Seite 1/12
Installation &
Operation
CPCC15
CPCC25
CPCC40
15 Farad,
25 Farad or
40 Farad
16 Volt Carbon Capacitor
INTRODUCTION
TABLE OF CONTENTS
2
Thank you for purchasing the Rockford Fosgate Carbon Capacitor. The Rockford Carbon Capacitors,
also known as Electric Double Layer Capacitors (EDLC) or Super Capacitors, are passive electrostatic
energy storage devices. They are state of the art technology that allows you to put massive power
storage in a very small space
What are Rockford Carbon Capacitors good for?
Some of the most promising applications that have been found for Rockford Carbon Capacitors are
battery and large audio system performance enhancement. Even the very best batteries, that present
day technology has to offer, have performance limitations determined by the laws of physics and
chemistry that govern their operation. Rockford Carbon Capacitors supply their energy much faster
than a battery. A properly installed Rockford Carbon Capacitor can deliver the instantaneous power
(Amps) that are commonly demanded by today's large audio systems.
How do Rockford Carbon Capacitors compare with Batteries?
Rockford Carbon Capacitors have approximately 10 times the power density of a same sized battery
and the capability of being charged and discharged over 100 times faster than a battery. This is why
they make such great intermediate power sources. However, Rockford Carbon Capacitors do not
have the characteristic battery limitations of a short life span, cold intolerance, and critical charge
and discharge rates.
What makes Rockford Carbon Capacitor Cells so special?
The electrode forming process, which produces ultra-dense yet porous carbon electrodes, and the
continuous operating voltage of 2.7 volts (per cell) give the Rockford Carbon Capacitor the highest
energy storage capacity and power density of any other commercially available components of
comparable size and weight.
To add the finishing touch to your new Rockford Fosgate system order your Punch Sport apparel,
which include everything from T-shirts and jackets to hats and sunglasses.
To get a free brochure on Rockford Fosgate products and Punch Sport apparel,
in the U.S. call 480-967-3565 or FAX 480-967-8132.
For all other countries, call +001-480-967-3565 or FAX +001-480-967-8132.
Or, visit our web site at www.rockfordfosgate.com
Introduction . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Instructions . . . . . . . . . . . . . . . . . . . 3
Contents of Carton . . . . . . . . . . . . . . . . . . . 3
Design Features . . . . . . . . . . . . . . . . . . . . . 4
Safety Features . . . . . . . . . . . . . . . . . . . 4
Visit our web site for the latest information on all Rockford products.
www.rockfordfosgate.com
NOTE: Review each section for more detailed information.
If, after reading your manual, you still have questions regarding this product, we recommend
that you see your Rockford Fosgate dealer. If you need further assistance, you can call us direct at
1-800-669-9899. Be sure to have your model number and date of purchase available when you
call. (Outside U.S. call 1-480-967-3565)
Installation . . . . . . . . . . . . . . . . . . . . . . . 4-7
Installation Considerations . . . . . . . . . . . 4
Mounting Locations. . . . . . . . . . . . . . . . 5
Wiring the System . . . . . . . . . . . . . . . . . 5
Specifications . . . . . . . . . . . . . . . . . . . . . . . 8
Limited Warranty Information. . . . . . . . . . . 9
S IAFETY NSTRUCTIONS
3
This symbol with WARNING is intended to alert the user to the
presence of important instructions. Failure to heed the
instructions will result in severe injury or death.
This symbol with CAUTION is intended to alert the user to the
presence of important instructions. Failure to heed the
instructions can result in injury or unit damage.
CAUTION: To prevent injury and damage to the unit, please read and follow the
instructions in this manual. We want you to have enjoyment from this
system, not a headache.
CAUTION: If you feel unsure about installing this system yourself, have it installed
by a qualified Rockford Fosgate technician.
CAUTION: Before installation, disconnect the battery negative (-) and positive (+)
terminal to prevent damage to the unit, fire and/or possible injury.
WARNING: To prevent serious personal injury, fire and/or damage, ensure the
capacitor has been properly discharged before servicing the vehicle
and/or system components.
CAUTION: Failure to observe the following safety precautions could result in
damage to the capacitor, vehicle and/or personal injury.
DO NOT allow metal objects, such as screwdrivers or other tools, to touch both
capacitor terminals at the same time. The result may cause arcing and
possible fire.
DO NOT use capacitor cells that have signs of damage, including cracks, leaks, or
swelling.
DO NOT expose capacitor cells to flames, sparks or heat at any time.
DO NOT immerse capacitor cells in water or allow water to come into contact
with them at any time.
DO NOT remove the electrolyte filling bolt from the top of a capacitor cell at any
time.
• –DO NOT connect the positive (+) wire from the battery to the negative ( )
terminal of the capacitor.
• –DO NOT connect the negative ( ) wire from the battery to the positive (+)
terminal of the capacitor.
DO NOT make any connections to a capacitor if the connecting polarity cannot
be properly identified. Applying reversed polarity will damage capacitor
cells.
!
!
!
!
!
CONTENTS OF CARTON
Either a model CPCC15, CPCC25 or
CPCC40 Carbon Capacitor Module
Installation & Operation Manual
Charging Resistor
Warning Label
