Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Rockford Fosgate Punch PL1-112 (4 Seiten) in der Kategorie Speaker. Dieser Bedienungsanleitung war für 4 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet
Seite 1/4
Installation &
Operation
Installation et fonctionnement
Instalación y funcionamiento
Einbau und Betrieb
Installazione e funzionamento
Punch Series
Loaded Enclosures
PL1-110
PL1-210
PL1-112
PL1-212
PL2-110
PL2-210
PL2-112
PL2-212
PL3-110
PL3-210
PL3-112
PL3-212
INSTALLATION – ENGLISH
CAUTION: Before installation, disconnect the battery negative (-) terminal to prevent damage to the unit, fire and/or possible injury.
Run the speaker cable from the amp.When routing the speaker cable from the amplier, avoid running it close to any sources of high current
(wiring harnesses).The positive (+) speaker output from the amp connects to the red terminal of the enclosure, and the negative (-) connects to the
black terminal.
INSTALACIÓN – ESPAÑOL
PRECAUCIÓN: Antes de la instalación, desconecte el terminal negativo de la batería (-) para prevenir daño a la unidad, incendio
y/o posibles lesiones.
Recorrido del Cable de Altavoz Desde el Amplicador. Al llevar el cable de altavoz desde el amplicador, evite que pase cerca de cualquier
fuente de alto corriente (cables de alimentacion). El terminal positive (+) de las salida de rojo, y el terminal negativo (-) al terminal negro.
INSTALLATION – FRANÇAIS
MISE EN GARDE : avant d'entamer l'installation, déconnectez la broche négative (-) de la batterie pour éviter tout risque de
blessures, d’incendie ou de dommages à l'appareil.
Branchement du câble du haut-parleur de l’amplicateur. En plaçnt le câble du haut-parleur de l’ampli, éviter de l’approcher d’une source
de courant important. La sortie positive de l’ampli se branche sur le terminal rouge du caisson, et le négatif se branche sur le terminal noir.
EINBAU – DEUTSCH
VORSICHT: Entfernen Sie vor dem Einbau den negative Batteriepol, um Schäden am Gerät, Feuer bzw. mögliche Verletzungen zu
vermeiden.
Anschluß des Lautsprecherkabels. Beim Anschluß des Lautsprecherkables sollten Sie darauf achten, daß das Kabel keine Fahrzeugstromkabel
kreuzt, um Einsteuungen zu verhindern. Die Plus-Leitung des Lautsprecherkabels kommt in die rote Klemme des Terminals, die Negativ-Leitung in die
schwarze Klemme des Terminals.
INSTALLAZIONE – ITALIANO
ATTENZIONE: Prima dell’installazione, scollegate il terminale negativo (-) della batteria per evitare danni all’unità,
pericoli d’incendio e/o potenziali lesioni personali.
Far correre il cavo dell’altoparlante all’amplicatore. Quando fate correre il cavo dell’altoparlante all’amplicatore non
fatelo passare vicino a qualsiasi cavo dell’impianto elettrico di serie dell’auto. Il segnale positivo dell’altoparlante (+) in uscita dall’amplicatore á col-
legato al terminale rosso del diusore, e il negativo (-) al terminale nero.
Strip 5/8"
(16mm)
Amplifier 4Ω Mono
Amplificador 4Ω Mono
Amplificateur de 4Ω Mono
Amplifier 4Ω Mono
Amplicatore 4Ω Mono
Black
Negro
Noir
Schwarz
Nero
Red
Rojo
Rouge
Rot
Rosso
Black
Negro
Noir
Schwarz
Nero
Red
Rojo
Rouge
Rot
Rosso
FEATURES
SPECIFICATIONS
Vented Enclosure Features
• Proprietary High-Flow, Low-Noise Ports
• High Current Binding Posts
• Constructed with 5/8" MDF
• Covered with High Density Carpet
• Wired Exclusively with Connecting Punch
Speaker Features - SVC (Single Voice Coil)
• Parabolic Injection Molded Polypropylene Cone
• 2" Voice Coil
• Steel Basket with Pre-removed Motor Cover
• 30 and 60oz. Motor Structures
• Linear Spider
Speaker Features - DVC (Dual Voice Coil)
• Parabolic Injection Molded Polypropylene Cone
• 2.5" Aluminum Voice Coil Former
• Cast Aluminum Basket with Spider Venting
• 77 and 102oz. Double Stacked Motor Structures
• Linear Spider
Specifications subject to change without notice
PL1-110 (Single 10" SVC)
Nominal Impedance (Ohms) 4
Power Handling (Watts-RMS/Peak) 150 / 300
Internal Box Volume (ft3/liter) 1.05 (29.73L)
Overall Dimensions (HxWxD) 13.5” x 17.25” x 16”
(cm) (34.3 x 43.8 x 40.6)
PL1-210 (Dual 10" SVC)
Nominal Impedance (Ohms) 4 (8x2)
Power Handling (Watts-RMS/Peak) 300 / 600
Internal Box Volume (ft3/liter) 2.10 (59.46L)
Overall Dimensions (HxWxD) 13.5” x 31.25” x 16”
(cm) (34.3 x 81.9 x 40.6)
PL1-112 (Single 12" SVC)
Nominal Impedance (Ohms) 4
Power Handling (Watts-RMS/Peak) 150 / 300
Internal Box Volume (ft3/liter) 1.35 (38.23L)
Overall Dimensions (HxWxD) 15.5” x 19.25” x 16.5”
(cm) (39.4 x 48.9 x 41.9)
PL1-212 (Dual 12" SVC)
Nominal Impedance (Ohms) 4 (8x2)
Power Handling (Watts-RMS/Peak) 300 / 600
Internal Box Volume (ft3/liter) 2.70 (59.46L)
Overall Dimensions (HxWxD) 15.5” x 34” x 16.5”
(cm) (39.4 x 86.4 x 41.9)
PL2-110 (Single 10" SVC)
Nominal Impedance (Ohms) 4
Power Handling (Watts-RMS/Peak) 200 / 400
Internal Box Volume (ft3/liter) 1.05 (29.73L)
Overall Dimensions (HxWxD) 13.5” x 17.25” x 16”
(cm) (34.3 x 43.8 x 40.6)
PL2-210 (Dual 10" SVC)
Nominal Impedance (Ohms) 4 (8x2)
Power Handling (Watts-RMS/Peak) 400 / 800
Internal Box Volume (ft3/liter) 2.10 (59.46L)
Overall Dimensions (HxWxD) 13.5” x 31.25” x 16”
(cm) (34.3 x 81.9 x 40.6)
PL2-112 (Single 12" SVC)
Nominal Impedance (Ohms) 4
Power Handling (Watts-RMS/Peak) 200 / 400
Internal Box Volume (ft3/liter) 1.35 (38.23L)
Overall Dimensions (HxWxD) 15.5” x 19.25” x 16.5”
(cm) (39.4 x 48.9 x 41.9)
PL2-212 (Dual 12" SVC)
Nominal Impedance (Ohms) 4 (8x2)
Power Handling (Watts-RMS/Peak) 400 / 800
Internal Box Volume (ft3/liter) 2.70 (59.46L)
Overall Dimensions (HxWxD) 15.5” x 34” x 16.5”
(cm) (39.4 x 86.4 x 41.9)
PL3-110 (Single 10" DVC)
Nominal Impedance (Ohms) 4 (2x2)
Power Handling (Watts-RMS/Peak) 400 / 800
Internal Box Volume (ft3/liter) 1.05 (16.99L)
Overall Dimensions (HxWxD) 13.5” x 17.25” x 16”
(cm) (34.3 x 43.8 x 40.6)
PL3-210 (Dual 10" DVC)
Nominal Impedance (Ohms) 4 (8x2)
Power Handling (Watts-RMS/Peak) 800 / 1600
Internal Box Volume (ft3/liter) 2.10 (59.46L)
Overall Dimensions (HxWxD) 13.5” x 31.25” x 16”
(cm) (34.3 x 81.9 x 40.6)
PL3-112 (Single 12" DVC)
Nominal Impedance (Ohms) 4 (2x2)
Power Handling (Watts-RMS/Peak) 500 / 1000
Internal Box Volume (ft3/liter) 1.35 (38.23L)
Overall Dimensions (HxWxD) 15.5” x 19.25” x 16.5”
(cm) (39.4 x 48.9 x 41.9)
PL3-212 (Dual 12" DVC)
Nominal Impedance (Ohms) 4 (8x2)
Power Handling (Watts-RMS/Peak) 1000 / 2000
Internal Box Volume (ft3/liter) 2.70 (59.46L)
Overall Dimensions (HxWxD) 15.5” x 34” x 16.5”
(cm) (39.4 x 86.4 x 41.9)
