Seite 1/2
Compatible Model
Optional Accessories
Installation Instruction Diagram
s
Dimensions
• CVC5300DPVF
• CVC5845DNV, CVC5945DNV
• CVC5735DNV, CVC5835DNV, CVC5935DNV
• HT7246iHR, HT7247iHR, HT7250iHR
• HT7248FFi, HTD8FFi
• HTINTD8, HTINTD9, HTINTD10
• OINT03D1G
Pendant Mount
The following items are included in this package.
1-1. Install mount onto the ceiling by using the screws provided.
• INTPM
• 1 Bracket Base Adaptor
• 1 Wrench
• 4 Tapping Screws #8 x 25
• 4 Hexagon Socket Screws M5 x 10
• 3 Machine Screws M4 x 15
• 3 Machine Screws M4 x 22
• 2 Machine Screws M4 x 18
Side ViewFront View
INTPM / INTPMW
Package Contents
200 New Highway, Amityville N 11701Y
800.645.5516 / www.specotech.com
Installation Guide
CVCJBD
Dome Junction Box
JB03TG
Large Round Junction Box
Installation Instruction Diagram Installation Instruction Diagram
INTPM / INTPMW 200 New Highway, Amityville NY 11701
800.645.5516 / www.specotech.com
Installation Guide
2. Arrange each piece as shown in the image below.
3. Fasten the camera onto the mount.
*Compatible models
*Compatible models
*Compatible models
1-2. Install INTPM onto ceiling.
1-3. Install CVCJBD junction box onto INTPM as shown in the image below.
1-4. Install INTPM onto ceiling.
1-5. Install JB03TG junction box onto INTPM as shown in the image below.
