DSR1
PRODUCT OVERVIEW & APP SETUP
Step 2 - Non Vehicle-Specific Installation
The DSR1 comes pre-programmed as follows:
ī˜ƒ ā€¢ī˜ƒ (4)ī˜ƒInputs
ī˜ƒ ā€¢ī˜ƒ (8)ī˜ƒActiveī˜ƒOutputs:ī˜ƒ
ī˜ƒ ī˜ƒ ī˜ƒ -ī˜ƒFrontī˜ƒ(L/R)ī˜ƒ
ī˜ƒ ī˜ƒ ī˜ƒ -ī˜ƒSpareī˜ƒ(L/R,ī˜ƒsignalī˜ƒderivedī˜ƒfromī˜ƒfrontī˜ƒinputs)ī˜ƒ
ī˜ƒ ī˜ƒ ī˜ƒ -ī˜ƒRearī˜ƒ(L/R)ī˜ƒ
ī˜ƒ ī˜ƒ ī˜ƒ -ī˜ƒSubī˜ƒ(L/R)
Subwooferī˜ƒisī˜ƒaī˜ƒsummingī˜ƒofī˜ƒallī˜ƒ4ī˜ƒinputī˜ƒchannels.ī˜ƒNoī˜ƒ
balance,ī˜ƒnoī˜ƒfade.ī˜ƒī˜ƒYouī˜ƒwillī˜ƒneedī˜ƒtoī˜ƒdownloadī˜ƒtheī˜ƒappī˜ƒifī˜ƒ
youī˜ƒwantī˜ƒtoī˜ƒreconī Œgureī˜ƒtheī˜ƒdeviceī˜ƒandī˜ƒtakeī˜ƒadvantageī˜ƒofī˜ƒ
theī˜ƒcustomī˜ƒaudioī˜ƒtuningī˜ƒcapabilities.ī˜ƒī˜ƒ
Step 3 - Download the App
Toī˜ƒtakeī˜ƒadvantageī˜ƒofī˜ƒtheī˜ƒfullī˜ƒDSR1ā€™sī˜ƒtuningī˜ƒcapabilities,ī˜ƒ
downloadī˜ƒtheī˜ƒRockford Fosgate PerfectTuneā„¢ī˜ƒapp,ī˜ƒ
designedī˜ƒtoī˜ƒrunī˜ƒonī˜ƒbothī˜ƒtabletsī˜ƒandī˜ƒmobileī˜ƒdevices.
Step 4 - App Setup & Tuning
Onceī˜ƒyouī˜ƒhaveī˜ƒtheī˜ƒappī˜ƒinstalledī˜ƒontoī˜ƒyourī˜ƒdevice,ī˜ƒtheī˜ƒ
setupī˜ƒprocessī˜ƒwillī˜ƒwalkī˜ƒyouī˜ƒthroughī˜ƒtheī˜ƒnecessaryī˜ƒstepsī˜ƒ
forī˜ƒpairingī˜ƒtheī˜ƒdeviceī˜ƒtoī˜ƒtheī˜ƒDSR1.ī˜ƒAfterī˜ƒtheī˜ƒpairingī˜ƒisī˜ƒ
complete,ī˜ƒtheī˜ƒappī˜ƒwillī˜ƒcontinueī˜ƒtoī˜ƒprovideī˜ƒinstructionī˜ƒtoī˜ƒ
ī Œnalizeī˜ƒtheī˜ƒdesiredī˜ƒaudioī˜ƒtuneī˜ƒforī˜ƒtheī˜ƒvehicle.
P COUTPU T
INPUTVEHICLE HIG H LOW
INPUT LEVEL
EXP
STATUS
USB
Output Harness
Punch Level Control
(sold separately)
USB Setup / Update Port Input Harness
Status Indicator
Expansion Port
Input Level Switch
Vehicle T-Harness
(sold separately)
Ifī˜ƒyouī˜ƒplanī˜ƒtoī˜ƒuseī˜ƒDSR1ī˜ƒinī˜ƒaī˜ƒMAESTROī˜ƒvehicle-speciī Œcī˜ƒinstallation,ī˜ƒproceedī˜ƒ
withī˜ƒstepsī˜ƒ1-3ī˜ƒbelow,ī˜ƒthenī˜ƒfollowī˜ƒMaestroī˜ƒprogrammingī˜ƒabove.
PerfectTuneā„¢ App
Step 1 - Update DSR1
Getī˜ƒtheī˜ƒlatestī˜ƒaudioī˜ƒfeaturesī˜ƒbyī˜ƒupdatingī˜ƒtheī˜ƒDSR1ī˜ƒat
www.rockfordfosgate.com/products/details/dsr1.
INPUTVEHICLE HIGH LOW
INPUT LEVEL
EXP
STATUS
USB
INPUTVEHICLE HIGH LOW
INPUT LEVEL
EXP
STATUS
USB
INPUTVEHICLE HIGH LOW
INPUT LEVEL
EXP
STATUS
USB
HIGH LOW
INPUT LEVEL
HIGH LOW
INPUT LEVEL
HIGH LOW
INPUT LEVEL
Aftermarket Amps
Battery (+)
FRONT LEFT IN 1
Back of Factory Amplifier
(typically under seat)
Vehicle CAN-BUS
DSR1 ā€œVehicleā€ Connector
FRONT RIGHT IN 2
REAR LEFT IN 3
REAR RIGHT IN 4
B+ (constant +12v)
Remote Input +12v
T-HARNESS
(sold separately)
Chassis Ground
Remote Output +12v
AUX IN LEFT
AUX IN RIGHT
SPDIF IN
BLUE
BLUE / WHITE
YELLOW
BLACK
FRONT LEFT IN 1
PREAMP OUTPUTS DSR1 INPUTSDSR1 INPUTS
FRONT RIGHT IN 2
REAR LEFT IN 3
REAR RIGHT IN 4
B+ (constant +12v)
Remote Input +12v
Chassis Ground
Remote Output +12v
AUX IN LEFT
AUX IN RIGHT
SPEAKER LINE OUTPUTS
Add BluetoothĀ® audio with
RFBTRCA (sold separately)
Add BluetoothĀ® audio with
RFBTRCA (sold separately)
SPDIF IN
BLUE
Remote Output +12v
BLUE
BLUE / WHITE
YELLOW
BLACK
Aftermarket Amps
Battery (+)
May be needed if radio
doesnā€™t turn-on DSR1
+
ā€“
+
ā€“
+
ā€“
+
ā€“
Factory Amplifier
Optional ā€œRFI2SWā€
Data Port Radio
DSR1
FLEXIBLE INPUT CONFIGURATIONS
Theī˜ƒDSR1ī˜ƒcanī˜ƒbeī˜ƒutilizedī˜ƒout-of-the-boxī˜ƒwithī˜ƒhigh-level,ī˜ƒlow-level,ī˜ƒorī˜ƒwithī˜ƒaī˜ƒT-harnessī˜ƒandī˜ƒvehicleī˜ƒ
speciī Œcī˜ƒī Œrmwareī˜ƒenablingī˜ƒintegrationī˜ƒwithoutī˜ƒlossī˜ƒofī˜ƒfactoryī˜ƒequippedī˜ƒcontrolsī˜ƒandī˜ƒfeatures.
illustrated by Eric Russell
Allowsī˜ƒforī˜ƒinstallationī˜ƒofī˜ƒaftermarketī˜ƒ
ampliī Œersī˜ƒwithī˜ƒvehicleī˜ƒspeciī Œcī˜ƒī Œrmwareī˜ƒ
andī˜ƒT-harnessī˜ƒwhileī˜ƒretainingī˜ƒfactoryī˜ƒ
radioī˜ƒcontrolsī˜ƒandī˜ƒfeatures.
FACTORY RADIO + T-HARNESS
Allowsī˜ƒforī˜ƒinstallationī˜ƒofī˜ƒaftermarketī˜ƒ
ampliī Œersī˜ƒinī˜ƒvirtuallyī˜ƒanyī˜ƒvehicleī˜ƒwithī˜ƒaī˜ƒ
factoryī˜ƒradioī˜ƒusingī˜ƒhigh-levelī˜ƒinputs.
FACTORY RADIO
Allowsī˜ƒforī˜ƒinstallationī˜ƒofī˜ƒaftermarketī˜ƒ
ampliī Œersī˜ƒinī˜ƒvirtuallyī˜ƒanyī˜ƒvehicleī˜ƒwithī˜ƒanī˜ƒ
aftermarketī˜ƒradioī˜ƒusingī˜ƒlow-levelī˜ƒinputs.
AFTERMARKET RADIO
IMPORTANT:
Followī˜ƒinstructionsī˜ƒī˜ƒ
onī˜ƒbackī˜ƒpageī˜ƒtoī˜ƒ
ī ashī˜ƒDSR1.
PLCOUTPUT INPUTVEHICLE HIGH LOW
INPUT LEVEL
EXP
STATUS
USB
PLC2
(sold separately)
FRONT LEFT - OUT1
FRONT RIGHT - OUT2
SPARE LEFT - OUT3
SPARE RIGHT - OUT4
REAR LEFT - OUT5
REAR RIGHT - OUT6
SUB LEFT - OUT7
SUB RIGHT - OUT8
LAPTOP
USB 2.0 Type B
USB SETUP / UPDATE PORT
USB 2.0 Micro-B 5-Pin
LED
EXPANSION PORT
Reserved For Future Use
VEHICLE PORT
Maestro T-Harness
INPUT LEVEL SWITCH
INPUT
(looking into wired end)
OUTPUT
(looking into wired end)
High => 4.1v RMS
Low <= 4.0v RMS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Black
Black
Black
Black
Black
Black
Black
Black
Red
White
Red
White
Red
White
Red
White
Right Sub (-)
Left Sub (-)
Right Rear (-)
Left Rear (-)
Right Spare (-)
Left Spare (-)
Right Front (-)
Left Front (-)
Right Sub (+)
Left Sub (+)
Right Rear (+)
Left Rear (+)
Right Spare (+)
Left Spare (+)
Right Front (+)
Left Front (+)
Pin Wire Function Pin Wire Function
16 15 14 13 12 11 10 9
8 7 6 5 4 3 2 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Orange/Black
Violet/Black
Green/Black
Black
Black
Gray/Black
White/Black
Blue/White
Black
Orange
Violet
Green
Red
White
Gray
White
Blue
Yellow
SPDIF In (-)
Right Rear (-)
Left Rear (-)
Right Aux In Shield
Left Aux In Shield
Right Front (-)
Left Front (-)
Remote Output
Ground
SPDIF In (+)
Right Rear (+)
Left Rear (+)
Right Aux In (+)
Left Aux In (+)
Right Front (+)
Left Front (+)
Remote In
B+ Constant
Pin Wire Function Pin Wire Function
18 17 16 15 14 13 12 11 10
9 8 7 6 5 4 3 2 1
COLOR SOLID BLINKING
White Device On ā€“
Blue BT/USB Connected BT/USB Activity
Red Memory/Device Error ā€“
Yellow B+ Undervoltage (<9V) B+ Overvoltage (>16V)
Green ā€“ Maestro Activity
Violet Boot Loader Error ā€“
Front
Full-Range
Rear
Full-Range
Rear
Subwoofers
Front
Mid-bass
DSR1
TYPICAL OUTPUT CONFIGURATION + PIN OUTS
Theī˜ƒall-in-oneī˜ƒdigitalī˜ƒsoundī˜ƒprocessorī˜ƒandī˜ƒampliī Œerī˜ƒreplacementī˜ƒinterfaceī˜ƒ
allowsī˜ƒforī˜ƒinstallationī˜ƒofī˜ƒaftermarketī˜ƒampliī Œersī˜ƒinī˜ƒvirtuallyī˜ƒanyī˜ƒvehicle.ī˜ƒ
illustrated by Eric Russell
