QUICK GUIDE PLDVRCAM30
BUTTONS/FUNCTION:
1. SD Card
2. Power indicator light
3. RST
4. Power/Conrm/Record
5. Upper ,Lower/Fast forward, Rewind
6. USB
7. MIC
8. 2.0”HD Screen(Optional no screen)
9. Playback/Photo/Video
10. Menu/Lock video
1. POWER/CONFIRM/RECORD
• In the power o state, short press the power key to turn on the ma-
chine and enter to the standby state. In the power on state, if you long
press this key, the machine will automatically save video les and then
power o.
• In the video mode, short press the key to control the start and stop of
the video.
• In the photo mode, short press the key to take pictures.
• In the playback mode, short press the key to play and pause the video
le.
• Conrm the setting.
2. RST
• When abnormal conditions occur in the machine, press the key to
reset the machine.
3. RAISE/FAST FORWARD
• Press the key to raise.
• In the video and photo mode, Press the key to Zoom in.
• Fast forward the video le when playing.
4. LOWER/REWIND
• Press the key to lower.
• In the video and photo mode, Press the key to reduced focal length.
• Rewind the video le when playing.
• In the video mode, short press the key to open or o sound recording.
5. MENU/LOCK VIDEO
In the standby state, short press the key one time to video menu, short press
two times to enter to setting menu. In the setting mode, press the key again
to exit to the standby state.
In the photo mode, short press the key one time to enter to photo menu,
short press two times to enter to setting menu.
In the playback state, short press the key one time to le operation menu,
short press two times to setting menu.
Lock Video
In recording state, short press the key to lock current video le, short press
again can unlock the video le.
6. PLAYBACK/PHOTO/VIDEO
A. Playback
In the standby state, short press the key two times to playback state, press
the key again to exit to the standby state
1) In the video mode, short press the mode key two times to playback
mode, you can press upper and lower key to browse the image and video
data.
2) In the playback mode, if you press the menu key, delete, protect and
side show options will appear on the screen. Delete option is selected, you
can delete single le or all les. Protect option is selected, you can’t delete
the le before unlock, so we can protect some important les. Side show
option is browse the le in the TF card automatically, we can select the
times.
B. Photo
In the standby state, short press the key one time to photo state.
C. Video
Once the machine is on, it will be in the video mode.
USE:
1. TURN ON/ OFF
A. Short press the power key to turn on the machine, long press the
power key again to turn o the machine.
B. We must make sure the machine is connected to the car 5V power supply, if
we did that, the machine will power on and working after the car started. The
machine will save current video le and then power o after the car stalled.
2. SYSTEM SETTING
In video or photo mode state, press menu key two times to “System setting”
option. Press the upper and lower key to select the items to be set, press the
power key to conrm the setting, press the menu key again to exit to menu.
INSTALLATION:
Tear the 3M glue at the bottom of the recorder and install the recorder on the
windshield of the car.
FEATURES:
Full Color HD 1080p Video Recording
Camera + Camcorder: Ability to Record Video & Snap Pictures
Comes with All Necessary Cables & Wiring for Installation
Micro SD Memory Card Reader
Easy File Saving & Transfer
Built-in Microphone for Audio Recording
PiP (Picture-in-Picture) View Both Cameras On-Screen
SPECIFICATIONS
DASH CAM:
Compact Size
Windshield Mountable
Built-in 2.0’’ LCD Display Screen
Simple One Button Video Recording
Ability to Instantly Playback Recorded Video
Angle Adjustable Camera Lens
Size (L x W x H): 3.3’’ x 2.1’’ x 1.3’’
TECHNICAL SPECS:
Recording Resolution: 1080P HD, 30fps
Imaging Processor: CMD Full Color
Screen Pixels: 480 x 272
Video Format: .MOV, H.265
TV System: NTSC/PAL
Lens Recording: Wide Angle 170 Degree
USB Connector: 2.0
Maximum Micro SD Support Size: 32GB, Not Included
Sold as: 1
Weight: 0 lbs.
DUAL CAMERA DASH CAM SYSTEM • w/ Micro SD Memory Slot, 2.0’’ Monitor Display
CONNECTION:
