Seite 1/5
1. Pedestal
2 Telescopic tube.
3 Tube 2.
4 Tube1.
5 Flange.
6 Tool.
7 Screw M3 *4. ( )
Telescopic tube
Tube 2
Tube 1
Pedestal
1.16~1 48m .adjustable
0 49m.
0 49m.
0 3m.
Floor Standing Mount-
Quick Start Guide
Package
Gross weight Approx 4 7KG: . .
Net weight: Approx.4.6KG
The adjustable range of the bracket without Tube1 is
from 0.67m to 0.99m.
1 Put the flange into the hole of the pedestal. .
Installation
2 Use the tool to fix the flange and the tube1 (You.
can also directly install Tube2 if you don’t want to
install Tube1).
3 Install Tube 2 as shown above..
5 Install the wall mount onto the bracket and .
then fix it with 4 screws.
4 Install the telescopic tube..
Wall Mount
6 Adjust the height of the bracket and then tighten.
the screws .
4 screws
(M3)
Tube1
Tube2
Tube1
Flange
Tool
Telescopic tube
