Seite 1/38
www.solerpalau.comElectrical accessories
ELECTRICAL ACCESSORIES
Single phase speed controller
1
REB-1N / REB-1NE /
REB-2,5N / REB-2,5NE
Electronic single phase speed
controllers. Available in wall box or flush
mount versions.
Fuse protected + spare fuse included.
Minimum speed adjustment.
Single ON/OFF and speed regulation
control knob.
80 22 46
Model Electrical supply IP
Protection
Power
(VA)
Maximum
current
(A)
Minimum
current
(A)
Class Operating
temperatur
range
(ºC)
Frequency
(Hz)
Voltage
(V)
REB-1N/1NE 50 220-240 IP44 220 1 0,15 Class
II 0 /+40
REB-2,5N/2,5NE 550 2,5 0,15
REB-5
LxWxH (mm): 83 x 81 x 160
Electronic single phase speed controller.
Surface mounted.
Fuse protected.
Minimum speed adjustment.
Separate ON/OFF switch.
Model Electrical supply IP
Protection
Power
(VA)
Maximum
current
(A)
Class Operating
temperature
range
(ºC)
Frequency
(Hz)
Voltage
(V)
REB-5 50 230 IP54 1150 5 Class I +5 / +35
LxWxH (mm): 115 x 95 x 195
REB-10 Electronic single phase speed controller.
Surface mounted.
Fuse protected.
Minimum speed adjustment.
Separate ON/OFF switch.
Model Electrical supply IP
Protection
Power
(VA)
Maximum
current
(A)
Class Operating
temperature
range
(ºC)
Frequency
(Hz)
Voltage
(V)
REB-10 50 230 IP54 2300 10 Class I +5 / +35
www.solerpalau.com Electrical accessories
ELECTRICAL ACCESSORIES
Single phase speed controller
2
RRB-100 Electromechanical single-phase speed
controller.
Variable reactance.
Surface mounted.
Five position knob.
LxWxH (mm): 90 x 54 x 134
Model Electrical supply IP
Protection
Power
(VA)
Maximum
current
(A)
Class Operating
temperature
range
(ºC)
Frequency
(Hz)
Voltage
(V)
RRB-100 50 230 IP20 94,3W 0,41 Class II 5-45ºC
RMB Single phase speed controller by
auto-transformer.
IP56 ABS casing.
Electrical supply: 1/230V/50-60Hz.
Five position knob (0/1/2/3/4).
Voltage: 80, 105, 130, 160 and 230 V.
Pilot light.
A
B C
Model Maximum
current
(A)
Casing IP
Protection
Class Operating
temperature
range
(ºC)
Dimensions
(mm)
Weight
(kg)
A B C
RMB-1,5 1,5
PP V0 Class I 0 / +40IP55
230 180 95 3
RMB-3,5 3,5 230 180 95 4
RMB-5 5 230 180 95 4,5
RMB-8 8 310 230 125 10
RMB-10 10 310 230 1250 12
RMT Three phase speed controller by
auto-transformer.
IP54 ABS casing for RMT-1,5 and
RMT-2,5 models.
IP54 metallic casing from RMT-5 to
RMT-12 models.
Electrical supply: 3/400V/50-60Hz.
Six position knob (0/1/2/3/4/5).
Voltage: 90, 150, 200, 280 and 400 V.
Pilot light.
A
B C
Model Maximum
current
(A)
Casing IP
Protection
Class Operating
temperature
range
(ºC)
Dimensions Weight
(kg)
A B C
RMT-1,5 1,5 ABS
IP54 Class I 0 / +40
280 200 140 6
RMT-2,5 2,5 280 200 140 13ABS
RMT-5 5 Metallic 300 250 205 16
RMT-8 8 Metallic 400 300 205 21
RMT-12 12 Metallic 400 300 205 30
RMT configuration
with metallic box
RMT configuration
with ABS box
www.solerpalau.comElectrical accessories
ELECTRICAL ACCESSORIES
Single phase speed controller
3
Auto-transformer.
Single phase 230V-50 Hz.
Wall mounting.
IP44.
Motor PTO connection.
Maximum switch output: (1A).
Model Maximum
current
(A)
Dimensions Weight
(kg)
A B C
REV1,6N 1,6 A 240 190 120 3
REV3N 3 A 240 190 120 5
REV5N 5 A 240 190 120 6
REV7N 7 A 240 190 120 7
REV10N 10 A 290 240 160 12
Model Maximum
current
(A)
Dimensions Weight
(kg)
A B C
RDV0,8N 0,8 A 290 240 160 5,8
RDV1,2N 1,2 A 290 240 160 8
RDV2,5N 2,5 A 290 240 160 11,2
RDV3,2N 3,2 A 290 240 160 14,7
RDV5N 5 A 340 290 160 18,5
RDV7N 7 A 340 290 160 21
RDV10N 10 A 400 300 200 38
REV
RDV Auto-transformer.
Three phase 400V-50 Hz.
Wall mounting.
IP44.
Motor PTO connection.
Maximum switch output: (1A).
A
B C
A
B C
