11/02 Printed in China MAN-4437-A
WARRANTY NFORMAITION
Connecting Punch
Rockford Corporation
546 South Rockford Drive
Tempe, AZ 85281 USA
USA, (480) 967-3565
Europe, Fax (49) 4207-8101250
Japan, Fax (81) 559-79-1265
CPPI150
CPPI300
CPPI300HW
Installation &
OPERAtion Manual
Rockford Fosgate offers a limited warranty with the following terms:
• Length of Warranty
One year parts and labor warranty.
Requires proof of purchase.
• What is Covered
This warranty applies only to Rockford Fosgate products sold to
consumers by Authorized Rockford Fosgate Dealers in the United
States of America or its possessions. Product purchased by
consumers from an Authorized Rockford Fosgate Dealer in another
country are covered only by that country’s Distributor and not by
Rockford Fosgate.
• Who is Covered
This warranty covers only the original purchaser of Rockford Fosgate
product purchased from an Authorized Rockford Fosgate Dealer in the
United States. In order to receive service, the purchaser must provide
Rockford Fosgate with a copy of the receipt stating the customer
name, dealer name, product purchased and date of purchase.
Products found to be defective during the warranty period will be
repaired or replaced (with a product deemed to be equivalent) at
Rockford Fosgate’s discretion.
• What is Not Covered
1. Damage caused by accident, abuse, improper operations, water,
theft
2. Any cost or expense related to the removal or reinstallation of
product
3. Service performed by anyone other than Rockford Fosgate or an
Authorized Rockford Fosgate Service Center
4. Any product which has had the serial number defaced, altered,
or removed
5. Subsequent damage to other components
6. Any product purchased outside the U.S.
7. Any product not purchased from an Authorized Rockford Fosgate
Dealer
• Limit on Implied Warranties
Any implied warranties including warranties of fitness for use and
merchantability are limited in duration to the period of the express
warranty set forth above. Some states do not allow limitations on the
length of an implied warranty, so this limitation may not apply. No
person is authorized to assume for Rockford Fosgate any other
liability in connection with the sale of the product.
• How to Obtain Service
Please call 1-800-669-9899 for Rockford Fosgate Customer Service.
You must obtain an RA# (Return Authorization number) to return
any product to Rockford Fosgate. You are responsible for shipment
of product to Rockford Fosgate. Always include Proof of Purchase.
Mark RA# on outside of shipping carton.
INTRODUCTION
Thank you for purchasing the Rockford Fosgate
Connecting Punch Power Inverter.
The Connecting Punch Power Inverters allow you to
power a variety of AC voltage devices from your
car, truck, boat or RV. Power 110 volt AC power
devices such as notebook computers, video game
consoles, and TVs directly from a 12 volt DC power
supply.
Please read, understand and follow all instructions
before connecting the Connecting Punch Power
Inverter. If, after reading your manual, you still have
questions regarding this product, we recommend
that you see your Rockford Fosgate dealer. If you
need further assistance, you can call us direct at
1-800-669-9899.
Model CPPI150
Output Connection 1 North American Standard
Receptacle
Output Voltage Approx. 110 Volts AC RMS 60Hz
Output Current 1.36 Amps RMS
Output Waveform Modified Rectangular Wave
Input Voltage Range 10.6 to 15.5 Volts DC
Low Voltage Alarm Voltage drops below 10.6 Volts DC
Low Voltage Shutdown Voltage drops below 9.6 Volts DC
No Load Input Current 0.3 Amps
Input Fuse 20 Amp AGU
Input Cable Hard Wired Lighter Plug
Additional Protection Overload, Over Voltage, Over Temp
Dimensions Length: 5.6" (142.2mm)
Width: 4.1" (104.1mm)
Height: 1.85" (47.0mm)
Model CPPI300
Output Connection 2 North American Standard
Receptacles
Output Voltage Approx. 110 Volts AC RMS 60Hz
Output Current 2.73 Amps RMS
Output Waveform Modified Rectangular Wave
Input Voltage Range 10.6 to 15.5 Volts DC
Low Voltage Alarm Voltage drops below 10.6 Volts DC
Low Voltage Shutdown Voltage drops below 9.6 Volts DC
No Load Input Current 0.3 Amps
Input Fuse 40 Amp AGU
Input Cable Lighter Plug and Battery Clip Adapter
Additional Protection Overload, Over Voltage, Over Temp
Dimensions Length: 7.5" (190.5mm)
Width: 4.1" (104.1mm)
Height: 1.85" (47.0mm)
Model CPPI300HW
Output Connection 2 North American Standard
Receptacles
Output Voltage Approx. 110 Volts AC RMS 60Hz
Output Current 2.73 Amps RMS
Output Waveform Modified Rectangular Wave
Input Voltage Range 10.6 to 15.5 Volts DC
Low Voltage Alarm Voltage drops below 10.6 Volts DC
Low Voltage Shutdown Voltage drops below 9.6 Volts DC
No Load Input Current 0.3 Amps
Input Fuse 40 Amp AGU
Input Cable Lighter Plug and Battery
Hard Wire Kit
Additional Protection Overload, Over Voltage, Over Temp
Dimensions Length: 7.5" (190.5mm)
Width: 4.1" (104.1mm)
Height: 1.85" (47.0mm)
SPECIFICATIONS
150 watt or 300 watt
12 volt DC to 110 volt AC
Power Inverter
S IAFETY NFORMATION
CAUTION: To prevent injury and damage to
the unit, please read and follow
the instructions in this manual.
CAUTION: If you feel unsure about installing
this system yourself, have it
installed by a qualified technician.
WARNING: To prevent serious personal injury,
fire, electrical shock and/or
damage, never connect the inverter
to an AC powered outlet.
Always unplug the appliance or
device from the inverter before
attempting any repairs to the
appliance or device.
Never connect the inverter to
places designated as IGNITION
PROTECTED.
CAUTION: Failure to observe the following
safety precautions could result in fire,
damage to the inverter, vehicle
and/or personal injury.
• DO NOT use with 6 or 24 volt DC systems or
positive ground electrical systems.
The majority of all vehicles are
negative ground.
• DO NOT use the inverter to operate high
wattage appliances or devices that
produce heat, such as hair dryers,
heaters, toasters, microwave ovens,
etc.
• DO NOT operate the inverter if it is wet.
• DO NOT install the inverter in the engine
compartment. Install in a well
ventilated, dry area.
• DO NOT use the inverter with a surge
protector or power strip.
• DO NOT use the inverter to power medical
equipment or devices.
• DO NOT replace a fuse with one of a
different type or rating.
• DO NOT operate the inverter near flammable
material or where flammable fumes
or gases may accumulate.
• DO NOT connect the inverter to a vehicle
battery while it is running.
• ALWAYS turn any device connected to the
inverter OFF before starting the
vehicle.
INSTALLATION / OPERATION
FEATURES
MOUNTING
Locate on your inverter in a well ventilated, dry place free
from dirt and grease. Keep the inverter away from heater
vents or heat producing devices. If at all possible, keep the
inverter away from direct sunlight.
CONNECTIONS
Before connecting the inverter to power, determine the
wattage needed to power your devices. Most electrical
devices have labels that indicate the power consumption in
amps or watts. To convert amps into watts, multiply amps by
the voltage. Example; a 110 volt AC device requires 1.2
amps, 110 X 1.2 = 132 watts needed.
CPPI150
CPPI300 / CPPI300HW
1. Lighted On/Off Power Switch – Turns power on
and off to AC outlet(s). I=On, O=Off.
2. 110 Volt AC Power Outlet(s)
3. External Fuse – 20A for CPPI150, 40A for CPPI300
& CPPI300HW.
4. LED – Lights green when 12 volt DC power is
connected and on.
5. Lighter Plug – (CPPI150) Plug into vehicle lighter
receptacle.
6. High Speed Fan – (CPPI300 & CPPI300HW)
7. Positive Binding Post – (CPPI300 & CPPI300HW)
Connect to positive12 volt DC power.
8. Negative Binding Post – (CPPI300 & CPPI300HW)
Connect to negative12 volt DC power.
If you're plugging the inverter into a cigarette lighter
outlet, ensure the outlet can supply the wattage needed.
Most vehicles have a 15 or 20 amp fuse protecting the
circuit. Multiply the fuse rating by voltage to determine
the maximum wattage output available. Example; 12 volts X
15 amp fuse = 180 watts maximum.
NOTE: For loads over 180 watts, connect the inverter
directly to the battery.
NOTE: Some vehicles may require you to turn the ignition
switch to the On position to supply power to the
cigarette lighter outlet.
CAUTION: To prevent fire, damage to the
inverter, vehicle and/or personal
injury, do not replace a fuse with
one of a different type or rating.
NOTE: Some devices, such as TVs and stereos, may require
2 to 6 times their wattage rating to start up. Testing is
the only way to check if the inverter will operate
these devices. If an overload does occur, the inverter
will shut down. Remove the device that caused the
overload and if necessary turn the power switch on
the inverter Off then On.
Connecting to Cigarette Lighter Outlet (All Models)
1. (Models CPPI300 and 300HW) Connect the cigarette
plug harness to the binding posts on the inverter.
2. Plug the cigarette plug into the cigarette lighter outlet.
3. The green LED on the inverter should light showing
power is connected and On.
4. Turn the switch on the inverter to On. This will light.
5. Plug your device into the inverter and use normally.
Connecting Directly to Battery
(CPPI300 and CPPI300HW Only)
1. (Model CPPI300 only) Connect the battery clip
harness to the binding posts on the inverter.
2. Clip the RED (positive +) clip to the positive (+) post on
the battery.
3. Clip the BLACK (negative ) clip to the negative (– –) post
on the battery.
CAUTION: To prevent fire, damage to the
inverter, vehicle and/or personal
injury, never connect the inverter to
a vehicle battery while it is running.
4. The green LED on the inverter should light showing
power is connected and On.
5. Turn the switch on the inverter to On. This will light.
6. Plug your device into the inverter and use normally.
CAUTION: To prevent damage to the inverter
and/or vehicle, turn any device
connected to the inverter OFF
before starting the vehicle.
