U104320-05
Fitting
Please read all of this instruction before
installing the splashback.
The manufacture disclaims all liabilities
for any damage or injury caused as a
result of not following this instruction
leaet.
This splashback is designed to t on
the wall behind your range cooker.
The wall should be at and clear of any
obstructions.
 Take care, the splashback is
heavy and we recommend at
least two people should t it.
 Beware of sharp edges. Use
gloves when handling the
splashback.
 Before drilling the wall check
that there are no electrical
cables or pipe work in the wall
in the xing areas.
The splashback should be tted AFTER
the cooker has been installed and
BEFORE an extractor hood is tted.
To Fit the Splashback
You will need the following equipment
to complete the splashback installation
satisfactorily
• Apencilormarker
• Arule
• Adrill
• A7mmmasonrydrill
• Acrosspointscrewdriver
• Rawlplugsandscrewsor;ifxing
to a hollow construction plaster,
special plaster board xing screws
or plugs.
In order to t the splashback at the
correct height the cooker must rst be
installed, set to the correct height and
levelled.
If the cooker has a short cooker
splashbacktted   canberemove it. It
retted later if required.
Mark the wall behind the cooker at the
ue grille height.
Move forward.thecooker Measure
down 38 mm from the your marks and
draw a line.
ArtNo.420-0001 Splashback: marking the wall
original line at cooker height
line of bottom edge of splashback
38 mm
This dimension will position the splash
plate as shown in (1).
If you want to mount the splashback
lower as in (2), please be aware that
you have movewill  to thecooker
forwards.
ArtNo.420-0003 Bottom fixing
1 2
Hold the splashback in position with
bottomedgelevelwiththelowerline.
ArtNo.420-0004 Holding the splashback to wall
Bottom line
Splashback
Mark the position of the xing holes on
the wall.
Atleast6screwsmustbeused holdto
the splashback – 3 at the top and 3 at
the bottom.
Removethesplashbackanddrillthe
wallusinga7mmmasonrybit.Using
suitable rawl plugs and screws, secure
the splashback into position.
Note: When tting a cookerhood along
with a splashback, please refer to the
cookerhood instructions for important
tting dimensions.
U104320-05
Care of your Splashback
Cleaning
NEVER USE PAINT SO ELV NTS, WASHING SODA, CAUSTIC CLEANERS,
BIOLOGICAL POWDERS, BLEACH, CHLORINE BASED BLEACH CLEANERS,
COARSE ABRASIVES OR SALT.
Enamelled splashback
Thevitreousenamelledsurfacecannormallybecleanedusingcleanhot
water and a liquid detergent. For any stubborn stains use a nylon scouring
pad or a well moistened soap pad.
AerosolscanbeusedbuttheproductMUSTbesuitable enamelsurfacesfor
andthemanufacturersinstructionsMUSTbefollowed.
Stainless steel splashback
For best results use a proprietary liquid detergent.
Avoid using any abrasive cleaners including cream cleaners on brushed
stainless steel surfaces.
