Seite 1/2
®
WARRANTY: This SECO-LARM product is warranted against defects in material and workmanship while used in normal service for one (1) year from the date of sale to the original customer.
SECO-LARM’s obligation is limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM. This Warranty is void if damage is caused
by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM
determines that such equipment is not operating properly as a result of causes other than defects in material and workmanship. The sole obligation of SECO-LARM and the purchaser’s
exclusive remedy, shall be limited to the replacement or repair only, at SECO-LARM In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential ’s option.
personal or property damage of any kind to the purchaser or anyone else.
Armored Door Cords
Installation Manual
SD- -T15Q/S shown 969
Also Available from ®:
Door Strikes
Push- -Exit Bars to
SD-995C Shown
SD- -36 Shown 961A
Maglocks
Deadbolts
E-941SA- Shown 600
SD- -GBQ Shown 997B
Armored Door Cord with Plastic End Caps, Silver
SD- -A18Q 969
ď‚· Plastic end caps
ď‚· Designed to carry wiring to conduct power to
electric locks or access systems mounted in doors
ď‚· Mounting screws included
ď‚· Surface-mount
 16” (41cm) Stainless steel armored cord
ď‚· Inside door-cord diameter: 5/16" (8mm)
ď‚· Outside door-cord diameter: 7/16" (1 mm)1
Armored Door Cord with Die-Cast Aluminum End Caps, Silver
SD- -S18Q 969
ď‚· Die-cast aluminum end caps
ď‚· Designed to carry wiring to conduct power to
electric locks or access systems mounted in doors
ď‚· Mounting screws included
ď‚· Surface-mount
 17 3cm) Stainless steel armored cord ” (4
ď‚· Inside door-cord diameter: 5/16" (8 mm)
ď‚· Outside door-cord diameter: 1/2" (1 mm)3
® U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Website: www.seco-larm.com
Phone: (949) 261-2999 | (800) 662- 0800
Email: sales@seco-larm.com
All trademarks are the property of SECO-LARM U.S,A., Inc. or their respective owners. The SECO-LARM policy is one of continual development and improvement. For that reason,
SECO-LARM reserves the right to change prices and specifications without notice. SECO-LARM is also not responsible for misprints.
Copyright © 2016 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in whole or in part, without the written permission of SECO-LARM.
®
PITGW1
MI_SD- -x1xQ_160727.docx969
Armored Door Cord with Terminal Blocks and Removable Die-Cast Aluminum End Caps
SD- -T15Q/B Bronze 969 –
SD- -T15Q/S Silver 969 –
ď‚· Designed to conduct power to electric locks or
access systems
ď‚· Once mounted, to access, simply remove cover.
Door cord stays in place. No need to remove
from the door. Prevents stripping of the screws
and mounting points
ď‚· Surface-mounted
ď‚· Terminal blocks with pre-wired cables (8
connections) for quick, easy, and secure
installation
 Maximum current 3A@30VAC/VD –C
 15” (39cm) Stainless steel armored cord
ď‚· Inside door-cord diameter: 5/16" (8mm)
ď‚· Outside door-cord diameter: 7/16" (11mm)
ď‚· Security screws (included) prevent tampering
ď‚· Available in bronze silver finish or
SD- -T15Q/S shown 969
Note: Each terminal is wired on a one to one basis, meaning that
whatever is wired to a particular terminal number on one block will
be connected the same terminal number on the other block. to
Sample Wiring Diagram
Armored Door Cord with Removable Die-Cast Aluminum End Caps
SD- -M15Q/B shown 969
SD- -M15Q/B Bronze 969 –
SD- -M15Q/S Silver 969 –
ď‚· Designed to carry wiring to conduct power to
electric locks or access systems
ď‚· Once mounted, to access, simply remove cover.
Door cord stays in place. No need to remove
from the door. Prevents stripping of the screws
and mounting points
ď‚· Surface-mounted
 15” (39cm) Stainless steel armored cord
ď‚· Inside door-cord diameter: 5/16" (8mm)
ď‚· Outside door-cord diameter: 7/16" (11mm)
ď‚· Security screws (included) prevent tampering
ď‚· Available in bronze silver finish or
