Speed Controller Programming Instructions
20A/30A/40A/45A/60A/70A/80A/100A/125A/200A
Phrases 1 Enter programming Mode
1. Connect your motor and receiver to the speed controller, but do not connect the
battery yet.
2. Turn on your transmitter and move the throttle stick to the full throttle position (full
up). Please Note: Most Futaba transmitters have the throttle channel reversed by
default.
3. Connect your battery and the controller will initialize with a musical tone.
Phrases 2 Programming
After 3 seconds, the controller will start beeping a sequence of tones β a musical tone
followed by one or more beeps. Each sequence represents a parameter that you can program
and is repeated 3 times. The parameters are:
β Tone + 1 Beep Cell Type and No. of Cells
β . β Tone + 2 Beeps Throttle Setting
β . β . β Tone + 3 Beeps Brake Setting /Throttle type (for Heli)
β β β β Tone + 4 Beeps Direction and Cutoff Type
β β β β β Tone + 5 Beeps Timing Mode
β β β β β β Tone + 6 Beeps Pulse Width Modulation (PWM)
Step 1. Starting. When you hear the sequence for the parameter you wish to program, move the
throttle stick to the .center position
The controller will then of short and long beeps start beeping a Morse code sequence
representing the possible options you may choose for the selected parameter. See table 2 for
a list of all programmable options. Each option sequence is repeated 3 times.
Step 2. Select and save move the throttle stick back to the full up , the select the option,
position., When you hear the sequence for the option you wish to select. The controller will
then save the selected option, and It then goes back sound a long beep as a confirmation.
to the beginning of the programming sequence (phrases 2 step 1).
Step 3. Complete programming and save options. Setup all the parameters you need to change.
When complete, move the throttle stick to the lowest (down) position. The controller will
save all options and re-initialize in normal running mode so you can start your motor.
The table below summarizes the various programming options for each parameter:
A- Aircraft
B- Helicopter
A: Options for Aircraft
1.1 For (2S-7S)-ESC--Cell Type and Number
of Cells
β’ β 1 Short + 1 Long NiMh/NiCD Auto Cell Count - 0.8V/Cell
Cutoff Voltage
β’ β β β’ 1 Short + 2 Long + 1 Short 7S Li-Po (25.9V) β 21V Cutoff Voltage
β’ β β’ β 1 Short + 1 Long + 1 Short + 1 Long 6S Li-Po (22.2V) β18V Cutoff Voltage
β’ β β’ β’ 1 Short + 1 Long + 2 Short 5S Li-Po (18.5V) β 15V Cutoff Voltage
β’ β’ β β 2 Short + 2 Long 4S Li-Po (14.8V) β 12V Cutoff Voltage
β’ β’ β β’ 2 Short + 1 Long + 1 Short 3S Li-Po (11.1V) β 9V Cutoff Voltage
2S Li-Po (7.4V) β 8V Cutoff Voltage
1.2 For (4S-8S) ESC--Cell Type and Number
of Cells
β’ β 1 Short + 1 Long NiMh/NiCD Auto Cell Count - 0.8V/Cell
Cutoff Voltage
β’ β β β’ 1 Short + 2 Long + 1 Short 8S Li-Po (29.6V) β 24V Cutoff Voltage
β’ β β’ β 1 Short + 1 Long + 1 Short + 1 Long 7S Li-Po (25.9V) β 21V Cutoff Voltage
β’ β β’ β’ 1 Short + 1 Long + 2 Short 6S Li-Po (22.2V) β 18V Cutoff Voltage
β’ β’ β β 2 Short + 2 Long 5S Li-Po (18.5V) β 15V Cutoff Voltage
β’ β’ β β’ 2 Short + 1 Long + 1 Short 4S Li-Po (14.8V) β 12V Cutoff Voltage
1.3 For (6S-10s) ESC --Cell Type and
Number of Cells
β’ β 1 Short + 1 Long NiMh/NiCD Auto Cell Count - 0.8V/Cell
Cutoff Voltage
β’ β β β’ 1 Short + 2 Long + 1 Short 10S Li-Po (37V) β 30V Cutoff Voltage
β’ β β’ β 1 Short + 1 Long + 1 Short + 1 Long 9S Li-Po (33.3V) β 27V Cutoff Voltage
β’ β β’ β’ 1 Short + 1 Long + 2 Short 8S Li-Po (29.6V) β 24V Cutoff Voltage
β’ β’ β β 2 Short + 2 Long 7S Li-Po (25.9V) β 21V Cutoff Voltage
β’ β’ β β’ 2 Short + 1 Long + 1 Short 6S Li-Po (22.2V) β 18V Cutoff Voltage
2. Throttle Setting
β’β’ β 2 Short + 1 Long Auto Throttle Range *
β’β’ β β 2 Short + 2 Long 1.1ms to 1.8ms
β’β’ β β β 2 Short + 3 Long Hard start*
β’β’ β β β β 2 Short + 4 Long Soft start
3. Brake Setting
β’β’β’ β 3 Short + 1 Long No Brake
β’β’β’ β β 3 Short + 2 Long Soft Brake*
β’β’β’ β β β 3 Short + 3 Long Medium Brake
β’β’β’ β β β β 3 Short + 4 Long Hard Brake
4. Direction and Cutoff Type
β’β’β’β’ β 4 Short + 1 Long Clockwise Rotation *
β’β’β’β’ β β 4 Short + 2 Long Counterclockwise Rotation
β’β’β’β’ β β β 4 Short + 3 Long Soft Cutoff
β’β’β’β’ β β β β 4 Short + 4 Long Hard Cutoff *
5. Timing Mode Setting
β’β’β’β’β’ β 5 Short + 1 Long 1ΒΊ - For 2-4 Pole Inrunner Motors *
β’β’β’β’β’ β β 5 Short + 2 Long 7ΒΊ - For 6-8 Pole Motors
β’β’β’β’β’ β β β 5 Short + 3 Long 15ΒΊ- For 10-14 Pole Outrunner Motors
β’β’β’β’β’ β β β β 5 Short + 4 Long 30ΒΊ - For 10-14 Pole High-RPM Outrunner
Motors
6. Pulse Width Modulation (PWM) Setting
β’β’β’β’β’β’ β 6 Short + 1 Long 8KHz β For low RPM and low pole count motors *
β’β’β’β’β’β’ β β 6 Short + 2 Long 16KHz β For most out runner motors
