SPLICE-500™ MKII DUAL MODE FET COMPRESSOR
Thank you for your purchase of the Serpent Audio SPLICE-500™ MKII. This unit is
proudly 100% designed and built in the USA. Through our dedication to advanced
engineering, high-quality components, and research from industry pros, you can
expect years of reliability and great customer service.
THANK YOU
TABLE OF CONTENTS:
DESCRIPTION / OVERVIEW 2
SPECIFICATIONS 2
INSTALLATION & OPERATION 3
FRONT PANEL CONTROLS 3
MAINTENANCE AND CLEANING 8
WARRANTY 8
SPLICE™ MKII
MANUAL V.1
.1
2
www.serpentaudio.com
1. DESCRIPTION / OVERVIEW:
The SPLICE-500™ MKII is a single channel FET based compressor, and can be
used for mono applications, or can be paired with a second SPLICE-500™ MKII for
stereo applications. The SPLICE-500™ MKII’s unique circuitry mode switching
allows the user to configure the input & output audio path circuitry between classic
Blackface and Blue Stripe modes, or mix and match the two to create completely
new sounds, unique to the SPLICE-500™ MKII.
2. SPECIFICATIONS:
Maximum Current Consumption: 175mA* @ +/-16V
Input: Constant 600R Input Attenuator, Floating Transformer Balanced
Output: Floating Transformer Balanced
Output (With Mix Enabled): <100 Ohm Output Impedance, Transformer-like
Floating Output, Electronically Balanced (Accepts Balanced or Unbalanced Signals)
External Send: <100 Ohm Output Impedance, Transformer-like Floating Output,
Electronically Balanced (XLR) (Accepts Balanced or Unbalanced Signals)
External Return: 22KHz Input Impedance, Electronically Balanced (XLR), (Accepts
Balanced or Unbalanced Signals)
Maximum Input Level: +30dbu with compression engaged and Input level knob set
to max (fully clockwise)
Maximum Output Level: +24dbu
Output Load: 150 Ohm minimal
Gain: 45db (+/-1dbu) with compression disabled (Ratio set to “BP”)
Gain Reduction Element: FET
THD+N: (20Hz-20KHz) Typically 0.5%
Signal-To-Noise Ratio: >80dbu
*Before installation, ensure that the SPLICE-500™ MKII’s power requirements do
not exceed your 500 series rack’s power supply rating.
SPLICE™ MKII
MANUAL V.1
.1
3
www.serpentaudio.com
3. INSTALLATION & OPERATION:
The SPLICE-500™ MKII is a 500 series format compressor. It requires one channel
in a 500 series compatible rack.
Be sure to safely and securely seat the edge cards of the SPLICE-500™ MKII into
the edge connectors of your 500 rack before inserting the module. If the mounting
holes on the front of the module do not properly align with the mounting holes on the
rack, it can be adjusted by using a gentle, slight up and down rocking motion while
inserting the module.
NEVER TWIST OR FORCE THE MODULE INTO THE RACK!
The SPLICE-500™ MKII contains a Class A transistor output circuit. Due to the
nature of Class A circuits and the subsequent heat and power dissipation the module
will be warm to the touch while in operation. The unit should be allowed a minimum
of 5 minutes after power down before handling.
It is important to ensure adequate ventilation of the module while in operation. The
SPLICE-500™ MKII should never be placed adjacent to another heat source or high
power 500 module. While it is not required, it is recommended to leave a blank slot
space to the right of the module in your 500 series rack to ensure adequate cooling
and ventilation.
Overheating of the SPLICE-500™ MKII may lead to damage to the product not
covered under warranty.
4. FRONT PANEL CONTROLS:
Input:
A fully adjustable rotary potentiometer, turning the input control clockwise will
increase the amount of signal entering the unit and increase the amount of
compression taking place (once the signal level reaches the compression threshold).
Output:
A fully adjustable rotary potentiometer, turning the output control clockwise will
increase the amount of signal leaving the unit. Use this control to set appropriate
make-up gain after adjusting the input knob for the desired amount of compression.
