Seite 1/2
Compatible Model
Optional Accessories
Installation Instruction Diagram
s
Dimensions
• HT7246iHR, HT7247iHR, HT7250iHR
• HT7248FFi
Dome Junction Box
The following items are included in this package.
• CVCJBD / CVCJBDW
• 1 Base Sponge Gasket
• 4 Tapping Screws 4 x 25
• 3 Machine Screws M4 x 15, PH
• 2 Machine Screws M4 x 15(Washer Based)
Side ViewFront View
CVCJBD / CVCJBDW
Package Contents
200 New Highway, Amityville N 11701Y
800.645.5516 / www.specotech.com
Installation Guide
1-1. Install junction box onto the ceiling by using the screws provided.
INTPM
Pendant Mount Wall Mount
INTWM
Installation Instruction Diagram Installation Instruction Diagram
CVCJBD / CVCJBDW 200 New Highway, Amityville NY 11701
800.645.5516 / www.specotech.com
Installation Guide
1-2. Install INTPM onto ceiling.
1-3. Install junction box onto INTPM as shown in the image below.
1-4. Install INTWM onto wall.
1-5. Install junction box onto INTWM as shown in the image below.
2. Arrange each piece as shown in the image below.
3. Fasten the camera onto the junction box.
