ENGLISH
SHINDAIWA OWNER’S/OPERATOR’S MANUAL
T260 GRASS TRIMMER
T260X GRASS TRIMMER
LE260 LAWN EDGER
C260 BRUSHCUTTER
Part Number 62710-94310 Rev. 8/05
Minimize the risk of injury to yourself and others!
Read this manual and familiarize yourself with the
contents. Always wear eye and hearing protection
when operating this unit.
WARNING!
2
WARNING!
Use Good Judgment
NEVER operate the engine when trans-
porting the unit.
NEVER operate the engine indoors!
Make sure there is always good ventila-
tion. Fumes from engine exhaust can
cause serious injury or death.
ALWAYS use the proper cutting tool for
the job.
ALWAYS stop the unit immediately if
it suddenly begins to vibrate or shake.
Inspect for broken, missing or improp-
erly installed parts or attachments.
NEVER extend trimming line beyond
the length specified for your unit.
ALWAYS keep the unit as clean as
practical. Keep it free of loose vegeta-
tion, mud, etc.
ALWAYS hold the unit firmly with both
hands when cutting or trimming, and
maintain control at all times.
ALWAYS keep the handles clean.
ALWAYS disconnect the spark plug
wire before performing any
maintenance work.
ALWAYS if a blade should bind fast in
a cut, shut off the engine immediately.
Push the branch or tree to ease the bind
and free the blade.
Introduction
Attention Statements .................................. 2
Safety Information .......................................2
Safety Labels ................................................ 4
Product Description ....................................6
Specifications ...............................................6
Assembly ...................................................... 7
Installing Cutting Attachments ................ 11
Engine Fuel ............................................... 15
Starting the Engine ...................................16
Stopping The Engine ................................ 16
Adjusting Engine Idle ............................... 17
Checking Unit Condition ......................... 17
Shoulder Strap ........................................... 17
Cutting Grass (trimmer head) ................ 18
Using a Brushcutter Blade ......................19
Using the Edger ........................................ 20
Maintenance .............................................. 21
Muffler Service .........................................23
Long Term Storage ...................................24
Blade Sharpening ...................................... 24
Troubleshooting Guide ............................25
Emission System Warranty ...................... 26
PAGE
The Shindaiwa 260-series hand held power
equipment has been designed and built to
deliver superior performance and reliability
without compromise to quality, comfort,
safety, or durability.
Shindaiwa’s high-performance engines rep-
resent the leading edge of 2-cycle engine
technology, delivering exceptionally high
power with remarkably low displacement
and weight. As an owner/operator, you’ll
soon discover for yourself why Shindaiwa is
simply in a class by itself!
IMPORTANT!
The information contained in this manual
describes units available at the time of
publication.
Shindaiwa Inc. reserves the right to make
changes to products without prior notice,
and without obligation, to make alterations
to units previously manufactured.
Contents
WARNING!
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth de-
fects or other reproductive harm.
Throughout this manual are special
“Attention Statements”.
IMPORTANT!
The operational procedures described in
this manual are intended to help you get
the most from your unit, and to protect you
and others from harm. These procedures
are guidelines for safe operation under most
conditions, and are not intended to replace
any safety rules and/or laws that may be in
force in your area.
If you have questions regarding your 260-
series unit, or if you do not understand
something in this manual, your Shindaiwa
dealer will be glad to assist you.
You may also contact Shindaiwa, Inc. at the
address printed on the back of this Manual.
Attention Statements
CAUTION!
A statement preceded by the word
“CAUTION” contains information that
should be acted upon to avoid damag-
ing the unit.
IMPORTANT!
A statement preceded by the word
“IMPORTANT” is one that possesses
special significance.
NOTE:
A statement preceded by the word “NOTE”
contains information that is handy to know
and may make your job easier.
WARNING!
A statement preceded by the trian-
gular attention symbol and the word
“WARNING” contains information that
should be acted upon to prevent seri-
ous bodily injury.
Work Safely
Trimmers and brushcutter operate at very
high speeds and can do serious damage or
injury if they are misused or abused. Never
allow a person without training or instruc-
tion to operate this unit!
General Safety Instructions
WARNING!
Never make unauthorized attachment
installations.
3
The Properly Equipped Operator
Stay Alert
You must be physically and mentally fit to
operate this unit safely.
WARNING!
Never operate power equipment of any
kind if you are tired or if you are under
the influence of alcohol, drugs, medica-
tion or any other substance that could
affect your ability or judgement.
WARNING!
Minimize the Risk of Fire
NEVER smoke or light fires near the
unit.
ALWAYS stop the engine and allow it
to cool before refueling. Avoid overfill-
ing and wipe off any fuel that may have
spilled.
ALWAYS inspect the unit for fuel leaks
before each use. During each refill,
check that no fuel leaks from around the
fuel cap and/or fuel tank. If fuel leaks
are evident, stop using the unit immedi-
ately. Fuel leaks must be repaired before
using the unit.
ALWAYS move the unit to a place well
away from a fuel storage area or other
readily flammable materials before start-
ing the engine.
NEVER place flammable material close
to the engine muffler.
NEVER run the engine without the
spark arrester screen in place.
General Safety Instructions
Always wear a harness when
operating a unit equipped
with a blade.
Wear appropriate footwear
(non-skid boots or shoes): do not wear
open-toed shoes or sandals. Never work
barefooted!
Wear hearing protection devices and a
broad-brimmed hat or helmet.
Wear close-fitting clothing to
protect legs and arms. Gloves
offer added protection and
are strongly recommended.
Do not wear clothing or
jewelry that could get caught
in machinery
or underbrush.
NEVER wear
shorts!
Always wear eye
protection such as goggles or
safety glasses.
Always operate with both
hands firmly gripping the
unit.
When operating with a blade, make
sure the handle is positioned to
provide you with maximum protec-
tion from contacting the blade.
Keep away from the rotating
trimming line or blade at all
times, and never lift a moving
attachment above waist-high.
Keep a proper
footing and do not
overreach—
maintain your balance
at all times during
operation.
Always make sure the
appropriate cutting
attachment shield is
correctly installed.
Figure 1
