USER MANUAL
Thank you for purchasing our product. Speco Technologies is constantly developing and
improving products. We reserve the right to modify product design and specifications
without notice and without incurring any obligation.
V5B3/V5B3M/V5D3/V5D3M/V5T3/V5T3M
Warnings
If th e pro d uct does not work properly, please con tact the d ealer or where the product was purchased.
Speco Tech nologies is not respo nsible for any problems caused by improper operation or repair.
Do not expose the unit to heavy stress, violent vibration or long-term exposure to water
and humidity during transportation, storage, and/or installation.
Do not install near sources of heat.
Only install the product in environments inside the specification operating temperature
and humidity range.
Do not install the camera near power lines, radar equipment or other electromagnetic
radiation.
Do not block any ventilation openings if any.
Use all the weatherproofing hardware requirement to minimize weather intrusion.
This camera series is th e latest techno log y and advanced circuit design, which features high definition and
sensitiv ity, low noise and distortion and supp orts HD vid eo transmission with the common coaxial cable,
ensu ring the requiremen t of the HD monitoring in the traditio nal surveillance system.
Introduction
Hig h Reso lu tion
Adopt high performance senso r, pro vid ing high definition and clear imag e.
Hig h Transmission Performance
Real time transmission with high sp eed and lon g distance- .
DNR
Reduce noise from brightness and colo r signal .
OSD
Access the camera settings which can be clearly disp lay ed through the main menu.
White Balance
Adju st th e color temperature according to the en viron ment automatically.
ICR Auto Switch
The filter will filter infrared light during th e day time and ch ange to n o rmal at night to
ensu re a high sensitivity and clear image .
AGC
Adju st the gain of amplifier, enabling th e camera to output the stan d ard v ideo sign al in different
ligh ting condition.
Wide Dy namic Range (WDR)
When there are both v ery b right and very dark areas simultaneously in the field of view, this function
will b alance the brigh tness level and provide clear images.
Backlight Compensation BLC ( )
When the back of the captured o bject is too much bright, you can set BLC for the captured o bject to
mak e it clearer.
1
Cables
Power Ca ble
Vide o Output
Vide o Switch Ca ble
Video Switch: Four v ideo o utput mo des can be op tio nal--AHD, TVI, CVI and CVBS
(a) remove the c o ver of th e video switch cable; (b) h old an d press the button in the video
switch cab le for 5 seconds to switch th e current video output.
2
Before y ou s tart, please mak e sure th at th e wall or ceiling is strong enou g h to wi th st a nd three times
the weigh t of the camera. Please install and use the camera in the dry environment.
Youd better install b ack the lens cover or lower dome less than 4 hours after removing it.
The mounting types of cameras are only for reference.
Installation
Mounting for V5B3/V5B3M
1. Drill the screw holes and the cable hole on the wall according to the drill template.
2. Route and connect the cables .
3. Secure the mounting base with camera to the wall with screws as shown below.
4.6
25.1
82.0
72.2
120°
120°
62.5mm
18.1mm
36.1mm
