Instructions for Atlantic single, Atlantic double, Quadbowl, Kube
STAINLESS STEEL
UNDERMOUNT BOWLS
Installation Instructions
&
Aftercare Information
Installer
Please leave this leaet with the user, as it contains valuable
after care advice.
Notes
Undermount sinks should only be xed to granite
worktops by a specialist installer.
Please beware of sharp metal edges prior to and
during installation.
During installation, take care to protect the bowl
from scus and scratches.
Avoid straining and overtightening of all plumbing
xtures connected to the bowl.
We recommend that the worktop opening is sealed
using waterproof sealant or a similar material.
Installation
Preparing the Worktop
1. Decide on the position that your bowl (or bowls) is to be
tted. Check that the bowl will not foul on the cabinet
below.
2. Place the sink upside down on the worktop. Position the
sink on the worktop as required. Make sure the cabinet
framework will clear all parts of the bowl. Using a soft,
sharp pencil draw around the bowl as accurately as
possible. Remove the bowl.
Alternatively, you can use a bowl template. For details
go to www.rangemaster.co.uk.
3. Referring to the templates as shown in this booklet,
draw another line – as indicate by ‘A’ (Fig.1) inside the
sink top outline – this is the cutting line for the opening.
4. Drill as large a hole as possible inside the cutting line.
Using a padsaw, jigsaw or similar, cut out the opening
up to the cutting line.
5. On the underside of the worktop, mark the positions for
the threaded inserts – see the templates in this booklet
for the correct dimensions or go to www.rangemaster.
co.uk for template details.
6. Drill the 10 mm diameter holes for the threaded (Fig.1)
inserts (refer to the worksurface supplier for drilling
advice and the drill bit diameter required).
7. Glue the threaded xing inserts into the drilled holes.
Applying the Sealant
Apply silicone sealant (not supplied) to the bowl rim (Fig.2).
14 mm
10 mm
A
Fig.1
Due to our policy of continual improvement, we reserve the right to change specications without prior notice.
Undermount bowl
Fig.2
Dimension A: 33mm, 27mm or 22mm depending on the bowl –
see the templates in this booklet for this dimension.
INSTALLATION
B
C
D
A
Fig.4
Fig.3
A – Threaded insert, B – Fixing clamp, C – Bowl, D – Seal
Fitting the Bowl
Position the bowl to the worktop. Using the xing clamps and
screws (Fig.3), secure the bowl to the worktop (Fig.4).
DO NOT tighten fully at rst attempt.
DO NOT overtighten the clamps.
Remove any surplus sealing material or wipe away any excess
sealant.
Note: Some bowls may require additional support (this
should be supplied and tted by your installer).
Fitting the Square Overflow Pipework
(Kube & Quadbowl models)
The overow pipework for the square style underbowls may
require modifying to t.
Fig.5 shows the suggested areas of the overow pipework
that may need to be cut. Measure the pipework, and cut the
areas show as required. Fit together as normal.
To ensure a watertight seal, apply silicon sealant onto the
sink-side face of the rubber seal before tting it to the sink
(Fig.6).
Rubber seal
Sink-side face
Silicon sealant
Fig.5
Fig.6
