USER MA NUAL
W W W. SEUR A .COM
FOR SÉUR A OUTDOOR DISPLAYS
Slim Wall Mount
MODEL NUMBERS
SW-1
SWL-1
2
Supplied Parts
CAUTION
DO NOT EXCEED
MAXIMUM LISTED
WEIGHT CAPACITY.
SERIOUS INJURY OR
PROPERTY DAMAGE
MAY OCCUR
This product is designed to mount televisions weighing up to 200 lbs to a vertical îś·rm wall.
Safety Warning: Ensure that there are no missing or defective parts upon receipt. Never use
defective parts. Improper installation may cause damage or serious injury.
Note: The included hardware is for mounting on walls. If you are uncertain about the nature of
your wall, consult an expert. Please consult your hardware or installation professional for proper
mounting to other types of walls.
Overall Dimensions (W x H x D): 17.5” x 4.19” x 0.5” (Model: SW-1 for 49” to 65” )
Overall Dimensions (W x H x D): 26” x 4.19” x 0.5” (Model: SWL-1 for sizes over 65”)
Safety
WALL MOUNTING
TEMPLATE
INSTALLATION
MANUAL
TV MOUNTING
HARDWARE
SW-1:
4 Stainless Steel
Lag Bolts
5/16”, 3” long
4 Plastic Anchors for
Concrete, Brick, and
Stone, 2.5” long
4 Stainless Steel
Flat Washers
4 Black Plastic Spacers
1/8” Thick
(needed for use with
Shade Series TVs)
SWL-1:
6 Stainless Steel
Lag Bolts
5/16”, 3” long
6 Plastic Anchors for
Concrete, Brick, and
Stone, 2.5” long
4 Stainless Steel
Flat Washers
4 Stainless Steel Vesa
Flanged Screws
M8, 12 mm long
NOTE: RECESSED OUTLET REQUIRED
BECAUSE THE SLIM MOUNT ALLOWS THE TV TO SIT TIGHTLY AGAINST THE WALL, TRADITIONAL WALL
OUTLETS DO NOT ALLOW ENOUGH CLEARANCE FOR CABLES. UTILIZE EITHER RECESSED OUTLETS OR
REMOTE POWER LOCATIONS THAT ARE COMPLIANT WITH YOUR LOCAL BUILDING CODES.
[400mm]
15-3/4in
WALL MOUNTING TEMPLATE
CENTER OF TELEVISION
Attaching Wall Plates to Wall
Note: This product should be mounted to concrete, stone, brick, or wood studs.
Measure the location for the template. The template will help guide the distance
from the edges of the TV to the center of the screen. Make sure to tape the
template securely to the wall. Use the wall mounting template to mark four
holes on the wall - two in the top plate, two in the bottom plate. Ensure that
the hole locations are level.
Solid Surface Wall Mounting (concrete, stone, or brick): Pre-drill holes through
the paper template with a 10mm masonry bit. Insert a concrete anchor into each
of these holes. Attach both wall plates to the wall using four lag bolts and four
lag bolt washers.
Drywall/Stud Wall Mounting: The wall plates must be mounted to at least two
wood studs. Use a stud sensor to locate three adjacent studs. Pre-drill a 55mm
deep hole using a 4.5mm drill bit. Use the wall plate drawing as a template to
mark the location of the second hole in each stud. Attach the wall plates to the
wall using the four lag bolts and four lag bolt washers.
Instructions
Television Location from Ed ge to Center
17"
14-9/16"
13-1/16"
17"
14-9/16"
13-1/16"
29-5/16"
25"
22-5/16"
29-5/16"
25"
22-5/16"
49"
55"
65"
Bottom
of TV
Television Size
Right Side
of TV
Left Side
of TV
Top of TV
WALL MOUNT BRACKETS x 2
4 SLIM MOUNT IDENTICAL BRACKETS:
TV MOUNT BRACKETS x 2
US E R MA N U A L
WW W. SE U R A. C OM
FO R S ÉUR A OU TD OOR DI SPL AYS
Slim Wall Mount
MODEL NUMBERS
SW-1
SWL- 1
3
1. Aach Wall Plate to Wall
NOTE: THIS PRODUCT SHOULD BE MOUNTED TO CONCRETE, STONE,
BRICK, OR WOOD STUDS.
1a. Measure the location for the template. The template will help guide
the distance from the edges of the TV to the center of the screen (b).
Make sure to tape the template securely to the wall (c). Use the wall
mounting template to mark four holes on the wall - two in the top plate
(d), two in the bottom plate. Ensure that the hole locations are level (e).
1b. Concrete, Stone, or Brick Wall Mounting: Pre-drill holes through the
paper template with a 7/16” masonry bit (b). Insert a concrete anchor (c)
into each of these holes. Attach both wall plates to the wall using four
lag bolts (d) and four at washers (e).
1c. Wood Stud Wall Mounting: The wall plates (b) must be mounted to at
least two wood studs. Use a stud sensor to locate three adjacent studs.
Pre-drill a 3” deep hole using a 7/32” drill bit. Use the wall plate drawing
as a template to mark the location of the second hole in each stud.
Attach the wall plates to the wall using the four lag bolts (c) and four lag
bolt washers (d).
Instructions
2. Aach Mounts to TV
Remove the Vesa mount screws from the back of the TV. Make sure the
two TV mounts are mounted at the speciîś·ed distance as indicated on
the template. Séura Outdoor TVs up to 65” require M6 bolts.
Note: On the 86” TV only, replace the vesa mount screws with the
screws supplied in the hardware kit.
Note: For use with Shade Series Outdoor TVs, use the included 1/8”
black plastic spacers between the back of the TV and the TV Mount
Bracket.
3. Hang TV and Adjust
NOTE: NEVER TRY TO HANG A TV BY YOURSELF. ALWAYS USE AT LEAST
TWO PEOPLE TO LIFT THE TV INTO PLACE.
Hook the top and bottom rails the TV rails over the top off the wall
plate. Both sets need to fully engage to be secure. Make sure the mount
is properly engaged.
SĂ©ura recommends checking knobs, screws, and bolts every 2-6
months. Temperature uxuations, wind, and normal wear and tear can
loosen hardware over time.
If you have any questions regarding installation, please contact SĂ©ura
Support at 1-800-957-3872.
TV BACK VIEW
