SENATOR STAINLESS STEEL
INSET SINK
WITH FIXED POSITION CLIPS
Installation Instructions &
Aftercare Information
3966-03
B – Sit-on t
A – Flush t
Installer
Please leave this leaet with the user, as it contains valuable
after care advice.
Notes
Please take care of sharp metal edges before and
during installation.
During installation, take care to protect the sink
from scus and scratches.
Avoid straining and overtightening of all plumbing
xtures connected to the sink.
Carefully check that the moulding and edges of the
sink are dead level so that water will ow o the
drainer.
We recommend that the worktop opening is sealed
using waterproof sealant, paint or a similar material.
Fig.1
Due to our policy of continual improvement, we reserve the right to change specications without prior notice.
INSTALLATION
The clamping brackets are suitable for worktops of
greater than 36 mm thickness. If your worktop is a
dierent size then it may require packing under the
clips or rebating.
If ush mounting the sink, we strongly recommend
that this is carried out by a suitably skilled
tradesperson.
We recommend that you t the inset sink to the
worktop before permanently xing the worktop to
the cabinet.
When tting a tap, we recommend you use a tap
stabiliser bracket to ensure a secure t.
Installation
There are two tting options (Fig.1): ush mount and sit-on
t.
Rebate for the sink edge.
Make allowance for silicon sealant.
Sink edge: nominal
thickness 1.2 mm
Marked
outer line
Worktop
Worktop
Cutting line for
opening
6 mm
Outer edge for rebate
1 2 3
SinkWorktop
Fig.2
Fig.3
Fig.4
Flush Mount
1. To accurately determine the size of the sink opening
measure the dimensions of the sink (manufacturer’s
tolerances will cause some variation in the dimensions
stated in the ‘Technical Data’).
Note: You will also need to allow additional space for
the silicon sealant providing the watertight seal.
2. Using a soft, sharp pencil, mark out the sink top opening
dimensions onto the worktop.
3. Draw another line 6 mm inside the sink top outline – this
is the cutting line for the opening (Fig.2).
4. Drill as large a hole as possible inside the cutting line.
Using a router, padsaw, jigsaw or similar, cut out the
opening up to the cutting line.
5. Rebate the worktop up to the outer line (Fig.3).
Note: The sink edge is nominally 1.2 mm thick so rebate
the worktop to a suitable depth, depending on the
worktop material, to allow for a layer of silicon sealant
providing good adhesion and a watertight seal.
6. Fit the retaining clips onto the tags around the edge of
the sink. Open the hinge on each clip.
7. Apply a thin layer of silicon sealant around the worktop
rebate.
8. Turn the sink upside down and lay the worktop over
the sink. Swing each clip into place (Fig.4) – this is the
most eective method, although if the worktop has
been tted to the cabinet the sink can be placed in the
opening and xed in position from underneath.
9. Centre the sink into the worktop recess. Tighten the
xing screws, a few turns at a time, in the sequence
shown in Fig.5. Repeat the sequence until the sink is
secure.
The clamping brackets are suitable for worktops of
greater than 36 mm thickness. If your worktop is a
dierent size then it may require packing under the
clips or rebating.
DO NOT tighten fully at rst attempt.
DO NOT overtighten the clips as this may distort the
sink rim.
10. Remove any surplus silicon sealant.
1
2
3
4
5
6
9
10
7
8
11
12
13
14
1516
Fig.5
