Seite 1/19
© SKAN HOLZ Europe GmbH D-21227 Bendestorf. Technical modifications reserved. All dimensions are approximate dimensions. Date 06/18
Hengelo 250 x 300cm
1
Important information
We are pleased that you have chosen a product of SKAN HOLZ.
Please check the construction set for completeness using the position list in good time before starting con-
struction or commissioning your construction team. If individual parts are defective or missing, we will deliver
these as quickly as possible. However, we cannot refund the costs for any resulting construction delays to a
construction company.
Please understand that we cannot assume any guarantee for the following defects:
- incorrect storage before assembly
- incorrect anchoring with the ground or inadequate foundation (foundation according to statics)
- damage due to erection errors, e. g. the house is not level or not right-angled
- damage through a higher level of snow burden than statically envisaged. Recommendation: lad relief of
the roof by removing the snow layer
- storm damage (insurance cases) or violent destruction
- damage through any alteration to the design by the client
- natural formation of cracks, branch holes, twisting, decolouration or similar modification (natural
process; has no influence on the statics)
Storage information until construction:
- store pallet on a level and dry surface.
- ; wood can warp drastically in a looseProtect from exposure to sunlight and the influences of weather
condition!
Maintenance tips:
Please observe the attached information sheet “Care instructions/Colour treatment”.
General tips and refers to:
The packaging foil to keep moisture out of the house. It is laid according to the ground area of thecan be used
house under the main bearing.
Given that the roof is constantly exposed to the weather, a covering with only one layer of roofing paper will not
be enough over the long-term. An additional covering with bitumen shingles, alternatively with a material of at
least equivalent quality, must follow.
Foundation according to the structural calculations (not included in the scope of delivery): concrete C25/30,
each 2 Ø 12 top and bottom, brace mat R188A (alternatively brace Ø 6/20cm). Anchoring of the floor beams
(in the building) on the strip foundation using bolts M12, e < 60cm. The base bearings in the storeroom of the
house must be entirely flush.
During the assembly of the planks that the planks are fixed with approx. it is essential to make sure 1mm
distance and the top planks have the same height all around.
Due to storage, the measurements of the planks may change over time and change the heigth of the wallplanks.
Please remember this during the installation of the planks, .otherwise it may result in different wall heights
If the door , this can be adjusted by .cannot be closed properly turning the hinges
-
-
-
-
-
1
1
2
2
603633 (unbehandelt)
603633-13 (schiefergrau)
603633-15 (schwedenrot)
3
250 x 300cm
1 x 28-22-018
350cm
4 x H16/58-00
168cm
2 x H16/58-04
203cm
4 x H58/58-00
201cm
© SKAN HOLZ Europe GmbH, D-21227 Bendestorf. Stand 06/18
1
22 x H19/121-01
293,5cm
14 x H20/20-04
200cm
64 x H19/119-01
60cm
603
603
603
6 x H16/58-00
203cm
1 x 28-22-019
350cm
1
1 x H19/120-00
53cm
64 x H19/119-01
97cm
1 x H16/58-00
263m
+
2 x H16/58-04
203cm
250 x 300cm
4
1 x 28-10-0031
1 x 28-10-0032
13 x 28-06-0103
2 x 28-04-0123
1 x 28-04-0124
2 x 28-04-0126
1 x 28-04-0127
1 x 28-04-0128
30 x 28-06-0122
© SKAN HOLZ Europe GmbH, D-21227 Bendestorf. Stand 06/18
603206 (unbehandelt)
603206-13 (schiefergrau)
603206-15 (schwedenrot)
1 x 28-10-0031
1 x 28-10-0032
13 x 28-06-0103
1 x 28-04-0125
2 x 28-04-0123
1 x 28-04-0124
2 x 28-04-0126
1 x 28-04-0127
1 x 28-04-0128
15 x 28-06-0036
1 x 28-04-0125
