Host Port
âą Used to connect the to the Host Computer
Docking Station.
âą Used to charge the connected .Host Computer
âą Power Delivery 3.0.
âą 60W of power output.
9HDMI Video 1 and 2
Ports (x 2)
âą Used to connect two to HDMI Display Devices
the .Docking Station
âą 1920x1200 @ 60 Hz.Maximum Resolution:
10 RJ-45 Port âą Used to connect a to the Network Device
Docking Station.
11 USB-A Ports (x 2) âą Used to connect to the USB Devices Docking
Station (mouse, keyboard, etc.).
Requirements
For the latest requirements, please visit www.startech.com/DK30CHHPD
Powering the Docking Station
1. Connect the to the on the Universal Power Adapter Power Connector Docking
Station.
2. Connect the to the and to an Power Cord Universal Power Adapter AC Electrical
Outlet.
12 3 4 5
6
78 9 10 11
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment oî and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
âą Reorient or relocate the receiving antenna.
âą Increase the separation between the equipment and receiver.
âą Connect the equipment into an outlet on a circuit diîerent from that to which the receiver is connected.
âą Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modiîcations not expressly approved by StarTech.com could void
the userâs authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le prĂ©sent appareil est conforme aux CNR dâIndustrie Canada applicables aux appareils radio exempts de licence. Lâexploitation
est autorisée aux deux conditions suivantes:
(1) lâappareil ne doit pas produire de brouillage, et (2) lâutilisateur de lâappareil doit accepter tout brouillage radioĂ©lectrique subi,
mĂȘme si le brouillage est susceptible dâen compromettre le fonctionnement.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
Warranty Information
This product is backed by a three-year warranty.
For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their oîcers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of proîts, loss of
business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
Safety Measures
âą If product has an exposed circuit board, do not touch the product under power.
Mesures de sécurité
âą Si lâun des circuits imprimĂ©s du produit est visible, ne pas touchez le produit lorsquâil est sous tension.
ćźć
šćŻŸç
âąî èŁœćă«éČćșăăç¶æ
ăźćè·Żćșç€ăć«ăŸăăć Žćăé»æșăć
„ăŁăŠăăç¶æ
ă§èŁœćă«è§ŠăăȘăă§ăă ăăă
Misure di sicurezza
âą Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando Ăš acceso.
SÀkerhetsÄtgÀrder
⹠Rör aldrig vid enheter med oskyddade kretskort nÀr strömmen Àr pÄslagen.
FR: startech.com/fr
DE: startech.com/de
ES: startech.com/es
NL: startech.com/nl
IT: startech.com/it
JP: startech.com/jp
StarTech.com Ltd.
45 Artisans Cres
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Rd,
Brackmills
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
2500 Creekside
Parkwy
Lockbourne, Ohio
43137
U.S.A.
1. Use a web browser to navigate to . www.startech.com/DK30CHHPD
2. On the page, click the tab located in the middle of the screen.Product Support
3. In the section, click on the driver link that corresponds with Drivers and Downloads
the operating system running on the host laptop.
4. Once the download is complete, extract the contents of the île.
5. Click the appropriate driver for the version of operating system that you are running
and follow the on-screen prompts to complete the installation.
Resolution Chart
Resolution Frequency Single or
Mirror Mode
Dual Screen
Extended
Full HD (1920 x1080, 1920x1200) 60 Hz Yes Yes
3. Press the on the to turn the On. Power Button Docking Station Docking Station
Connecting a Host Device
âą Connect a to the on the and the other end USB-C Cable USB-C Port Docking Station
to a USB-C port on the .Host Computer
Connecting Display Devices
1. Connect an (sold separately) to the on the HDMI Cable HDMI Video 1 Port Docking
Station Display Device and the other end to the HDMI port on the .
2. Repeat step 1 to connect a second .Display Device
Connecting a Network Device
âą Connect a to the on the and the other CAT 5e/6 Cable RJ-45 Port Docking Station
end to an RJ-45 port on a .Network Device
Connecting Peripheral Devices
1. (Optional) Connect a or other l (mouse, tablet, USB Storage Device USB Periphera
phone, etc.) to one of the on the .USB-A Ports Docking Station
2. (Optional) Connect a or other to the USB Storage Device USB Peripheral USB-C
Port Docking Station on the .
Driver Installation
Depending on your Host Laptopâs operating system, the required drivers will
automatically be installed when the Docking Station is connected and powered on. If
the drivers do not automatically install:
