Owner’s Manual
© 2022 Roland Corporation
Before using the unit, ensure that its system program is at the most recent version. For information on available upgrades for the system program,
see the Roland website (https://proav.roland.com/).
DMX conguration software
You can congure the DMX channels by
connecting this unit to a computer that’s running
DMX conguration software. For details, refer to
“Using VC-1-DMX conguration software” (Web).
1. Visit the following website on your computer
or other device.
https://proav.roland.com/manuals/
2. Choose “VC-1-DMX” as the product name.
“Before using this unit, carefully read “USING THE UNIT SAFELY” and “IMPORTANT NOTES” (the leaet “USING THE UNIT SAFELY” and the Owner’s
Manual (p. 6)). After reading, keep the document(s) where it will be available for immediate reference.
VIDEO LIGHTING CONVERTER
VC-1-DMX
Checking the Included Items
Check that all of the included items are present.
If any of the included items are missing, contact your
dealer.
ÂVC-1-DMX unit
ÂAC adaptor
ÂPlug holder
ÂRubber foot x 4
ÂOwner’s Manual
ÂLeaet “USING THE UNIT
SAFELY”
2
ÃAttaching the plug holder
Use the plug holder to stabilize the adaptor and
prevent the plug from accidentally coming loose.
To attach the plug holder, rst remove the screw just
above the DC IN jack, align the plug holder as shown
in the illustration below and then use the screw you
just removed to ax the plug holder onto the unit.
Panel Descriptions
Front Panel
1 POWER indicator
Once you connect the AC adaptor, this unit powers
up and the POWER indicator lights up red.
2 USB port
You can congure the DMX channels by connecting this
to a computer on which dedicated software is installed.
The dedicated software for use with this unit can be
downloaded from the Roland website.
https://roland.cm/VC-1-DMX/
3 SETTING switches
Use a thin pen tip or other such tool to congure
the operation settings. For the values, refer to
“Conguring the Operation Settings” (p. 4).
4 HDMI IN connector
Connect an HDMI source device such as a computer
or BD player for video input. Video signals up to a
resolution of full HD (1080/60p) can be input. HDCP-
protected video can also be input.
5 HDMI THRU connector
Outputs the video signal input from the HDMI IN
connector as-is. Connect a device that receives HDMI
video here, such as a TV monitor.
ÃAttaching the rubber feet
This unit can be placed on a table or other surface,
and you can use screws or bands to ax it to a wall
or other at place for use.
When placing the unit on a table, attach the included
rubber feet in the places shown in the illustration
before use.
* When turning the unit over, handle the unit
carefully; do not drop it.
Rear Panel
1 DC IN jack
Connect the included AC adaptor here. Use only
the AC adaptor that came with this unit.
2 AUDIO IN/OUT jacks
Connect an audio device.
3 MIDI IN connector
You can connect a device here that outputs MIDI,
to control DMX lighting from that external MIDI
device.
4 DMX OUT 5-pin connector/3-pin connector
These are output connectors for DMX signals.
Use either the 5-pin or the 3-pin connector,
depending on what DMX lighting equipment
you are using.
* Pin assignment of DMX OUT connectors
1 2 3 4 5
To AC outlet
1 2 3 4
ÃGround terminal
Connect this to an
external earth or
ground. This should
be connected when
necessary.
2: Data–
1: GND
3: Data+
1: GND
2: Data–
3: Data+
Plug holder
3
Connection Example
Basic Operations
Turning the Power On
* To prevent malfunction and equipment failure,
always turn down the volume, and turn o all the
units before making any connections.
1. Mute the audio output of the devices
connected to this unit.
2. Connect the included adaptor to the DC IN jack
of this unit, and plug the adaptor into an AC
outlet.
This turns the power on.
3. Adjust the volume of the external devices.
Turning the Power O
1. Mute the audio output of the external devices.
2. Disconnect this unit’s adaptor from the power
outlet, and turn o the power of this unit.
NOTE
Before turning the unit on/o, always be sure to
turn the volume down. Even with the volume
turned down, you might hear some sound when
switching the unit on/o. However, this is normal
and does not indicate a malfunction.
* Do not use a USB cable that is designed only for
charging a device. Charge-only cables cannot
transmit data.
DMX-compatible lighting
equipment
MIDI device
Audio input/output device
Computer for conguring DMX channels Video source device Display for video output
