SX700-LPT
SFX-L Form Factor
A pioneering SFX-L form factor power supply
SFX-L form factor for use small form factor computers
700W continuous power output rated for 24/7 operation
Class-leading single +12V rail with 58.4A
High efficiency with 80 PLUS Platinum certification
Silent running 120mm fan with advanced semi-fanless operation
100% modular short cables with flexible flat arrays
Strict ±3% voltage regulation and low ripple & noise
Support quad PCI-E 8/6pin connectors
High quality construction with all Japanese capacitors
SPECIFICATION
SFX-L Form Factor
SST-SX700-LPT
700W Switching Power Supply
With Active PFC
80Plus Platinum
01
1.1 Scope
This specification defines the performance characteristics of a single phase 700 watts, 5 output power
supply. This specification also defines worldwide safety and electromagnetic compatibility requirements
for the power supply which is intended for use in computer products.
Nominal Voltage
100-240 Vrms
Voltage Variation Range
90 - 264 Vrms
1. General
2.1 Input Voltage
2.2 Input Frequency
* The power supply must operate at above frequency with 90-264 VACrms input voltage range.
2. Input Characteristics
Nominal Frequency
50-60 Hz
Frequency Variation Range
47 Hz to 63 Hz
02
2.3 Max. Input AC Current
3.1 Normal Operation Output
3. Output characteristics
Max. Input Current
2.4 Inrush Current
The power supply must meet inrush requirements for any rated AC voltage, during turn on at any phase
of AC voltage, during a single cycle AC dropout condition, during repetitive ON/OFF cycling of AC, and
over the specified temperature range. The peak inrush current shall be less than the ratings of its critical
components (including input fuse, bulk rectifiers, and surge limiting device).
2.5 Efficiency
SX700-LPT provides an efficiency of 90% at20% load, 92% at50% load, 89% at100% load under115V/60Hz
and 230V/50Hz condition.
Maximum continuous total DC output power should not exceed 700W.
Maximum continuous combined load on +3.3VDC and +5VDC outputs shall not exceed 120W.
Maximum combined load on 12V outputs shall not exceed 700W.
NOTE:
Noise test should be measured with 20 MHz bandwidth frequency oscilloscope. The output terminal shall
add a tantalum capacitor of 10uF in parallel with a ceramic capacitor of 0.1uF.
3.2 Remote On/Off Controlled mode
The PSON# signal is required to remotely turn on/off the power supply, PSON# is an active low signal that
turns on the output power rails. When this is not pulled low by the system, or left open, the outputs (except
the +5VSB) turn off. This signal is pulled to a standby voltage by a pull-up resistor internal to the
power supply.
TTL level "H" 2.0 V – 5.25 V
"L" 0.0 V – 1.0 V
10.0A
Measuring Range
90 - 264 Vrms
Output Voltage
1. +5V
2. +3.3V
3. +12V
4. -12V
5. +5Vsb
Load MIN
0.0A
0.0A
0.0A
0.0A
0.0A
Range MAX
22A
22A
58.4A
0.3A
3.0A
Regulation
±3%
±3%
±3%
±10%
±5%
Ripple & Noise P-P Max.
50mV
50mV
120mV
120mV
50mV
