Polycom® KIRK® 70-Handset Series
The Ultimate Wireless Solution for Healthcare Personnel
Benefits
• Supported on Microsoft® LyncTM
Server 2010
• Improved reaction time to medical
emergencies via alarms in case of
heart attack, epileptic attack, and
other situations where lives are at
stak
• More time to patient care and faster
interaction between patient and
caregiver
• Resistance to disinfectants and easy
clean keypad membrane reduce
the risk of spreading bacteria and
diseases
• Protection against splashing water
enables caretakers to assist patients
in wet rooms without detaching the
handset
• Automatic alarms - if man down, no
movement, or running is detected -
increase personal safety
• Tear-off string and alarm button
increase security for personnel in
high risk environments
• Focused communication ensures the
correct person can take action right
away
Polycom offers a wireless solution that combines high demands for hygiene with
enhanced responsiveness and personal safety, and that is specially designed for
environments where mobility and communication are critical factors for saving lives.
The intuitive, ruggedized, and disinfectant resistant Polycom® KIRK® 70-Handset
Series is designed to enable healthcare personnel to be mobile while still within
quick reach in critical situations. Integrated with third-party applications, like nurse
call or equipment monitoring system, alarm icons and the integrated alarm button
ensure immediate reaction in emergency situations.
Special alarm icons for healthcare environments have been developed for the KIRK
70-Handset Series ensuring that messages and alarms are easy, fast, and intuitive
to understand. The high-quality TFT color display provides a clear view from all
angles, and the unique alarm color codes ensure that users easily can determine
the type of emergency – even if the phone is sitting in a belt clip.
The KIRK 70-Handset Series is designed to meet the high demands of hygiene by
healthcare personnel. To avoid the spread of bacteria, the handsets are disinfectant
resistant and can be cleaned with the disinfectants used in hospitals, which makes
them ideal for environments where hygiene and sterile equipment is of highest
importance.
Moreover, the KIRK 70-Handset Series is supported on Microsoft® LyncTM Server
2010. Use your KIRK 70-Handset to connect to Microsoft UC environments in a
KIRK Wireless Server 6000 Lync set-up.
KIRK 7010 Handset
The KIRK 7010 Handset is robust, dust protected, and resistant to splashing
water, vibrations, and shocks. The KIRK 7010 Handset is prepared for third-party
applications and has all the standard features needed within healthcare and at
nursing homes. The ruggedized application-enabled handset is recommended for
personnel in nursing homes and non-medical staff at hospitals.
KIRK 7020 Handset
The KIRK 7020 Handset is disinfectant-resistant with a membrane keypad for
easy cleaning to avoid the spread of bacteria. The IP64-compliant handset is dust
tight and protected against splashing water, which enables caretakers to help
patients in wet rooms without detaching the handset.
KIRK 7040 Handset
The KIRK 7040 Handset extends the capabilities of the KIRK 7020 Handset. The
Handset combines durability with high demands for hygiene and maximum security.
Personal safety is reinforced with automatic alarms detectors such as man down
and running as well as a tear-off string alarm. With the expanded safety features,
the KIRK 7040 Handset is ideal for personnel within psychiatrics where personal
safety might be at risk.
A POLYCOM DATA SHEET
Polycom® KIRK® 70-Handset Series Features
Polycom Worldwide Headquarters
4750 Willow Road, Pleasanton, CA 94588
1.800.POLYCOM or +1.925.924.6000
www.polycom.com
© 2012 Polycom, Inc. All rights reserved. POLYCOM®, the Polycom “Triangles” logo and the names and marks associated with Polycom’s products are trademarks and/or service marks of Polycom, Inc. and are registered
and/or common law marks in the United States and various other countries. All other trademarks are property of their respective owners. No portion hereof may be reproduced or transmitted in any form or by any means,
for any purpose other than the recipient’s personal use, without the express written permission of Polycom. 11/09/2012
Approvals
• EMC:
• EN 301 489-1
• EN 301 489-6
• Radio: EN 301 406
• Safety: EN 60950-1
Size and Weight
• KIRK 7010:
• Size: 148 x 50.4 x 21.6 mm. /
5.8 x 2.0 x 0.9 in.
• Weight: 120 gr. / 4.2 oz. incl. battery
• KIRK 7020:
• Size: 148 x 50.4 x 20 mm. /
5.8 x 2.0 x 0.8 in.
• Weight: 111 gr. / 3.9 oz. incl. battery
• KIRK 7040:
• Size: 148 x 50.4 x 20 mm. /
5.8 x 2.0 x 0.8 in.
• Weight: 115 gr. / 4.0 oz. incl. battery
Speech/Standby time
• KIRK 7010: up to 23/118 hours
• KIRK 7020: up to 23/118 hours
• KIRK 7040: up to 22/90 hours
• KIRK 7040: up to 11/50 hours (with
Bluetooth enabled)
• Charger w/wo USB 2.0 connection
• Battery: Li-ion battery
• Battery lifetime: Normal lifetime under
proper charge and discharge conditions:
1 year or 300 charging cycles
Operating Temperature
• Incl. charging: -10 - 55°C /
14°F - 131°F
IP Rating
According to EN60529:
• KIRK 7010: IP54 classified (dust
protected and water splash proof)
• KIRK 7020/7040: IP64 classified (dust
tight and water splash proof)
KIRK 7010/7020/7040
• TFT color display:
• 65,000 colors
• 8 lines of text/icons
• 128x160 pixels
• Date and time in display*
• 4-way navigation key
• 2 soft keys
• R-key for transfer and special services
• Key lock
• Auto key lock
• Volume control
• 10 different ringtones and adjustable
ring volume
• Internal/External ring pattern*
• Microphone mute
• Adjustable alert volume (low battery/low
coverage/incoming message)
• Silent mode (mutes all alerts/calls)
• Alerting on silent mode (display flash or
short ring)
• CLIP (40 caller-ID presentations)*
• Telephone book with 250 entries (four
numbers per name)
• Call list of incoming/missed/received
calls (last 40 entries)*
• Redial from call list
• Speed dial
• Any key answer
• Auto login - roaming between 15
different installations
• Adjustable backlight delay for max.
battery conservation
• Messaging:
• Message templates: 10 user-
defined templates
• Text message storage: 20 messages
of max. 72 characters per message*
• Alarm icons and messaging**
• Base station location*
• HD voice ready
• Virtual SIM support
• Disinfectant resistant
• 14 menu languages (UK, FR, DE, ES, IT,
NL, CZ, PL, DK, NO, SV, FI, PT, RU)
KIRK 7020/7040 additional features
• Vibrating alert
• Auto answer (b-answer) with different
settings (after 1st ring/on headset/loud
speaker on). Only possible when not in
charger
• Speaker on auto-answer
• Loud speaking/Handsfree
• Intercom/Loud speaker call*
• Headset jack
• Ringtone in headset
• Adjustable volume in headset
• Answer/End calls via headset
• LED**
• Alarm key - ready for alarm application**
• Membrane keypad for easy cleaning
KIRK 7040 additional features
• Bluetooth headset connection
• Tear-off string**
• Man down detector**
• No movement detector**
• Running detector**
• KIRK Automatic Alarm Call***
• KIRK Handset Sharing***
* System dependent feature. For details, see
Feature Reference Guide on www.support.
polycom.com.
** Application dependent feature.
*** License required
Polycom® KIRK® 70-Handset Series Technical Specifications
Tests
• Vibration test: IEC 60068-2-6
• Bump test: IEC 60068-2-27
• Drop test: IEC 60068-2-31
Polycom EMEA
270 Bath Road, Slough, Berkshire SL1 4DX, UK
+44 (0) 1753 723000
www.polycom.eu
Polycom Asia Pacific
8 Shenton Way, # 11-01 Temasek Tower,
Singapore 068811
+65.6389.9200 - www.polycom.asia
The KIRK 70-Handset Series is available for
sale in Europe, North America, Australia, and
New Zealand.
Left to right: KIRK 7010, 7020, 7040
