Seite 1/24
5.25" device bay to 3.5" SAS/SATA 6.0 Gbit/s
trayless hot-swap cage
Front Panel Storage FS303 / FS304 / FS305
5 25" d i b t 3 5"
6
.0
G
bit
/
s
FS304
/
FS305
The following manual and guides were carefully prepared by the SilverStone engineering team to
help you maximize the potential of your SilverStone product. Please keep this manual for future
reference when upgrading or performing maintenance on your system. A copy of this manual can also
be downloaded from our website at:
Installation and system optimization guide:
Product Overview
Installation Chart
Indicator Status
Warranty
P.1
P.6
P.10
P.21
Product Overview
Front Panel Storage
1
Specifications
To accommodate PC user’s need for more storage flexibility and convenience, SilverStone created a line of front bay storage products
called the FS series. These are 5.25” bay chassis designed to fit 3.5” or 2.5” SAS/SATA drives. Equipped with release handle made out
of finely brushed aluminum, hot-swapping drives is extremely quick and comfortable. Built-in cooling fan behind the chassis ensures
drive and run cool for extended life while individual LED indicators let user easily monitor drive status in one glance. For security, each
drive tray also has metal key lock. For those that need to upgrade their current PC with more drives, SilverStone’s FS series is a great
choice.
FS303 FS304 FS305
Model
Color
Material
Form factor
Drive support
Transfer rate
Host interface
Power connector
Drive door security
Number of Key
LED indicator
Cooling fan
Switch button
Net weight
Dimension
SST-FS303B, SST-FS304B, SST-FS305B
Black
Aluminum and front bezel with plastic clip button
5.25” drive bay
3.5” SAS/SATA HDD or SSD
Up to 6 Gbit/s (dependent on drive speed)
7-Pin SATA connector X3 or SAS primary channel connection (FS303)
7-Pin SATA connector X4 or SAS primary channel connection (FS304)
7-Pin SATA connector X5 or SAS primary channel connection (FS305)
SATA 15-Pin X2
Triangle metal key lock design
2
Power ON : Blue
Accessing : Purple blinking
70mm fan x 1, 3000rpm (FS303)
80mm fan x 1, 3000rpm (FS304, FS305)
Fan speed
HDD LED
1.02kg (FS303)
1.45kg (FS304)
1.40kg (FS305)
High/Low
ON/OFF
Introduction
Fits 3.5” SAS/SATA 6Gbit/s drives in 5.25” device bay
Adjustable drive status LED and fan control system
Trayless & screwless design
Individual metal key lock for each drive for extra security
All aluminum body with beautiful hairline brushed finish
Independent drive status LED
Built-in cooling fan for excellent heat dissipation
Fully supports SATA Hot-Swap function
Special Features
o
r those that need to up
g
rade their current P
C
FS3
04
ho
ice
.
FS30
3
Sp
p
ecial Features
v
erStone created a line of front ba
y
sto
r
S
ATA drives.
Eq
uip
ped
with release ha
n
ble. Built-in coolin
g
fan behind the ch
a
m
onitor drive status in one
g
lance. For
s
e
drives, SilverStone’s FS se
FS305
C
with mor
e
146 Xmm (W) 84.5 mm (H) X 195 mm (D) , FS303
146 Xmm (W) 126 mm (H) X 199 mm (D) , FS305
146 Xmm (W) 125 mm (H) X 98 mm (D) , FS304
