Seite 1/4
1230-57454-03 Printed in China
Installation & Operation
M2 – WAKEBOARD TOWER PEAKERSS
M GA R I N E R A D E
6.5" 8"
M262-Wake M282-Wake
M262B-Wake M282B-Wake
Serial Number: Date of Purchase:
Rockford Corporation offers a limited warranty on Rockford Fosgate products on the following terms:
Length of Warranty
Speakers – 1 Year. Any Factory Refurbished Product – 90 days (receipt
required)
What is Covered
This warranty applies only to Rockford Fosgate products sold to consumers by Authorized Rockford Fosgate
Dealers in the United States of America or its possessions. Product purchased by consumers from an
Authorized Rockford Fosgate Dealer in another country are covered only by that country’s Distributor and
not by Rockford Corporation.
Who is Covered
This warranty covers only the original purchaser of Rockford product purchased from an Authorized
Rockford Fosgate Dealer in the United States. In order to receive service, the purchaser must provide
Rockford with a copy of the receipt stating the customer name, dealer name, product purchased and date of
purchase. Products found to be defective during the warranty period will be repaired or replaced
(with a product deemed to be equivalent) at Rockford's discretion.
What is Not Covered
1. Damage caused by accident, abuse, improper operations, water, theft, shipping
2. Any cost or expense related to the removal or reinstallation of product
3. Service performed by anyone other than Rockford or an Authorized Rockford Fosgate Service Center
4. Any product which has had the serial number defaced,altered, or removed
5. Subsequent damage to other components
6. Any product purchased outside the U.S.
7. Any product not purchased from anAuthorized Rockford Fosgate Dealer
Limit on Implied Warranties
Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the
period of the express warranty set forth above. Some states do not allow limitations on the length of an implied
warranty, so this limitation may not apply. No person is authorized to assume for Rockford Fosgate any other
liability in connection with the sale of the product.
How to Obtain Service
Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further
assistance, call 1-800-669-9899 for Rockford Customer Service.You must obtain an RA# (Return
Authorization number) to return any product to Rockford Fosgate.You are responsible for shipment
of product to Rockford.
EU Warranty
This product meets the current EU warranty requirements, see your Authorized dealer for details.
2012 Rockford Corporation. All Rights Reversed. ROCKFORD FOSGATE and associated logos where
applicable are registered trademarks of Rockford Corporation in the United States and/or other countries.
All other trademarks are the property of their respective owners. Specifications subject to change without
notice.
L WIMITED ARRANTY TATEMENTS
Check our website for additional information and
updates on these products.
www.RockfordFosgate.com
2
Before beginning any installation, follow these simple rules:
1. Be sure to carefully read and understand the instructions before attempting to
install these speakers.
2. For safety, disconnect the negative lead from the battery prior to beginning the
installation.
3. For easier assembly, we suggest you run all wires prior to mounting your speakers
in place.
4. Use high quality connectors for a reliable installation and to minimize signal or
power loss.
5. Think before you drill! Be careful not to cut or drill into gas tanks, fuel lines,
brake or hydraulic lines, vacuum lines or electrical wiring when working on any
vehicle. If installation in a boat, take care not to cut or drill through the main hull.
6. Never run wires in the open area of the boat. Running the wires inside the wake-
board tower and hull area provides the best protection.
7. Avoid running wires over or through sharp edges. Use rubber or plastic
grommets to protect any wires routed through metal.
1. Determine where the speakers will be mounted. Be sure that the mounting loca-
tion has sufficient clearance in all directions for the speaker to swivel; conduct a
full rotation to ensure there is no obstruction.
2. Mark the locations on the underside of the clamping surface for the speaker har-
ness to be feed through. Drill the holes with a 3/8" bit.
3. Feed the speaker wires through the hole and connect to the speaker harness. Be
sure to observe proper polarity when connecting the wires.The speaker harness's
negative wire is indicated with a "black-stripe".
4. Feed the speaker harness through the center of the base of the clamp. Fit the
clamp to the mounting area and tighten the bolts evenly with the supplied allen
wrench.
NOTE: Use the proper rubber insert for the corresponding clamping diameter.
SAFETY
CARTON ONTENTSC
CAUTION: Before installation, disconnect the battery
negative (-) terminal to prevent damage
to the unit, fire and/or possible injury.
PRACTICE SAFE SOUND™
Continuous exposure to sound pressure levels over 100dB may
cause permanent hearing loss. High powered auto sound systems
may produce sound pressure levels well over 130dB. Use common
sense and practice safe sound.
• (1) Set Marine Grade M2 Wakeboard Tower Speakers
• (1) Set of adjustable swivel clamps
• (1) Allen head wrench
• (1) Molex speaker harness
• (1) Set of rubber inserts for 1 1/2” - 1 3/4” applications
• (1) Set of rubber inserts for 1 7/8” - 2 3/4” applications
INSTALLATION ONSIDERATIONSC
MOUNTING
1 1/2"
Adjusts to fit
(3.81cm)
1 3/4"
(4.45cm)
1 7/8"
Adjusts to fit
(4.76cm)
2 3/4"
(6.99cm)
3
Specifications subject to change without notice
MARINE GRADE M2 6.5" 8"
M262-WAKE/M262B-WAKE M282-WAKE/M282B-WAKE
A- Overall height-inch 10.96 13.14
(cm) (27.83) (33.37)
B- Overall length-inch 11.26 13.10
(cm) (28.59) (33.25)
C- Overall diameter-inch 7.03 9.05
(cm) (11.85) (23.00)
D- Clamp Range-inch 1.5 to 2.75 1.5 to 2.75
(cm) (3.81 to 6.99) (3.81 to 6.99)
Mass (Weight) - lbs. 6.20 8.80
(kg) (2.80) (4.00)
Power handling-watts (RMS) 75 100
(Peak) 150 200
PHYSICAL IMENSIONSD
C
D
A
B
