Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: March 16, 2022 11:40 AM
Product Diagram
Product ID
127B-USBC-MULTIPORT
USB-C Multiport Adapter - 4K 60Hz HDMI HDR - 3 x USB 5Gbps - GbE - 100W PD
3
12
5
4
Component Function
1Built-in USB-C Host Cable
âą Connect to a USB-C Port on a Host Computer
âą USB 3.2 Gen 1 (5 Gbps)
âą Power Delivery 3.0 Speciîcation
2HDMI Output Port
âą Connect an HDMI Display Device
âą HDMI 2.0b HDR10
âą Up to 4K (4096x2160) 60 Hz
âą Via DisplayPort 1.4 DP Alt Mode
33x USB-A Data Ports âą Connect USB-A Peripherals
âą USB 3.2 Gen 1 (5 Gbps)
4USB-C 100W Power
Delivery Port
âą Connect a USB-C power adapter
âą USB Power Delivery 3.0 (up to 100W)
5Gigabit Ethernet Port
âą Connect a CAT 5e/CAT 6 cable to establish a
network connection
âą 10/100/1000 Mbps
Requirements
âą Computer
âą DP Alt Mode enabled USB-C Port
For the latest drivers, manuals, product information, technical speciîcations, and
declarations of conformance, please visit: www.StarTech.com/127B-USBC-MULTIPORT
Package Contents
âą USB-C Multiport Adapter x 1
âą Quick-Start Guide x 1
(Side A)
(Side B)
(Side C)
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
PHILLIPSÂź is a registered trademark of Phillips Screw Company in the United States or other countries.
Warranty Information
This product is backed by a 3-year warranty.
For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their oîcers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of proîts, loss of
business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
FR: startech.com/fr
DE: startech.com/de
ES: startech.com/es
NL: startech.com/nl
IT: startech.com/it
JP: startech.com/jp
StarTech.com
Ltd.
45 Artisans Cres
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Rd,
Brackmills
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
4490 South Hamilton
Road
Groveport, Ohio
43125
U.S.A.
StarTech.com Ltd.
Siriusdreef 17-27
2132 WT Hoofddorp
The Netherlands
Regulatory Compliance
FCC -- Part 15
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment oî and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
âą Connect the equipment into an outlet on a circuit diîerent from that to which the receiver is connected.
âą Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modiîcations not expressly approved by StarTech.com could void
the userâs authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le prĂ©sent appareil est conforme aux CNR dâIndustrie Canada applicables aux appareils radio exempts de licence. Lâexploitation
est autorisée aux deux conditions suivantes:
(1) lâappareil ne doit pas produire de brouillage, et (2) lâutilisateur de lâappareil doit accepter tout brouillage radioĂ©lectrique subi,
mĂȘme si le brouillage est susceptible dâen compromettre le fonctionnement.
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limit set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator and your body.
Installation
Side A Ports
1. Connect the , located on the Multiport Adapter, to a Built-in USB-C Host Cable
USB-C Port on your Host Computer. Your Host Computer will automatically detect
the Multiport Adapter and install the required drivers.
2. Connect an HDMI Enabled Display Device, to the , located on HDMI Output Port
the Multiport Adapter, using an HDMI cable.
Notes:
âą The Host Computerâs USB-C port must support DP Alt Mode in order to output
video.
âą Video performance, such as resolution, and refresh rate depends upon the
connected Host Computerâs video controller. Please verify the speciîcations of
the Host Computer.
3. Connect USB Peripheral Devices to the , located on the USB-A Data Ports
Multiport Adapter.
Note: USB-A Data Ports The will output whatever bus power is available, up
to 4.5 W.
Side B Port
4. Connect a USB-C Power Adapter (up to 100 W) from an AC outlet to the USB-C
100 W Power Delivery Port on the Multiport Adapter, to charge the Host
Computer thatâs connected to the .Built-in USB-C Host Cable
Note: The Multiport Adapter reserves 15 W of power, with up to 85 W
available for charging your Host Computer.
Side C Port
7. Connect an RJ-45 terminated network cable (CAT5e or better) from your Network
Device (e.g. Router, Switch, Modem, etc.) to the on the Gigabit Ethernet Port
Multiport Adapter, to access the network via a wired LAN connection.
