Seite 1/1
Sensor
4. Locate the output socket in a convenient location on the instrument and attach with applied double sided adhesive4. Locate the output socket in a convenient location on the instrument and attach with applied double sided adhesive
1. Test fit sensors into the slot between the wing and foot.
Pickup should t tightly for best output (see g 1).
1. Test fit sensors into the slot between the wing and foot.
Pickup should t tightly for best output (see g 1).
2. If pickup is too loose, shim with included shim material (see fig 2). If pickup is too high, file the bridge slot slightly.2. If pickup is too loose, shim with included shim material (see fig 2). If pickup is too high, file the bridge slot slightly.
3. Install the sensors into the bridge slots.3. Install the sensors into the bridge slots.
5. Connect to appropriate amplifier with instrument cable.5. Connect to appropriate amplifier with instrument cable.
Copper Foil
Tape
Fax: (561) 743 0460
eMail: jjmelch@shadow-pickups.com
Shadow Elektroakustik
Peter-Haendel Straße 2
91334 Hemhofen · Germany
Shadow Electronics of America Inc.
17791 Alexander Run
Jupiter, FL 33478 U.S.A.
Fax: +49 - 91 95 - 92 99 30
eMail: info@shadow-electronics.com
Content:Content:
Fig. 2Fig. 2
Fig. 1Fig. 1
Violin Twin Bridge Pickup,
Cable holder,
Integrated Volume and tone control,
12 foot cable,
Copper Foil Tape
Violin Twin Bridge Pickup,
Cable holder,
Integrated Volume and tone control,
12 foot cable,
Copper Foil Tape
Installation Instruction for Shadow SH 941
Violin Twin Bridge Pickups
Note:
Piezo pickups and transducers have a very high output impedance. In order to get the optimum sound output we recommend
an amplier with low impedance input.
Note:
Piezo pickups and transducers have a very high output impedance. In order to get the optimum sound output we recommend
an amplier with low impedance input.
