4
3
21
7
6
5
CAUTION:
No user serviceable parts inside. Please return to the agents or a similarly
qualified service centre for repair.
SAFETY INSTRUCTION
1. Please read the user manual carefully before use. Retain for future reference.
2. All warning on the appliance and in the user manual should be adhered to.
3. Do not use the appliance near water.
4. Ventilation-do not blocks any of the ventilation opening.
Do not install near any heat sources or fire.
Do not install in an airtight location.
5. Keep the cord and plugs in good order.
6. The unit may be wiped down with a damp cloth once the unit has been
switched off and the plug removed.
7. Unplug the during lighting storms or when not in use for long periods of time.
8. Keep foreign objects and liquid from entering the unit to avoid short circuit,
fire and electrical accident.
9. Keep the appliance in a dry location.
10. Refer all servicing to the agent or a similarly qualified service centre for repair.
PACKING LIST
Remote control------------------------1 piece
Power cord-----------------------------1 piece
Audio cable-----------------------------1 piece
Manual-----------------------------------1 book
DJ-721200USB
Symptom Possible problem Solution
No function light
& no sound
1.Plug is not well connected
Insert the plug into electrical
outlet
2.Speaker power button is not turned on
Turn on the button
Function light on
but no sound
1.Cable misconnected
Turn off the power, check the
input jack to ensure proper
audio signal is connected to
relevant input jack
2.Speaker are not connected or misconnected
Power off, then check and
confirm the cable connection
again
3.Audio signal is not transmitted to speaker
Check all the speaker if there is
audio signal output
If the problem exists after checking related procedures above, please refer to the appointed service
agent or professional technician to fix it. Do not attempt to open the cover, otherwise we assumes no
responsibility
Simple troubleshooting
When you are in use this speaker run into hereinafter problem, please consult the way
below mentioned. If after dispose the problem is still exist, please look for the qualified
technician or contact our company.To prevent get the electric shock or expand the
scope of the malfunction. Do not repair by yourself.
Connectio n line board on the back
1.Power ON/OFF.
2.Electricity supply AC 120v/60Hz
AC ~1 20 V/ 60 Hz
AC~120V/60Hz
1
2
1.USB / SD Card/Bluetooth Control Console: There are two USB / SD
Card Control Consoles, Channel 1 and Channel 2. After inserting a USB
flash drive / SD Card into the input terminal press the mode button to choose
between audio from the USB or SD Card input or Bluetooth. Bluetooth/FM/
Recording/Remote control function is available on Channel 1 only.
STEPS FOR CONNECTING WITH BLUETOOTH DEVICE
A.Set the Channel 1 Input selector to USB1/SD1/BT then press MODE button
on Ch 1 and enter into bluetooth mode.
B.Search on the bluetooth device and you can find the bluetooth name
“ SBX-921200”
C.Select the SBX-921200 bluetooth name and wait for the device to pair.
The screen will display “SEARCHING”.
D.The SBX-921200 will emit a noise confirming that the devices have
successfully paired and screen will display “BLUETOOTH CONNECTED”
E.Once paired you can play music from your bluetooth device. You can also
use the control buttons on the unit to select the tracks from your bluetooth
device.
Use the MODE button to select the input sources, such as USB/SD/FM/
BLUETOOTH and RECORDING mode and other controls, play/pause,
stop, repeat (Current track / All tracks), previous track & next track to
play audio from the USB flash drive / SD Card.
NOTE: The USB input is ONLY meant to connect to a USB flash drive
(thumb drive). Connecting a MP3 player or computer directly to the USB
flash drive input will result in the unit failing to play the audio from those
devices. There is a 3.5mm input on the rear of the unit designed to connect to
a MP3 player computer.
USB / SD Card Control Console Display Screen
A.SWITCH FOR USB mode, SD mode, BLUETOOTH mode, FM mode, RECORDING
mode.
Notes: The unit is set in USB mode and only when you press “A” button to go to
BLUETOOTH mode OR FM mode or Recording mode. ( BLUETOOTH/FM/
RECORDING function is available for USB 1 only)
B.PLAY/PAUSE- Press this button to pause the signal from the USB flash drive, press
again to play. This button will only function for the USB flash drive signals. When in
BLUETOOTH mode, it will auto search and match the Bluetooth you are using. After
matching the Bluetooth, “ SBX-9212000” will show on the display screen and from the
Bluetooth devices, you can easily find out Bluetooth name. When in FM
mode, press this button to auto scan.
C.SINGLE REPEAT/RAMDOM/ ALL REPEAT
There are 3 types of Repeat and they will show on the screen, and you can press this
button to select the favorable repeat type.
D.Press shortly to go to previous track or previous FM channel, press more than 3 seconds
for fast backward in the USB or SD mode.
E. Press shortly to go to next track or next FM channel, press more than 3 seconds for fast
forward in the USB or SD mode.
SBX-9212000
(1) Search mode: When the word FOLDER is flashing on the screen, the unit is in
FOLDER SEARCHING mode. Turn the FOLDER/TRACK knob to search through
the folder. Press the FOLDER / TRACK knob to choose a track.
Upon exiting the folder mode, the word ALL will appear on the screen. This
indicates that the unit will play all the tracks from the USB flash drive / SD Card.
When the REPEAT button is pressed, there will be 6 different displays depending on
the setting you choose; ALL / NORMAL / SINGLE / FOLDER / RANDOM / BROWSE.
(2) Input Source: The display will show U when set to USB mode and S when set to SD card
mode. Press the mode button to switch from one input to the other.
(3) Track Number: The track number (for all tracks on the entire flash drive) will
appear here. In the picture above the unit is playing track number 1.
(4) Track or Folder Information: The name of the folder will appear here. In the
picture above the folder being played is named MUSIC.
(5) Elapsed Time: The elapsed time of the current track will display here.
2.Track / Folder Searching Knob:
* Turn this knob clockwise to search through all of the tracks inside the USB flash
drive / SD Card. Each track will appear by the name of the track. It will show the
tracks or folders chronologically (from when the files were loaded onto the USB
flash drive / SD Card. Press the knob to begin playing the desired track.
First the tracks on the root file will be displayed and then the tracks that are in folders.
* Press this knob to activate the folder searching function. Once pressed the word
“ FOLDER” will begin flashing on the display screen. Then, turn this knob
clockwise to search the folders inside the USB flash drive / SD Card. Press the
knob to begin playing the tracks from that folder.
3.Level Meter: The VU-meter (with LED indicators) will display the strength of
the output signal.
4.Microphone Echo Volume Control Knob: Turn this knob to adjust the microphone
echo volume level.
5.Microphone Volume Control Knob: Turn this knob to adjust the volume of microphone
6.Channel 1 Input Selector: Use the selector to choose the desired inputs source.
Channel 1 has three different input sources, AUX1 (Red and White RCA inputs on
the rear of the unit), MP3 (3.5mm input on the rear of the unit) and USB1 & SD1
(USB flash drive / SD Card inputs for Channel 1).
7.Treble Control: Turn this knob to adjust the high frequencies of Channel 1& Channel 2.
8.Bass Control: Turn this knob to adjust the low frequencies of Channel 1 & Channel 2.
9.Cue Selector: Press this button to monitor the audio via the headphone connector.
10.Channel Fader: Move the fader up and down to adjust the volume of each channel.
11.Master Volume Fader- Move the fader up and down to adjust the master volume.
12.Channel 2 Input Selector: Use the selector to choose the desired inputs source.
Channel 2 has two different input sources, AUX2 (Red and White RCA inputs on
the rear of the unit) and USB2 & SD2 (USB flash drive / SD Card inputs for Channel 2).
13.Microphone Talkover: When this button is pressed, all signal sources except the
microphone will be reduced to 20dB. The Microphone Talkover is ideal for making
announcements without stopping the music.
14.CH1 / CH2 Crossfader: Slide the crossfader to determine the balance between
Channel 1 and Channel 2. To only play the audio from Channel 1 push the
crossfader slider all the way to the left. To only play the audio from Channel 2
push the crossfader all the way to the right. To have an even balance of audio f
rom Channel 1 and Channel 2 set the crossfader to the center position.
15.Headphones Volume Control Knob: Turn this knob to set the volume of the
headphone output.
15.Headphones Volume Control Knob: Turn this knob to set the volume of the
headphone output.
16.Light
17.RCA Audio Output Terminals: Connect this output to the input on your equalizer,
preamplifier or amplifier.
18.RCA Audio Input Terminals for AUX1: Connect the audio output from your
signal source (DVD player, MP3 player, etc.) to this audio input for Channel 1.
19.RCA Audio Input Terminals for AUX2: Connect the audio output from your
signal source (DVD player, MP3 player, etc.) to this audio input for Channel 2.
20.3.5mm (MP3) Input Terminal: Connect the audio output from a MP3 player/
computer to this audio input for Channel 1.
21.XLR Microphone Input: Connect the DJ professional microphone with 3pin male
XLR type connector to this input terminal.
22.Headphone (6.5mm)Input: connect the headphone to this output terminal.
Power ON/OFF
23.Sound effects volume
24.Sound effects speed
25.With 8 sound effects
12
8
9
10
11
1
2
3
4
6
5
7
1.Standby
2. Previous Channel
3.mp3 Next Song
4.
5.
6.
7.0~9: Through Selected Song
8.Repeat mode ( )
9.
10.Next FM Channel
11.EQ Mode
12. Pause/play/Auto Search/Recording Start And End
FM
Input switch(USB/SD/FM/BLUELOOTH/Recording
mp3 Last Song
Volume+
Volume-
SINGLE REPEAT/RAMDOM/ ALL REPEAT/FOLDER.
TOP CONTROL PANEL
Rear Panel
Remote Control (only for MP3 player 1) SPECIFICATION
Impedance --------------------40hms
Frequency response-----------45-20 KHz
S/N ratio-------------------------92dB±3dB
Electricity supply---------------AC 120/60Hz ±10%
1
2 2
3
4
5
6
77
8 8
99
12
10 10
14
13 15
21
22 16
17
19
18
20
23 24
25
11
1
DJ -7 21 20 0U SB
Produktspezifikationen
| Marke: | Pure Acoustics |
| Kategorie: | Audiosystem |
| Modell: | DJ-721200USB |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Pure Acoustics DJ-721200USB benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Audiosystem Pure Acoustics
7 Juli 2024
6 Juli 2024
6 Juli 2024
Bedienungsanleitung Audiosystem
- Audiosystem Samsung
- Audiosystem Medion
- Audiosystem Nedis
- Audiosystem Philips
- Audiosystem Sony
- Audiosystem Sweex
- Audiosystem Tevion
- Audiosystem AEG
- Audiosystem TechniSat
- Audiosystem Yamaha
- Audiosystem MarQuant
- Audiosystem Grundig
- Audiosystem Kenwood
- Audiosystem Lynx
- Audiosystem Telestar
- Audiosystem Aiwa
- Audiosystem Auna
- Audiosystem Bose
- Audiosystem Lenco
- Audiosystem ODYS
- Audiosystem Pioneer
- Audiosystem JBL
- Audiosystem JVC
- Audiosystem Muse
- Audiosystem Onkyo
- Audiosystem PEAQ
- Audiosystem Technics
- Audiosystem TERRIS
- Audiosystem Teufel
- Audiosystem Akai
- Audiosystem Axxion
- Audiosystem Dual
- Audiosystem Reflexion
- Audiosystem Toshiba
- Audiosystem Tascam
- Audiosystem Zoom
- Audiosystem Ricatech
- Audiosystem Elta
- Audiosystem Fenton
- Audiosystem OneConcept
- Audiosystem Boston Acoustics
- Audiosystem Harman Kardon
- Audiosystem Naim
- Audiosystem Power Dynamics
- Audiosystem S-Digital
- Audiosystem Samson
- Audiosystem Skytec
- Audiosystem Tangent
- Audiosystem Vonyx
- Audiosystem NAD
- Audiosystem Proline
- Audiosystem Omnitronic
- Audiosystem Arcam
- Audiosystem TEAC
- Audiosystem Pure
- Audiosystem Sangean
- Audiosystem NextBase
- Audiosystem Revox
- Audiosystem GPO
- Audiosystem JGC
- Audiosystem Soundmaster
- Audiosystem Sonoro
- Audiosystem Pinnacle
- Audiosystem Ebench
- Audiosystem ION
- Audiosystem Hiteker
- Audiosystem DNT
- Audiosystem Roadstar
- Audiosystem Tivoli
- Audiosystem Tokaï
- Audiosystem Scansonic
- Audiosystem HQ Power
- Audiosystem Polk
- Audiosystem Bluesound
- Audiosystem Devialet
- Audiosystem Fusion
- Audiosystem Iluv
- Audiosystem Jarre
- Audiosystem Karcher Audio
- Audiosystem KRK Systems
- Audiosystem Meridian
- Audiosystem Moneual
- Audiosystem Monitor
- Audiosystem Numan
- Audiosystem Quadral
- Audiosystem Quantis
- Audiosystem Revo
- Audiosystem Roku
- Audiosystem Sitecom
- Audiosystem Tamashi
- Audiosystem Visual Land
- Audiosystem Bang Olufsen
- Audiosystem Argon
- Audiosystem AquaSound
- Audiosystem Belson
Neueste Bedienungsanleitung für -Kategorien-
5 Oktober 2024
26 September 2024
24 September 2024
Sitecom wl 060 wireless audio transmitter Bedienungsanleitung
23 September 2024
23 September 2024
28 August 2024
27 August 2024
27 August 2024
27 August 2024
27 August 2024
