Operator’s Manual
RC2177 / RC2267 / RC2277/
RC2377 / RC2387 / RC2405
Impact Wrench
WARNING
To reduce risk of injury, everyone using, installing, repairing, maintaining,
changing accessories on, or working near this tool must read and
understand these instructions, as well as separately provided safety
instructions part number 8956000026, before performing any such task.
8956000112 REV 05 - 07/2018
Fig. 1
Fig. 2 Fig. 3
Air Diagram:
Model
Drive
Torque
Speed Dimension
Air consumption
Weight Inner hose
diameter Air inlet
Sound
pressure
LpA
Sound
power
LwA
Vibrations
Working Max Average @ load a k
L
W
H
1 2 3 4 5 6 7 8 9 10 11
in. ft.lbs
N.m
ft.lbs
N.m min-1 in.
mm
SCFM
Nl/s
lbs
kg
in.
mm in. dB(A) dB(A) m/s² m/s²
RC2177 3/8" 27-190
37-258
428
580 8200 6.5*6.7*1.3
165*170*59
5.9
2.7
17.2
7.8
2.86
1.3
3/8"
10 1/4" FT 90 101 7.9 2.5
RC2267 1/2" 16-276
22-374
487
660 10200 6.5*6.7*1.3
165*170*59
6.6
3
18.7
8.5
2.86
1.3
3/8"
10 1/4" FT 93 104 6.9 2
RC2277 1/2" 46-540
62-732
"922
1250" 8200 7.6*7.4*2.8
194*188*70
9
4.1
27.9
12.7
4.4
2.0
3/8"
10 1/4" FT 93 104 9.7 2.6
RC2377 3/4" 172-1026
234-1391
"1438
1950" 5760 9.1*7.9*3.3
230*200*84
8.3
3.8
35.6
16.2
7.7
3.5
1/2"
13 3/8" FT 97 108 14.5 6.7
RC2387 3/4" 147-1007
199-1366
"1438
1950" 5760 11.9*7.9*3.3
302*200*84
8.3
3.8
35.6
16.2
8.36
3.8
1/2"
13 3/8" FT 97 108 14.5 6.7
RC2405 1" 128-782
174-1061
"1438
1950" 5760 9.3*7.9*3.3
237*200*84
8.3
3.8
35.6
16.2
7.92
3.6
1/2"
13 3/8" FT 97 108 14.5 6.7
HA
B
LW
8 bar
114 PSI
40168574) (1/4”)
40168576) (1/2”)
40168575) (1/4”)
40168577) (1/2”)
8951011861 (1l)
8951011784 (1/4” AG)
8951011786 (1/2” AG)
START
Max.
Min.
8951011796 (Ø9)
8951011791 (Ø9)
8951011796 (Ø9)
8951011836 (Ø9)
30 to 50 cm hose
8951011836
8951011831 (Ø8x5m)
8951011833 (Ø8x8m)
8951011835 (Ø8x10m)
1.Technical Data
Model
Drive Torque Free speed Dimension
L x W x H
Air Consumption Weight Inner Hose Dia. Air Inlet
Sound pressure
LpA
Sound power
LwA
Vibrations
Working Max Average at load ahd K
W
L
1 2 3 4 5 6 7 8 9 10
[inch] [ft.lbs]
[Nm]
[ft.lbs]
[Nm] [min-1] [inch]
[mm]
[Nl/s]
[SCFM]
[kg]
[lb]
[inch]
[mm] [inch] [dB(A)] [dB(A)] [m/s²] [m/s²]
max. pressure 6.3bar(90psi)
ah : Vibration level, Uncertainty ; k L
pA
Sound pressure dB(A), KpA K= WA = 3 dB Uncertainty.
Declaration of noise and vibration statement (ISO 15744 and ISO 28927-2)
All values are current as of the date of this publication. For the latest information please visit www.rodcraft.com.
These declared values were obtained by laboratory type testing in accordance with the stated standards and are suitable for comparison with the declared
values of other tools tested in accordance with the same standards. These declared values are not adequate for use in risk assessments and values measured
in individual work places may be higher. The actual exposure values and risk of harm experienced by an individual user are unique and depend upon the way
the user works, the workpiece and the workstation design, as well upon the exposure time and the physical condition of the user. We, RODCRAFT PNEUMATIC
TOOLS , cannot be held liable for the consequences of using the declared values, instead of values reecting the actual exposure, in an individual risk
assessment in a work place situation over which we have no control. This tool may cause hand-arm vibration syndrome if its use is not adequately managed.
An EU guide to managing hand-arm vibration can be found at www. pneurop.eu/uploads/documents/pdf/PN3-02-NV_Declaration_info_sheet_0111.pdf. We
recommend a programme of health surveillance to detect early symptoms which may relate to noise or vibration exposure, so that management procedures can
be modied to help prevent future impairment.
2. Machine type(s)
• This product is designed for installing and removing threaded fasteners in wood, metal and plastic. No other use permitted. For professional use only.
• Please read the instructions carefully before starting the machine.
3. Operation
• Fix the accessories properly to the tool.
• Connect device as shown in Fig. 01 to a clean and dry air supply.
• To start the machine, pull the trigger (A). Machine speed is increase by increasing pressure on the trigger. Release the trigger to stop.
• To switch rotation, turn the switch (B) as shown in Fig. 03.
• Use the reverse switch (B) only when the drive spindle comes to a complete stop. Changing the speed before the drive spindle stops may damage the
machine.
• To adjust output power, turn the regulator (B).
4. Lubrication
Motor Clutch
• Use an air line lubricator with SAE #10 oil, adjusted to two drops per minute. If an air line
lubricator cannot be used, add air motor oil to the inlet once a day.
Recommended lubricant : 8951011861
• Use synthetic clutch Grease 8951012205
Model qty
3/8" RC2177 6.6 g / 0.23 oz
1/2" RC2267 10.8 g / 0.38 oz
1/2" RC2277 10.8 g / 0.38 oz
3/4" RC2377 20.6 g / 0.72 oz
3/4" RC2387 20.6 g / 0.72 oz
1" RC2405 20.6 g / 0.72 oz
5. Maintenance instruction
• Follow local country environmental regulations for safe handling and disposal of all components.
• Maintenance and repair work must be carried out by qualified personnel using only original spare parts. Contact the manufacturer or your nearest authorised
dealer for advice on technical service or if you require spare parts.
• Always ensure that the machine is disconnected from energy source to avoid accidental operation.
• Disassemble and inspect the tool every three 3 months if the tool is used every day. Replace damaged or worn parts.
• High wear parts are underlined in the parts list.
• To keep downtime to a minimum, the following service kits are recommended :
Tune-Up Kit : see part list
6. Disposal
• The disposal of this equipment must follow the legislation of the respective country.
• All damaged, badly worn or improperly functioning devices MUST BE TAKEN OUT OF OPERATION.
• Repair only by technical maintenance staff.
7. EC Declaration of conformity
We : Rodcraft Customer Center Langemarckstr.35 bis 45141 Essen- Germany
Machine type(s) : impact wrench
Declare that the product(s) : RC2177/RC2267/RC2277/RC2377/RC2387/RC2405 Serial Number : 001 -999
Origin of the product : Taiwan
is in conformity with the requirements of the council Directives on the approximation of the laws of the Member States relating : to “Machinery“ 2006/42/EC (17/05/2006)
applicable harmonised standard(s) : EN ISO 11148-6:2012
Name and position of issuer : Pascal Roussy (R&D Manager)
Place & Date : Saint-Herblain, 05/07/2018
Technical le available from EU headquarter. Pascal Roussy R&D manager CP Technocenter 38, rue Bobby Sands - BP10273 44800 Saint Herblain - France
Copyright 2018, Rodcraft
All rights reserved. Any unauthorized use or copying of the contents or part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers and drawings.
Use only authorized parts. Any damage or malfunction caused by the use of unauthorized parts is not covered by Warranty or Product Liability.
Original Instructions
EN English (English)
