Seite 1/8
Installation &
Operation
Installation et fonctionnement
Instalación y funcionamiento
Einbau und Betrieb
Installazione e funzionamento
Punch Series
Loaded Enclosures
PL1-110
PL1-210
PL1-112
PL1-212
PL2-110
PL2-210
PL2-112
PL2-212
PL3-110
PL3-210
PL3-112
PL3-212
INSTALLATION ENGLISH
CAUTION: Before installation, disconnect the battery negative (-) terminal to prevent damage to the unit, fire and/or possible injury.
Run the speaker cable from the amp.When routing the speaker cable from the amplier, avoid running it close to any sources of high current
(wiring harnesses).The positive (+) speaker output from the amp connects to the red terminal of the enclosure, and the negative (-) connects to the
black terminal.
INSTALACN ESPAÑOL
PRECAUCIÓN: Antes de la instalación, desconecte el terminal negativo de la batería (-) para prevenir daño a la unidad, incendio
y/o posibles lesiones.
Recorrido del Cable de Altavoz Desde el Amplicador. Al llevar el cable de altavoz desde el amplicador, evite que pase cerca de cualquier
fuente de alto corriente (cables de alimentacion). El terminal positive (+) de las salida de rojo, y el terminal negativo (-) al terminal negro.
INSTALLATION FRANÇAIS
MISE EN GARDE : avant d'entamer l'installation, connectez la broche négative (-) de la batterie pour éviter tout risque de
blessures, d’incendie ou de dommages à l'appareil.
Branchement du câble du haut-parleur de l’amplicateur. En plaçnt le câble du haut-parleur de l’ampli, éviter de l’approcher d’une source
de courant important. La sortie positive de l’ampli se branche sur le terminal rouge du caisson, et le gatif se branche sur le terminal noir.
EINBAU DEUTSCH
VORSICHT: Entfernen Sie vor dem Einbau den negative Batteriepol, um Scden am Get, Feuer bzw. gliche Verletzungen zu
vermeiden.
Anschluß des Lautsprecherkabels. Beim Anschluß des Lautsprecherkables sollten Sie darauf achten, daß das Kabel keine Fahrzeugstromkabel
kreuzt, um Einsteuungen zu verhindern. Die Plus-Leitung des Lautsprecherkabels kommt in die rote Klemme des Terminals, die Negativ-Leitung in die
schwarze Klemme des Terminals.
INSTALLAZIONE ITALIANO
ATTENZIONE: Prima dell’installazione, scollegate il terminale negativo (-) della batteria per evitare danni all’unità,
pericoli d’incendio e/o potenziali lesioni personali.
Far correre il cavo dell’altoparlante all’amplicatore. Quando fate correre il cavo dell’altoparlante all’amplicatore non
fatelo passare vicino a qualsiasi cavo dell’impianto elettrico di serie dell’auto. Il segnale positivo dell’altoparlante (+) in uscita dall’amplicatore á col-
legato al terminale rosso del diusore, e il negativo (-) al terminale nero.
Strip 5/8"
(16mm)
Amplifier 4Ω Mono
Amplificador 4Ω Mono
Amplificateur de 4Ω Mono
Amplifier 4Ω Mono
Amplicatore 4Ω Mono
Black
Negro
Noir
Schwarz
Nero
Red
Rojo
Rouge
Rot
Rosso
Black
Negro
Noir
Schwarz
Nero
Red
Rojo
Rouge
Rot
Rosso
FEATURES
SPECIFICATIONS
Vented Enclosure Features
Proprietary High-Flow, Low-Noise Ports
High Current Binding Posts
Constructed with 5/8" MDF
Covered with High Density Carpet
Wired Exclusively with Connecting Punch
Speaker Features - SVC (Single Voice Coil)
Parabolic Injection Molded Polypropylene Cone
2" Voice Coil
Steel Basket with Pre-removed Motor Cover
30 and 60oz. Motor Structures
Linear Spider
Speaker Features - DVC (Dual Voice Coil)
Parabolic Injection Molded Polypropylene Cone
2.5" Aluminum Voice Coil Former
Cast Aluminum Basket with Spider Venting
77 and 102oz. Double Stacked Motor Structures
Linear Spider
Specifications subject to change without notice
PL1-110 (Single 10" SVC)
Nominal Impedance (Ohms) 4
Power Handling (Watts-RMS/Peak) 150 / 300
Internal Box Volume (ft3/liter) 1.05 (29.73L)
Overall Dimensions (HxWxD) 13.5” x 17.25” x 16”
(cm) (34.3 x 43.8 x 40.6)
PL1-210 (Dual 10" SVC)
Nominal Impedance (Ohms) 4 (8x2)
Power Handling (Watts-RMS/Peak) 300 / 600
Internal Box Volume (ft3/liter) 2.10 (59.46L)
Overall Dimensions (HxWxD) 13.5” x 31.25” x 16”
(cm) (34.3 x 81.9 x 40.6)
PL1-112 (Single 12" SVC)
Nominal Impedance (Ohms) 4
Power Handling (Watts-RMS/Peak) 150 / 300
Internal Box Volume (ft3/liter) 1.35 (38.23L)
Overall Dimensions (HxWxD) 15.5” x 19.25” x 16.5”
(cm) (39.4 x 48.9 x 41.9)
PL1-212 (Dual 12" SVC)
Nominal Impedance (Ohms) 4 (8x2)
Power Handling (Watts-RMS/Peak) 300 / 600
Internal Box Volume (ft3/liter) 2.70 (59.46L)
Overall Dimensions (HxWxD) 15.5” x 34” x 16.5
(cm) (39.4 x 86.4 x 41.9)
PL2-110 (Single 10" SVC)
Nominal Impedance (Ohms) 4
Power Handling (Watts-RMS/Peak) 200 / 400
Internal Box Volume (ft3/liter) 1.05 (29.73L)
Overall Dimensions (HxWxD) 13.5” x 17.25” x 16”
(cm) (34.3 x 43.8 x 40.6)
PL2-210 (Dual 10" SVC)
Nominal Impedance (Ohms) 4 (8x2)
Power Handling (Watts-RMS/Peak) 400 / 800
Internal Box Volume (ft3/liter) 2.10 (59.46L)
Overall Dimensions (HxWxD) 13.5” x 31.25” x 16”
(cm) (34.3 x 81.9 x 40.6)
PL2-112 (Single 12" SVC)
Nominal Impedance (Ohms) 4
Power Handling (Watts-RMS/Peak) 200 / 400
Internal Box Volume (ft3/liter) 1.35 (38.23L)
Overall Dimensions (HxWxD) 15.5” x 19.25” x 16.5”
(cm) (39.4 x 48.9 x 41.9)
PL2-212 (Dual 12" SVC)
Nominal Impedance (Ohms) 4 (8x2)
Power Handling (Watts-RMS/Peak) 400 / 800
Internal Box Volume (ft3/liter) 2.70 (59.46L)
Overall Dimensions (HxWxD) 15.5” x 34” x 16.5
(cm) (39.4 x 86.4 x 41.9)
PL3-110 (Single 10" DVC)
Nominal Impedance (Ohms) 4 (2x2)
Power Handling (Watts-RMS/Peak) 400 / 800
Internal Box Volume (ft3/liter) 1.05 (16.99L)
Overall Dimensions (HxWxD) 13.5” x 17.25” x 16”
(cm) (34.3 x 43.8 x 40.6)
PL3-210 (Dual 10" DVC)
Nominal Impedance (Ohms) 4 (8x2)
Power Handling (Watts-RMS/Peak) 800 / 1600
Internal Box Volume (ft3/liter) 2.10 (59.46L)
Overall Dimensions (HxWxD) 13.5” x 31.25” x 16”
(cm) (34.3 x 81.9 x 40.6)
PL3-112 (Single 12" DVC)
Nominal Impedance (Ohms) 4 (2x2)
Power Handling (Watts-RMS/Peak) 500 / 1000
Internal Box Volume (ft3/liter) 1.35 (38.23L)
Overall Dimensions (HxWxD) 15.5” x 19.25” x 16.5”
(cm) (39.4 x 48.9 x 41.9)
PL3-212 (Dual 12" DVC)
Nominal Impedance (Ohms) 4 (8x2)
Power Handling (Watts-RMS/Peak) 1000 / 2000
Internal Box Volume (ft3/liter) 2.70 (59.46L)
Overall Dimensions (HxWxD) 15.5” x 34” x 16.5
(cm) (39.4 x 86.4 x 41.9)
