– VGA to BNC Video Converter
Speco Technologies’ VGABNC VGA to BNC converter modifies your VGA signal for viewing on any standard
definition TV, projector, or any other device that uses a standard BNC connector. It also features a VGA
output that allows for VGA Loop-Through to simultaneously view video on a VGA monitor and CRT TV
monitor.
Features:
 Connects your DVR with VGA output ports to older model TVs or CRT monitors.
 Ideal for notebook computer users to easily connect and use a large-format monitor.
 Video standards: NTSC/NTSC-EIAJ/PAL/PAL-M/PAL-N.
 Resolutions support: 640 x 480 (up to 85 Hz), 800 x 600 (up to 85 Hz) and 1024 x 768 (up to 75 Hz).
 Input port: VGA (DB15).
 Dual output ports: composite video (BNC connector), VGA (DB15).
 Image controls: Horizontal and vertical size, brightness, contrast, hue, saturation, sharpness and on screen
display background.
 Simple and quick to install; Windows and Mac compatible.
 No driver or operating system requirements; compatible with Windows and Mac computers.
View of Connection and Installation:
On Screen Display Function
HSIZE
VSIZE
BRIGHTNESS
CONTRAST
HUE (This function for NTSC system only)
SATURATION
FLICK
SHARPNESS
OSD (on screen display)
2
BACKGROUND
View of Front Panel:
MENU
display
m
ain
m
UP adjust picture move to up
DOWN adjust picture move to down
LEFT adjust picture move to left
RIGHT adjust picture move to right
SIZE
a
uto adjust picture
to the middle position
ZOOM magnify the picture up to 9 times
* ZOOM magnify the picture up to 9 times with UP DOWN LEFT RIGHT button.
View of Back Panel:
Resolution Menu:
Specifications:
ITEM NO.
VGABNC
Input Signal 1 x VGA
Output Signal 1 x Composite Video (BNC), 1 x VGA 15 pin D female connector
Power Consumption 500mA
Power Supply DC5V 1Amp Regulated Power Supply
Temperature Operation: 32°F to 131°F, Storage: -4°F to 185°F, Humidity: up to 95%
Dimension L x W x H
4.9” x 3.7” x 1.2”
Weight 0.6 Lbs.
Speco Technologies is constantly developing and improving products.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
Speco Technologies 200 New Highway Amityville NY 11701 ● ● ● ● ● www.specotech.com
Rev. 04/2/20
Screen Resolution Screen Refresh Rate
640 x 480 60,72,75,85hz
800 x 600
60,72,75,85hz
1024x768 60,72,75hz
