User Manual BMUZ650
USA
6 BAND
Mobile Z6 4G LTE
Wireless Booster
High Power
MULTI BAND
stealth
tech
®
Cellular
Signal Booster
RX/TX
MULTI BAND
50dB
50dB
6 BAND
GSM,HSPA,CDMA,LTE, LTE A
Band 12,17
Band 13
Band 5
Band 4
Band 2 25 ,
700MHz Upper
850MHz
1700/2100MHz
2G, 3G, 3G+, 4G, 4G+
1900MHz ext
700MHz Lower
Wireless Booster High Power
50dB
Gain
50 dBm
23 dBm
Operating temp
-22 F TO + 185 F
Dimensions
L 4.72 xW 4.25 x H 1.25 (inch)
Model Series
BMUZ650
SPECIFICATIONS
2G, 3G, 3G+, 4G, 4G+, GSM, HSPA, CDMA, LTE, LTE A
Frequencies MHz
700 MHz upper 700 MHz lower 850 MHz 1700/2100 MHz 1900 MHz
Max Power-TX
POWER SUPPLY 12V DC CLA OR 12V DC
fused or 120V AC/DC
Smoothtalker.com
1-877-726-3444
Weight 1.2 lb
To comply with FCC rules, this booster must only be operated with cables, antennas
and coupling devices that have been approved for use with this equipment.
Applications
Optional Desktop (Fig. 2)
(Additional parts required which are
not included in Booster kit.)
1
Contents
Cellular Booster
12 volt install type12 volt socket plug type120 volt AC/DC
Optional Power Types
Inside antenna
SRP1X
All kits include necessary brackets and co-axial cables for assembly. It is normal for the booster to be quite warm while the phone
is in use state. All parts shown are not included in all kits. Please check your model number for more details at smoothtalker.com
Typical Vehicle Installation Mobile Z650 (Fig. 1 )
(All parts are included)
Fig. 1
Mobile Wireless 12 V Socket CLA plug-in Type
Fig. 2
Desktop Wireless with 120 volt adapter
Outside antenna
SEMINI
The Mobile Z650
Can easily be moved from the vehicle to a trailer
2
Installation
1) Connect the outside antenna to the side of the booster
marked as “outside antenna”
Connect the inside antenna to the side of the booster
marked as “inside antenna”
2) Placement
Place the outside antenna in the middle of the vehicle roof. If the vehicle has a
sunroof please place the antenna on the roof towards the back window.
Place the Patch (inside) antenna in desired location. For cars and trucks
the console between the front seats is recommended. Connect the booster as
shown in Fig. 1 & 2 on Pg.1 or Fig. 3 on Pg. 4.
Important: Use only the power supply included with the booster. Connecting any
other power supply at any time will result in damage to the booster and will void
the warranty. Do not turn on the power switch until ALL cables have been
screwed or plugged into the booster or you can cause damage to the booster.
