RSH-1151/1651 Laminator
OWNER'S MANUAL
18. WARRANTY
Royal Sovereign International warrants the equipment sold is free from defects in
material and workmanship for a period of One (1) year for Parts and Labor from the date
of installation, excluding lamination rollers which are warranted for Six (6) months. This
warranty is extended only to the original purchaser. This warranty is the only warranty
made by Royal Sovereign International and cannot be modified or amended. Royal
Sovereign’s sole and exclusive liability and the customer’s sole and exclusive remedy
under this warranty shall be, at Royal Sovereign’s option, to repair or replace any such
defective part or product. These remedies are only available if Royal Sovereigns
examination of the product discloses to Royal Sovereign’s satisfaction that such defects
actually exist and were not caused by misuse, neglect, attempt to repair, unauthorized
alternation or modification, incorrect line voltage, fire, accident, flood or other hazard.
The warranty made herein is in lieu of all other warranties, expressed or implied,
including any warranty or merchantability or fitness for a particular purpose. Royal
Sovereign will not be liable for personal damage or personal injury (unless primarily
caused by its negligence), loss of profit, or other incidental or consequential damages
arising out of the use or inability to use this equipment.
This warranty specifically does not cover damage to laminating rollers caused by knives,
razor blades, or any sharp objects or abrasives, or failure caused by adhesives, or
damage caused by lifting, tilting and/or any attempt to position the machine other than
rolling on the installed castors or feet on even surfaces, or improper use of the
machine. Warranty repair or replacement by Royal Sovereign or its authorized
Reseller(s) does not extend the warranty beyond the initial one year period from the
date of installation. Unauthorized customer alterations will void this warranty.
LIMITED WARRANTY
Royal Sovereign International Inc.
www.royalsovereign.com
Read all instructions carefully before use.
For any Customer Support needs please choose the
Customer Support tab on www.royalsovereign.com
RS Holland B.V.
Columbusstraat 25 - 3165 AC Rotterdam,
The Netherlands
E-mail : paulchoi@royalsovereign.com
henryabrahamian@royalsovereign.com
RS International Australia PTY. LTD.
30 Prime Drive, Seven Hills, NSW 2147, Australia
TEL : +61) 2-9674-2127
FAX : +61) 2-9674-2027
E-mail : salesaust@royalsovereign.com
CORPORATE HEADQUARTERS
Royal Sovereign International Inc.
2 Volvo Drive, Rockleigh, NJ 07647 U.S.A.
TEL : +1) 800-397-1025 FAX : +1) 201-750-1022
E-mail : info@royalsovereign.com
Royal Sovereign Inc.
<Oversea Sales Office>
1001, World Meridian II, 426-5, Gasan-dong,
Geumcheon-gu, Seoul, 153-759, KOREA
TEL : +82)2-2025-8800 FAX : +82)2-2025-8830
E-mail : sales@royalsovereign.com
RS Canada Inc.
164 Oakdale Road, Toronto, Ontario M3N 2S5
CANADA
TEL : +1) )416-741-8400 FAX : +1 416-741-8185
E-mail : info@royalsovereign.com
RSH-1151/1651
21
TABLE OF CONTENTS 1. INTRODUCTION
TOPIC PAGE
1. Introduction.......................................................................................................... 2
2. Safety Precautions............................................................................................... 2
3. Installation ............................................................................................................ 3
4. Included with Laminator....................................................................................... 4
5. Product Identification.............................................................................................5
6. Control Panel........................................................................................................ 6
7. Speed and Temperature Settings ....................................................................... 8
8. Roller Nip Settings................................................................................................ 8
9. Using Foot and Remote Control .............................................................. 9Pedal .
10. Using Cross Cutter ............................................................................................ 9
11. Using Slitter...................................................................................................... 10
12. Loading Film..................................................................................................... 11
13. Threading Film
13.1. Laminating and Encapsulation................................................................ 12
13.2. Decaling .................................................................................................. 14
13.3. Mounting ................................................................................................. 15
14. Installation of the Front Feed and Rear Rewind Options ................................ 16
15. Maintenance..................................................................................................... 17
16. Troubleshooting ............................................................................................... 17
17. Specifications................................................................................................... 18
18. Warranty........................................................................................................... 19
Thank you for choosing a Royal Sovereign laminator. It has been designed and
manufactured to provide years of continuous service. For complete operating and
maintenance information please read this manual thoroughly. Upon receipt of your
laminator, please inspect the box, the machine and all other contents for shipping
damage. Damage should be brought to the immediate attention of the delivering carrier
(See page 4 for list of shipment elements).
2. SAFETY PRECAUTIONS
Failure to comply with any of the following safety procedures could result in serious injury.
Please read the instructions carefully and keep for future reference.
1. Only a licensed electrician should install wiring and outlet for the laminator.
2. Ensure the unit is plugged into a properly grounded outlet with the correct voltage.
3. Keep hands and clothing (i.e. Neckties) away from rollers.The rollers pinch pointshave
that can trap body parts or clothing and cause serious injury.
4. Keep flammable and wet objects away from the machine.
5. Place machine on a level surface.
6. Avoid excessive sunlight, humidity and extreme temperatures.
7. Ensure the unit is turned off, cooled, and unplugged from the outlet prior to moving
and/or repairing.
8. Keep out of reach of children.
9. Only Royal Sovereign authorized maintenance and service technicians should make
repairs.
10. Do not attempt to laminate items that exceed total recommended material thickness
for the unit
11. When cleaning the machine, don't use flammable sprays or materials.
12. Do not touch the rollers when they are hot or place foreign objects inside the machine.
13. Do not cover the surface of the machine until the machine has completely cooled.
RSH-1151/1651
43
3. INSTALLATION
Note: The laminator should be installed by a trained service technician.
ELECTRICAL REQUIREMENTS
POWER SUPPLY
The laminator comes fully assembled, except for the feed table and paper guide to avoid
shipping damage. Upon arrival, thoroughly inspect the unit. It is imperative that any
shipping damage is reported and a claim is filed with the delivering carrier immediately
upon receipt.
The laminator should be located in an area with adequate work space for feeding graphics
and lamination materials.
Avoid placing the laminator in a dusty area or near sources of extreme heat or cold.
Once the laminator is in place, lock the casters into position(ON” position). Always unlock
the casters (OFF position) when moving to a different location.
4. INCLUDED WITH LAMINATOR
Thoroughly inspect the parts and the unit. It is imperative that any missing parts are
reported and a claim is filed with the reseller immediately upon receipt of shipment.
Royal Sovereign recommends that a licensed electrician ensures proper power to your
laminator in accordance with electrical codes in your area.
The laminator should have a dedicated power line.
230V UL 220V EU 240V UK
Part Name
Laminator
Owner's Manual
Registration Card
´(76mm) / 2" (57mm) Auto Grip
L-wrench (2.5)
Dust Cover
Spare Motor Fuse - FUSE(50T)
( 6.3A)
Spare Main Power Fuse - FUSE(65TS)
15A(RSH-1151) / 20A(RSH-1651)
Roll film Samples
8 - 1/4"Hexa head Bolt (M6 20mm)
8 - Spring Washer( 6.1)
(Included with option only)
Front Feeder and Rear Rewinder Kit
(Included with option only)
1
1
1
4/2
1
1
1
1
2
8/8
2/2
Quantity Picture
12 - 3/16"screw (M5 10mm).
12 - Spring Washer( 5.1)
(Included with option only) 12/12
AC 220~240V, 50/60Hz, Single phase
