RFKHD9813

1998 - 2013

HARLEY-DAVIDSON

AMPLIFIER INSTALL KIT

Installation & Operation

Serial Number: Date of Purchase:

Installation assistance availible at:

www.rockfordfosgate.com/rftech

R O C K F O R D F O S G A T E . C O M

600 South Rockford Drive • Tempe, Arizona 85281 United States

Direct: (480) 967-3565 • Toll Free: (800) 669-9899

Dear Customer,

Congratulations on your purchase of the world’s ﬁnest brand of audio

products. At Rockford Fosgate we are fanatics about musical reproduc-

tion at its best, and we are pleased you chose our product. Through

years of engineering expertise, hand craftsmanship and critical testing

procedures, we have created a wide range of products that reproduce

music with all the clarity and richness you deserve.

For maximum performance we recommend you have your new Rockford

Fosgate product installed by an Authorized Rockford Fosgate Dealer,

as we provide specialized training through Rockford Technical Training

Institute (RTTI). Please read your warranty and retain your receipt and

original carton for possible future use.

Great product and competent installations are only a piece of the puzzle

when it comes to your system. Make sure that your installer is using

100% authentic installation accessories from Rockford Fosgate in your

installation. Rockford Fosgate has everything from RCA cables and

speaker wire to power wire and battery connectors. Insist on it! After all,

your new system deserves nothing but the best.

To add the ﬁnishing touch to your new Rockford Fosgate image order

your Rockford accessories, which include everything from T-shirts to

hats.

Visit our web site for the latest information on all Rockford products;

www.rockfordfosgate.com

or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all other

countries, call +001-480-967-3565 or FAX +001-480-966-3983.

Table of Content

If, after reading your manual, you still have questions regarding this prod-

uct, we recommend that you see your Rockford Fosgate dealer. If you need

further assistance, you can call us direct at . Be sure to 1-800-669-9899

have your serial number, model number and date of purchase available

when you call.

Safety

This symbol with “WARNING” is intended

to alert the user to the presence of important

instructions. Failure to heed the instructions

will result in severe injury or death.

This symbol with “CAUTION” is intended to

alert the user to the presence of important

instructions. Failure to heed the instructions

can result in injury or unit damage.

• To prevent injury and damage to the unit, please read and follow the

instructions in this manual. We want you to enjoy this system, not get

a headache.

• If you feel unsure about installing this system yourself, have it installed

by a qualiﬁed Rockford Fosgate technician.

• Before installation, disconnect the battery negative (-) terminal to

prevent damage to the unit, ﬁre and/or possible injury.

Introduction

Corporation in the United States and/or other countries. Ultra Classic ®, Electra Glide®, Street Glide®, Tri Glide®, Road Glide®, Road Glide Ultra®, CVOTM and

Harley-Davidson® are registered trademarks of Harley-Davidson, Inc, and if used or implied are for reference only. There is no afﬁliation between Harley-

Davidson, Inc., and Rockford Corporation. All other trademarks are the property of their respective owners. Speciﬁcations subject to change without notice.

PRACTICE SAFE SOUND

Continuous exposure to sound pressure levels over 100dB may cause

permanent hearing loss. High powered auto sound systems may

produce sound pressure levels well over 130dB. Use common sense

and practice safe sound.

2 Introduction

3 Speciﬁcations

4-5 Design Features

6Wiring Diagram

7Installation Considerations

7-9 Installation

Ultra Classic®
