Seite 1/4
Instructions for Manhatton, Keyhole, Chicago, Oakland, Glendale, Baltimore & Arlington
STAINLESS STEEL INSET SINKS
WITH FIXED POSITION CLIPS
Installation Instructions
&
Aftercare Information
Installer
Please leave this leaet with the user, as it contains valuable
after care advice.
Notes
Please take care of sharp metal edges before and
during installation.
During installation, take care to protect the sink
from scus and scratches.
Avoid straining and overtightening of all plumbing
xtures connected to the sink.
Carefully check that the moulding and edges of the
sink are dead level so that water will ow o the
drainer.
We recommend that the worktop opening is sealed
using waterproof sealant, paint or a similar material.
The clamping brackets are suitable for worktops of
between 28–40 mm thickness. If your worktop is a
dierent size then it may require packing under the
clips or rebating.
Installation
Marking Out the Opening
1. We recommend that you t the inset sink to the
worktop before permanently xing the worktop to the
cabinet.
2. Place the sink upside down on the worktop. Position
the sink on the worktop as required. Make sure the
cabinet framework will clear all parts of the sink. Using a
soft, sharp pencil draw around the sink as accurately as
possible (Fig.1). Remove the sink.
Alternatively, you can use a sink template. For details go
to www.rangemaster.co.uk.
3. Draw another line 10 mm inside the sink top outline –
this is the cutting line for the opening (Fig.2).
4. Drill as large a hole as possible inside the cutting line.
Using a padsaw, jigsaw or similar, cut out the opening
up to the cutting line.
Fitting the Sink
1. Open the hinge on the clip.
2. Turn the sink upside down and lay the worktop over
the sink. Swing each clip into place (Fig.3) – this is the
most eective method, although if the worktop has
been tted to the cabinet the sink can be placed in the
opening and xed in position from underneath.
3. Centre the sink. Tighten the xing screws in the
sequence shown in Table 1.
DO NOT tighten fully at rst attempt.
DO NOT overtighten the clips as this may distort the
sink rim.
Remove any surplus sealing material (Fig.4).
Worktop
Final position
of sink
Cutting line for opening
10 mm
Fig.1
Fig.2
Due to our policy of continual improvement, we reserve the right to change specications without prior notice.
1 2 3
SinkWorktop
Worktop
Trim with a sharp knife
Sealing tape
Fig.3
Fig.4
INSTALLATION
Fitting the Arlington Overflow
Pipework
The overow pipework for the Arlington sink will require
modifying to t. Cut the parts as shown (Fig.5). Fit together
as normal.
To ensure a watertight seal, apply silicon sealant onto the
sink-side face of the rubber seal before tting it to the sink
(Fig.6).
1
2
3
4
5
6
7
8
910
1
2
3
4
5
6
7
8
910
1
2
3
4
5
6
7
8
910
1
2
3
4
5
6
78
1
2
3
4
5
6
78
9 10
1
2
3
4
5
6
7
8
9
8 clips
9 clips (keyhole)
10 clips
Table 1 Clip positions and recommended tightening sequence
All dimensions in mm
30 mm
10 mm
55 mm
Rubber seal
Sink-side face
Silicon sealant
Fig.5
Fig.6
