Seite 1/8
Installation & Operation
Serial Number: Date of Purchase:
PM262 PM262B PM262X• •
PM2652 PM2652B PM2652X• •
PM282 PM282B PM282X• •
®
SPEAKERS
Installation assistance available at:
www.rockfordfosgate.com/rftech
R O C K F O R D F O S G AT E . C O M
600 South Rockford Drive • Tempe, Arizona 85281 United States
Direct: (480) 967-3565 • Toll Free: (800) 669-9899
2
Dear Customer,
Congratulations on your purchase of the world’s finest brand of audio
products. At Rockford Fosgate we are fanatics about musical reproduc-
tion at its best, and we are pleased you chose our product. Through
years of engineering expertise, hand craftsmanship and critical testing
procedures, we have created a wide range of products that reproduce
music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new Rockford
Fosgate product installed by an Authorized Rockford Fosgate Dealer,
as we provide specialized training through Rockford Technical Training
Institute (RTTI). Please read your warranty and retain your receipt and
original carton for possible future use.
Great product and competent installations are only a piece of the puzzle
when it comes to your system. Make sure that your installer is using
100% authentic installation accessories from Rockford Fosgate in your
installation. Rockford Fosgate has everything from RCA cables and
speaker wire to power wire and battery connectors. Insist on it! After all,
your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image, order
your Rockford accessories, which include everything from T-shirts to
hats.
Visit our web site for the latest information on all Rockford products;
www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all other
countries, call +001-480-967-3565 or FAX +001-480-966-3983.
Table of Content
If, after reading your manual, you still have questions regarding this prod-
uct, we recommend that you see your Rockford Fosgate dealer. If you need
further assistance, you can call us direct at . Be sure to 1-800-669-9899
have your serial number, model number and date of purchase available
when you call.
Safety
This symbol with “WARNING” is intended
to alert the user to the presence of important
instructions. Failure to heed the instructions
will result in severe injury or death.
This symbol with “CAUTION” is intended to
alert the user to the presence of important
instructions. Failure to heed the instructions
can result in injury or unit damage.
• To prevent injury and damage to the unit, please read and follow the
instructions in this manual. We want you to enjoy this system, not get
a headache.
• If you feel unsure about installing this system yourself, have it installed
by a qualified Rockford Fosgate technician.
• Before installation, disconnect the battery negative (-) terminal to
prevent damage to the unit, fire and/or possible injury.
Introduction
©2015 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE, PUNCH ® and associated logos where applicable are registered trademarks of Rockford
Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Specifications subject to change without notice.
2 Introduction
3-4 Specifications
5 Installation
Installation Considerations
Mounting
6-7 Additional Languages
French
Spanish
German
Italian
8 Limited Warranty Information
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB may cause
permanent hearing loss. High powered auto sound systems may
produce sound pressure levels well over 130dB. Use common sense
and practice safe sound.
PRATIQUEZ UNE ÉCOUTE SANS RISQUES
Une exposition continue à des niveaux de pression acoustique upérieurs à
100 dB peut causer une perte d’acuité auditive permanente. Les systèmes
audio de forte puissance pour auto peuvent produire des niveaux de
pression acoustique bien au-delà de 130 dB. Faites preuve de bon sens et
pratiquez une écoute sans risques
PRACTIQUE EL SONIDO SEGURO
El contacto continuo con niveles de presión de sonido superiores a 100
dB puede causar la pérdida permanente de la audición. Los sistemas de
sonido de alta potencia para automóviles pueden producir niveles de
presión de sonido superiores a los 130 dB. Aplique el sentido común y
practique el sonido seguro.
PRAKTIZIEREN SIE SICHEREN SOUND
Fortgesetzte Geräuschdruckpegel von über 100 dB können beim
Menschen zu permanentem Hörverlust führen. Leistungsstarke
Autosoundsysteme können Geräuschdruckpegel erzeugen, die weit über
130 dB liegen. Bitte wenden Sie gesunden Menschenverstand an und
praktizieren Sie sicheren Sound.
OSSERVATE LE REGOLE DEL SUONO SENZA PERICOLI
La costante esposizione a livelli di pressione acustica al di sopra dei
100dB possono causare la perdita permanente dell’udito. I sistemi
audio ad alta potenza possono produrre livelli di pressione acustica ben
superiori ai 130dB. Si consiglia il buon senso e l’osservanza delle regole
del suono senza pericoli
3
Specifications
Model PM262 PM262B PM262X PM2652 PM2652B PM2652X PM282 PM282B PM282X
Nominal Diameter - inch
(mm)
6
(152)
6
(152)
6
(152)
6.5
(165)
6.5
(165)
6.5
(165)
8
(203)
8
(203)
8
(203)
Description 2-Way 2-Way 2-Way 2-Way 2-Way 2-Way 2-Way 2-Way 2-Way
Nominal Impedance (Ohms) 4Ω 4Ω 4Ω 4Ω 4Ω 4Ω 4Ω 4Ω 4Ω
Frequency Response (Hz) 53-22kHz 53-22kHz 53-22kHz 49-22kHz 49-22kHz 49-22kHz 48-22kHz 48-22kHz 48-22kHz
Voice Coil Diameter - inch
(mm)
1.0
(25.4)
1.0
(25.4)
1.0
(25.4)
1.0
(25.4)
1.0
(25.4)
1.0
(25.4)
1.25
(32.3)
1.25
(32.3)
1.25
(32.3)
Power Handling - Watts
(RMS/Peak) 75/150 75/150 75/150 85/170 85/170 85/170 100/200 100/200 100/200
Fs - Free Air Resonance (Hz) 60 60 60 65.5 65.5 65 50 50 50
Qts 0.64 0.64 0.64 0.79 0.79 0.80 0.53 0.53 0.53
Vas - cu. ft.
(Liter)
0.445
(12.6)
0.445
(12.6)
0.445
(12.6)
0.417
(11.8)
0.417
(11.8)
0.417
(11.8)
1.06
(30)
1.06
(30)
1.06
(30)
Sensitivity (1W/1M) 88dB 88dB 88dB 89dB 89dB 89dB 90dB 90dB 90dB
Sensitivity (2.83V/1M) 91dB 91dB 91dB 92dB 92dB 92dB 93dB 93dB 93dB
Xmax - inch
(mm)
0.2
(5)
0.2
(5)
0.2
(5)
0.2
(5)
0.2
(5)
0.2
(5)
0.28
(7)
0.28
(7)
0.28
(7)
Mounting Diameter 5.2
(131)
5.2
(131)
5.2
(131)
5.3
(136)
5.3
(136)
5.3
(136)
7.1
(180)
7.1
(180)
7.1
(180)
Mounting Depth 2.8
(71)
2.8
(71)
2.8
(71)
2.8
(72)
2.8
(72)
2.8
(72)
3.4
(87)
3.4
(87)
3.4
(87)
Grille/Trim Ring YES YES YES YES YES YES YES YES YES
See page 4 for additional dimensions
CEA 2031
Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards. This means your speaker has the capacity to handle
power under continuous demand, not instantaneous power handling that over time can damage voice coils.
VERIFIED WITH KLIPPEL
To adorn the ‘Verified with Klippel’ mark, the qualifying company’s loudspeaker engineering personnel must be trained and certified by
Klippel prior to using the three separate Klippel systems to design, develop and test. Rockford Fosgate has made the investment in Klippel to
deliver the best possible speakers and subwoofers to their customers.

Produktspezifikationen
