Seite 1/6
AD22S
AUDIO DELAY
1: 88.8 FRAMES 23.976 fps MEM: A*
2: 88.8 FRAMES 24 fps MEM: A
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
To reduce the risk of electrical shock, do not open the unit. No user
serviceable parts inside. Refer servicing to qualied service personnel.
e symbols shown below are internationally accepted symbols that warn
of potential hazards with electrical products.
is symbol indicates that a dangerous voltage
constituting a risk of electric shock is present within
this unit.
is symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying this unit.
WARNING
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, registers, stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A ground-
ing-type plug has two blades and a third grounding prong. e wide blade or third prong is provided for your safety. If the provided plug does not
t into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord and plug from being walked on or pinched particularly at plugs, convenience receptacles, and the point where it exits from
the apparatus.
11. Only use attachments and accessories specied by Rane.
12. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply
cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
15. e plug on the power cord is the AC mains disconnect device and must remain readily operable. To completely disconnect this apparatus from
the AC mains, disconnect the power supply cord plug from the AC receptacle.
16. is apparatus shall be connected to a mains socket outlet with a protective earthing connection.
17. When permanently connected, an all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in the electri-
cal installation of the building.
18. If rackmounting, provide adequate ventilation. Equipment may be located above or below this apparatus, but some equipment (like large power
ampliers) may cause an unacceptable amount of hum or may generate too much heat and degrade the performance of this apparatus.
19. is apparatus may be installed in an industry standard equipment rack. Use screws through all mounting holes to provide the best support.
WARNING: To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture. Apparatus shall not be exposed to dripping
or splashing and no objects lled with liquids, such as vases, shall be placed on the apparatus.
NOTE: is equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. ese
limits are designed to provide reasonable protection against harmful interference in a residential installation. is equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modications not expressly approved by Rane Corporation could void the user's authority to operate the equipment
is Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Manual-1
OPERATORS MANUAL AD22S
AUDIO DELAY
QUICK START
Your AD22S is out of its box, and now it’s time to integrate it
with your audio setup. But wait! What are these buttons for?
What do all those numbers on the display mean? is guide in-
tends to help you quickly learn the basics and familiarize you with
the device so there’s no delay before you delay.
FRONT PANEL CONTROLS
e rst thing to decide is which alignment mode to use. If you’re
using the AD22S to synchronize audio with video, then select
Video mode. Otherwise select Distance alignment. e DIS-
TANCE and VIDEO buttons on the left hand side of the unit
switch between the two modes. Display settings and delay values
are controlled by using the CHANNEL button to toggle between
channels 1 or 2, and by using the CURSOR buttons to select
the value you wish to change. e COARSE and FINE buttons
increment or decrement the value currently selected.
DISTANCE ALIGNMENT
One of the main applications for the AD22S is synchronizing
an audio signal coming from separate sources at two dierent
distances. Say, for example, you want the music emanating from
a stack of loudspeakers on the lawn at an amphitheater to get to
your audience at exactly the same time as sound coming from
the speaker arrays on stage. e amount of delay needed is the
time it takes sound to travel from the stage to the lawn. While in
DISTANCE mode, this can be displayed in feet, meters, or mil-
liseconds.
VIDEO ALIGNMENT
e AD22S is also excellent for synchronizing audio with video
feeds, especially in a live environment where video processing
typically adds several milliseconds to the signal that can have a
noticeable eect on the nal output. To assist in this application,
the AD22S can show your delay value directly in terms of frames.
All common frame rates for NTSC and PAL/SECAM are sup-
ported, and the audio stream can be delayed with a precision of
0.5 frames to line up perfectly with any video stream.
WEAR PARTS: is product contains no wear parts.
RANE AD 22S AUDIO DELAY
SETTING DELAY
Use the CURSOR buttons to select the unit type, then
press the COARSE or FINE buttons to cycle through options. In
Distance mode, choose between feet, meters, or milliseconds; in
Video mode the delay is shown in frames or milliseconds. If you
know the distance between the sources you are summing, set the
units for feet or meters.
e ambient temperature also aects the speed of sound. To
set the temperature, use the CURSOR buttons to select either °C
or °F, then set the value to the approximate temperature at your
speaker location. e AD22S calculates the correct delay based on
your environment.
Note: Changing units from distance to time does not change
the output delay. For example, if you are viewing the settings for
channel 1 in meters, a change from meters to milliseconds keeps
the same amount of delay but shows it in milliseconds rather than
distance.
LINKING CHANNELS
e LINK button connects the controls so that all changes apply
to both channels. Channels do not need to share the same setting.
While linked, incrementing or decrementing a value changes the
delay for both channels at once. To treat the channels as a stereo
pair, rst set the delay value to the same setting on both channels
before pressing the LINK button.
MEMORY FUNCTIONS
Each channel has two memory banks, A and B. e character *
at the right of the display indicates that the current setting does
not match what is stored in memory.
Pressing STORE copies the current settings into the selected
Memory, clearing the character. e cursor must be over the *
Memory Bank eld before pressing STORE. To activate a stored
setting, press RECALL to change the active delay to the value
stored in the memory location shown. If channels are linked, both
will be recalled.
Additional features are described in Operation
Details on page Manual-4.
